Tiger Tough 97400 Series Assembly Instructions

Skyscraper playground with adjustable height, 26.4” x 16.9” x 100~114”, 67 x 43 x 253-289 cm

Advertisement

Quick Links

Parts List

1
1 PC
Base Platform
23.6" x 15.7" x .8"
67 cm x 43 cm x 2 cm
Bottom
Top
2
(with Fur)
1 PC
House Bottom & Top
14.2" x 14.2" x .8"
36 cm x 36 cm x 2 cm
3
1 PC
Hammock (Bowl)
15.7" dia x 8"
40 cm x 20 cm
4
1 PC
Hammock Platform
15" x 15" x .6"
38 cm x 38 cm x 1.5 cm
5
1 PC
Rope Toy Platform
15" x 15" x .8"
38 cm x 38 cm x 2 cm
7
1 PC
Wand Toy Platform
15" x 15" x .8"
38 cm x 38 cm x 2 cm
8
3 PC
House Interior Post
(2.25" dia)
9
3 PC
House Base Post
3.25" dia x 15"
8.5 cm dia x 38 cm
10
4 PC
Sisal Post
3.25" dia x 19.3"
8.5 cm dia x 49 cm
11
3 PC
Center Post
3.5" dia x 12.6"
8.5 cm dia x 32 cm
12
1 PC
Center Post (Sisal)
3.5" dia x 12.6"
8.5 cm dia x 32 cm
13
1 PC
Top Connect Post (Long)
3.5" dia x 11"
8.5 cm dia x 28 cm
14
1 PC
Top Connect Post (Short)
3.5" dia x 5.5"
8.5 cm dia x 14 cm
15
1 PC
Ceiling Brace
3.9" dia x 12.6"
10 cm dia x 32 cm
16
1 PC
Ceiling Brace Cover
17
3.9" dia x 22.8"
10 cm dia x 58 cm
18
1 PC Rope Toy
19
1 PC Spring-y Ball
1 PC House Cover
Wand Toy
Hardware
Size
Screw
8mm x 40mm
A
B
Dowel
8mm x 65mm
Washer
25mm
C
Allen Wrench
5mm
Quantity
7pcs
12pcs
4pc
FurHaven Pet™ Products
1pc
Bellingham, Washington USA
97400 Series
FOR CATS AT PLAY
TM
Skyscraper
Playground
with adjustable height
26.4" x 16.9" x 100~114"
(67 x 43 x 253~289 cm)
Thank you for choosing Tiger Tough™ for your pet!
For questions and inquiries, please contact FurHaven Customer Service
at 1.888.459.2337 or via email at service@furhaven.com
