KICKER AMP
INSTALLATION GUIDE
FOR USE WITH INDIAN CHIEFTAIN
INCLUDED IN THIS FIT KIT:
> Step-by-step Installation Guide
> 5 1/4" Kicker Speakers Pair
> Kicker Amp 100W/50W
> Stainless Steel Mounting Brackets
> Custom Wiring Harness
> Black Heat Shrink
> Black Cable Tie
&
SPEAKER
> All Necessary Hardware
- 8 - 32 x 1/2" Button Head Bolts
- 8 - 32 Nylock Nuts
- 1/4" - 20 x 5/8" socket head bolts
- 1/4" flat washers
- 1/4" - 20 Klip Nuts
- M6 x 1.9 x 15mm Sockethead bolts
- M10 x 1.5 x 55mm flanged head bolt
- M10 x 1.5 flanged lock nut
- 1/8" x 5.25" speaker spacer rings
Advertisement
Table of Contents
Summary of Contents for KLOCK WERKS FINC14
-
Page 1: Installation Guide
KICKER AMP & SPEAKER INSTALLATION GUIDE FOR USE WITH INDIAN CHIEFTAIN INCLUDED IN THIS FIT KIT: > Step-by-step Installation Guide > All Necessary Hardware - 8 - 32 x 1/2” Button Head Bolts > 5 1/4” Kicker Speakers Pair - 8 - 32 Nylock Nuts >... - Page 2 KLOCK WERKS | INDIAN CHIEFTAIN KICKER INSTALLATION GETTING STARTED | *Please refer to model appropriate service manual for procedures and torque specifications 1. Protect painted surfaces with a soft cloth. 2. Remove the seat. 3. Remove fastener for the ECU tray and safely keep ECU assembly away from the battery box during installation of this kit.
-
Page 3: Speaker Installation
KLOCK WERKS | INDIAN CHIEFTAIN KICKER INSTALLATION 20. Install the amplifier assembly to the motorcycle with the two supplied ¼-20 fasteners and washers. (Pic 8) 21. Connect harness to amplifier. SPEAKER INSTALLATION 22. Disconnect the stock speaker terminals. 23. Remove the four fasteners that hold each speaker to the inner fairing. -
Page 4: Final Assembly
Note: At this time, it is highly recommended to follow the guidelines in your Kicker PX 100.2 owner’s manual to set up the amplifier. Klock Werks recommends that the dip switches be set up as follows: AUTO TURN-ON - 12V INPUT LEVEL - HI HI-PASS –...
