Mode
Repeat press of
scrolls through DAB, FM, Bluetooth™, Aux.
Bluetooth™
Press
to scroll to Bluetooth™ (displayed as "BT mode")
Initiate Bluetooth™ on your device (iPhone/iPad etc). This is usually done in "Settings". Turn Bluetooth™ on, ensuring
the device is in discoverable mode. The mirror will appear as "Radio Mirror". No access code is required.
You can now stream from your Bluetooth™-enabled device.
To disconnect your Bluetooth™-enabled device and link another, first press
Bluetooth™ on the second device and link as above.
EQ Set
Press
Repeat press to scroll through the EQ settings to select your favourite tone.
Classic, Rock, Jazz, Pop, Flat or set your own levels with "My EQ" (bass, treble).
See Detailed Set-Up and Operating Instructions for other functions and preferences.
Switching on for the first time
Use the Remote Control for all set-up functions
Remove the battery cover and remove the battery protector's plastic strip.
Press power
to turn on the unit. The mirror will turn on in DAB mode.
DAB Stations
The DAB radio may run an auto-scan. Do not interrupt while scan is in progress.
At the end of the scan, the LCD will display the number of DAB stations detected.
Stations are found alphabetically (eg Absolute to XFM). If scan does not start
automatically, then press
You can fast click
required station press
If no DAB stations are received, check your aerial connection. If the aerial
connection is good you may be in an area with poor, or no, DAB signal. Check
station availability at www.ukdigitalradio.com.
If you wish to rescan, press
Favourite DAB stations can be saved to presets, see User Instructions.
FM Stations
Press
to scroll to FM
Press
tuner will scan to the next FM station
or hold
for 2 seconds to scan to next FM station
Favourite FM stations can be saved to presets, see User Instructions.
This completes the installer check.
Music In Every Room Ltd
Tenor Audio Mirror
on the remote control.
to scroll through DAB stations. When you reach the
.
on the Remote Control.
to disconnect the first device. Initiate
Bluetooth
FM/DAB Radio
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Tenor Audio Mirror
- Page 1 Music In Every Room Ltd Tenor Audio Mirror Bluetooth FM/DAB Radio Switching on for the first time Use the Remote Control for all set-up functions Remove the battery cover and remove the battery protector’s plastic strip. Press power to turn on the unit. The mirror will turn on in DAB mode.
- Page 2 Using the touch-sensitive buttons to operate the mirror The buttons are capacitive touch sensitive. The larger area of your thumb is more effective than a finger, pressing harder will have no more effect. On/Off Mode Repeat press to select DAB, FM, Bluetooth™ (BT) and auxiliary input (Aux) Back arrow Scroll backwards through radio stations or music album Forward arrow...
- Page 3 Set clock The clock will set automatically when tuned to DAB. Manual setting is only required if no DAB signal is received. The clock can only be set manually when the Tenor Audio Mirror is turned off. Shows set clock to set hours Moves to mins.
- Page 4 Menu functions Mirror must be turned on to be able to access options. Menu functions available when in FM mode Select FM mode then press Scan setting allows the search of strong stations (default) or all stations. to change the setting. to store.
