AGORA SOCCER WATCH INSTRUCTION MANUAL
MODEL: SA-7700

FEATURES:

1. Hour, Minute, Second, Date, and Weekday
2. Soccer timer and stoppage timer to keep track of stoppage time
3. 12 24 Hour Format auto calendar /
4. Alarm
5. Chronograph, 1/100 second, measure up to 9 hours 59 minutes and 59.99 seconds
6. 10 recallable lap and split memories

Time Mode

A) Time Display:

Press D to cycle between the 4 display modes:
TH
(Time
9- 19

:
Press A when showing Time to display Year
A 10 15
30

Press B when showing Time to switch between 12/24 Hour format
(In the 12 Hour Mode it shows A or P for am/pm)
B) Time Setting:

Press C when showing Time and hold for 2 seconds to enter into
Time Setting Mode,

Press A to reset Seconds to 00
9- 19

Press B to sequentially select and adjust
:
A 10 15
30
(Seconds

Use A to adjust the Minutes, Hour, Year, Month, and Day

Press C when finished adjust the Time Settings

Alarm Mode

Alarm Display:

Press D to cycle between the 4 display modes:
AL
(Time

: 12 00
Press A when showing Alarm to turn it On/Off

Press C when in Alarm and hold for 2 seconds to enter into
Alarm Setting Mode, the Hour digit(s) start flashing

Press B to sequentially select and adjust
AL
(Hour
: 12 00

Use A to adjust the Hour, and Minutes

Press C: To complete Alarm Setting

Chronograph Mode

Chronograph Display:

Press D to cycle between the 4 display modes:
(88)
SPLIT
: : ' "
0 00 00
(Time
00

: : ' "
0 00 00 To Start/Stop, press A when showing Chronograph
00

To Reset: Press A to stop, then B to reset

Lap/Split: Reset to 0, then press C to switch between Lap/Split

Pressing B while the Chronograph is running will record Laps/Splits

Pressing C before resetting, will show the records
 Slow 
(Fast

Soccer Timer Mode

Timer Display:
Timer comes factory set for 45 minutes

Press D to cycle between the 4 display modes:
: ' "
00 00
(Time
: ' "
45 00

00
Press B when showing Timer to Start/Stop the countdown
- Press B and hold for 2 seconds to reset to 45'
- When the countdown reaches 00, it will start counting up
- 30 seconds before the time on the Stoppage timer is reached,
It will give 3 short beeps continually until it matches the Stoppage Timer
- When the Stoppage Time is reached, it will give 3 long beeps
Continually for 10 seconds to indicate that the playing time is over.

Press A to Start/Stop Stoppage Time
Press and hold for 2 seconds to reset to 00
(Counting up to 59'59" will reach the limit of the Stoppage Timer
It will return to 00 and continue counting)
B) Soccer Timer Setting:
Timer can be adjusted from 1 to 99 minutes

Press D to cycle between the 4 display modes:
(Time

When the Soccer Timers displays, press and hold C for 2 seconds

Press A to set the desired time (in minutes)

When the desired time has been set, press C to return to the
Soccer Timer display mode.
,
 Alarm  
Chronograph Soccer Timer)
the seconds digits start flashing
   
Minutes Hour Year Month
 Alarm  
Chronograph Soccer Timer)

Minutes)
 Alarm  
Chronograph Soccer Timer)

Average From the first record, to the last)
 Alarm  
Chronograph Soccer Timer)
 Alarm  
Chronograph Soccer Timer)
B
C

Day)
successively:
© 2013-16 Sator Sports Inc
a g o r a
A
(88)
: : ' " SPLIT LAP
8 88 88
88
: : ' "
8 88 88
88
D
- agorasoccer.com
®
S a t o r S p o r t s
b y
a g o r a s o c c e r . c o m
Rev. 2016C
