OPERATOR'S MANUAL
LOTUS 460 / 520
Bhe013-b.chp
®
®
AWS
, LOTUS
and STABILO are registered trademarks. The right of exclusive use belongs to the companies
of the LELY Group.
©2000. All rights reserved. Nothing of this publication may be reproduced and/or published by printing,
photocopying, microfilm or any other way without the prior written permission of LELY INDUSTRIES N.V..
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LELY LOTUS 460
Summary of Contents for LELY LOTUS 460
- Page 1 STABILO are registered trademarks. The right of exclusive use belongs to the companies of the LELY Group. ©2000. All rights reserved. Nothing of this publication may be reproduced and/or published by printing, photocopying, microfilm or any other way without the prior written permission of LELY INDUSTRIES N.V..
-
Page 3: Table Of Contents
TABLE OF CONTENTS ....................page PREFACE ..........................23 WARRANTY CONDITIONS .....................23 TYPE AND SERIAL NUMBER OF YOUR MACHINE ...........23 SAFETY INSTRUCTIONS ....................24 EXPLANATION OF SAFETY DECALS ON THE MACHINE ........25 1 INTRODUCTION ......................26 2 MOUNTING BEHIND THE TRACTOR ..............27 3 TRANSPORT .......................28 4 MACHINE ADJUSTMENTS ..................29 5 OPERATING THE LOTUS ..................30 General instructions ..................30... -
Page 5: Preface
PREFACE This Operator's Manual is meant for personnel that are operating the machine and are responsible for its daily maintenance. Kindly read this manual fully prior to starting work. Such instructions as are related to your safety and/or that of others are marked in the margin by a warning triangle with exclamation mark. -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS - Use the machine only for the purpose for which it was designed. - Follow all prevailing safety regulations, including those laid down in this manual and occurring on the machine. - Operate this machine in a safe way. - The machine should be operated by authorised persons only. -
Page 7: Explanation Of Safety Decals On The Machine
EXPLANATION OF SAFETY DECALS ON THE MACHINE • Carefully read operator's manual before handling the machine. Observe instructions and safety rules when operating. • Attention! Moving parts. Stay clear of rotating machine parts. • Danger of flying objects. Maintain a sufficient, safe distance from the machine as long as the tractor engine is running. -
Page 8: Introduction
1 INTRODUCTION The LOTUS 460 and 520 are rotary tedders which are used for tedding mown grass and for spreading out windrows. The LOTUS tedder is equipped with 4 rotors. Each rotor is fitted with six tine arms with double spring steel tines (fig. -
Page 9: Mounting Behind The Tractor
2 MOUNTING BEHIND THE TRACTOR LOTUS tedder with self steering headstock / STABILO self steering device: - Adjust the tractor 3 point hitch lower arms at equal height. - Fit the lower arms to the linkage pins of the machine's headstock. -
Page 10: Transport
3 TRANSPORT The LOTUS tedder can be transported on the tractor's 3 point hitch. Use all such lighting and warning signals as are manda- tory by law. For transport on public roads: make sure that the front axle weight is sufficient (fit front weights, if necessary) and that the rear axle weight allowed as a maximum is not exceeded. -
Page 11: Machine Adjustments
4 MACHINE ADJUSTMENTS Adjust the machine to the working position (spreading and tedding) as follows. - Set the wheel supports of the lateral rotors and those of the central rotors in the same position. - Remove the blocking pin from the headstock / self steering device and place it in the appropriate hole on top of the headstock (STABILO) or in a vacant hole of the top link plate (fig. -
Page 12: Operating The Lotus
® 5 OPERATING THE LOTUS Make sure that nobody is near the machine at the moment the PTO is engaged. Do not allow anyone to come within a 25 m radius from the machine during work. Stop the tractor engine before leaving the tractor cab. - If the machine is newly commissioned: first carry out the check and maintenance duties which are specified in "7.3 Intermittent Maintenance"... -
Page 13: Forward Speed And Pto Speed
Forward speed and PTO speed Both pick-up and spreading of the crop are dependent on the forward speed and rotor r.p.m. speed. - Select the highest possible forward speed (up to 15 km/h as a maximum). - Operate at the lowest possible PTO output (400 - 450 r.p.m.) always ensuring that the crop is picked up effec- tively. -
Page 14: Dismounting From The Tractor
6 DISMOUNTING FROM THE TRACTOR - Block the trail type headstock / STABILO self steering device (fig. 15). The machine can be stored in either of two positions: folded out or folded up. Storage in the folded-out position is recommended. •... -
Page 15: Maintenance
7 MAINTENANCE Correct machine servicing is necessary with a view to reliable and safe working. Maintenance after operations - Clean the machine thoroughly. - Check the tines and tine arms for tightness and damage, if any. - Grease the machine with a rust preventive. Pay special attention to the tines. -
Page 16: Intermittent Maintenance
Intermittent maintenance Intermittent maintenance has to be carried out: • at the start of the season • before prolonged storage of the machine • when the machine is used extensively during the season. 40 h 40 h - Grease all points of the machine listed in "7.2 Lubrication" - Grease the spring-loaded locking pins of the yoke lock of the PTO shaft. - Page 17 - Convince yourself of the presence and undamaged condi- tion of all safety decals on the machine (fig. 24). (P/N 9.1170.0408.0) - 4x - (P/N 9.1170.0407.6) (P/N 9.1170.0410.2) (P/N 9.1170.0420.5) (P/N 9.1170.0125.4) (P/N 16.61.175) SHELL ALVANIA WR-0 0,25 kg - Check the gearbox for grease leakage Grease to be renewed every 500 working hours for which the cover at the rear side of the gearbox (fig.
-
Page 18: A Technical Details
Supplement A A TECHNICAL DETAILS ® LOTUS Working width 4,60 m 5,20 m Transport width 2,75 m 2,75 m Parking height 2,50 m 2,60 m Machine length 2,20 m 2,20 m Weight 600 kg 640 kg Power required 15 kW 25 kW (20 HP (34 HP)
