Summary of Contents for AEM 5115
- Page 1 ■ POCKET MULTIMETER 5115 ENGLISH User Manual...
- Page 2 ® ® Chauvin Arnoux , Inc., AEMC , are registered ® trademarks of Chauvin Arnoux , Inc. Pocket Multimeter 5115...
-
Page 3: Statement Of Compliance
Refer to our repair and calibration section at www.aemc.com Serial #: 2154.10 Catalog #: 5115 Model #: Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: ® Chauvin Arnoux , Inc. ® d.b.a AEMC Instruments www.aemc.com Pocket Multimeter 5115... - Page 4 Thank you for purchasing the AEMC Pocket Multimeter Model 5115. For best results and safety, read and follow all operating instructions and precautions for use. AC - Alternating DC - Direct current current AC or DC Double insulated Shock Hazard...
- Page 5 Before using the instrument, make sure it functions properly by measuring a known voltage, and check continuity by short circuiting both test leads. Pocket Multimeter 5115...
- Page 6 Replace the batteries immediately when the symbol appears on the LCD display. Disconnect all connections before opening the instrument casing. Use personal protection equipment when conditions require it. Pocket Multimeter 5115...
-
Page 7: Table Of Contents
3.5. Continuity Check ..........15 3.6. Resistance Measurement ......... 16 3.7. Diode Check ............16 3.8. Non-Contact Voltage Detection (NCV) ..... 17 4. MAINTENANCE ............. 18 4.1. Cleaning ............18 4.2. Battery Replacement ......... 18 LIMITED WARRANTY ..........22 Pocket Multimeter 5115... -
Page 8: Introduction
Multimeter Model 5115………..Cat. #2154.10 Includes meter, soft carrying pouch, two lithium CR2032 batteries (installed), and user manual. 1.2. Description The Model 5115 measures AC or DC voltage, resistance, and continuity (with buzzer). It can also perform a diode test. Pocket Multimeter 5115... -
Page 9: Front Panel
1.3. Front Panel Flashlight light Function button LCD display HOLD button Rotary selection MAX button switch Backlight/flashlight button Pocket Multimeter 5115... -
Page 10: Functions
■ Diode test Specifications: Display LCD (includes backlight) Counts 2000pts Power 2 x CR2032 IP40 Safety 600V CATIII Operating range 32 to 122°F (0 to 50°C) Accuracy : 1.2% + 2cts : 1.5% + 8cts Resistance: 1.5% + 5cts Pocket Multimeter 5115... -
Page 11: Setup
1. Remove the back cover fastening screw, using a Phillips-head screwdriver. 2. Remove the back cover. 3. Insert two lithium CR2032 batteries into the battery compartment. Ensure polarity is correct. 4. Replace back cover and fastening screw. Pocket Multimeter 5115... -
Page 12: Instrument Check
(for example a battery). Ensure the reading is accurate. 2.3. Sleep Mode To save battery life, the instrument automatically enters sleep mode and turns OFF the LCD after 30 minutes of inactivity. Press any key to restore normal operation. Pocket Multimeter 5115... -
Page 13: Operation
AC voltage is detected (see §3.8). 3.2. Data Hold Dangerous voltages may be present at the input terminals and may not be displayed. To “freeze” the displayed measurement on the LCD, press the HOLD button. A second press resumes normal measurement. Pocket Multimeter 5115... -
Page 14: Max Mode
AC and DC. 1. Turn the rotary switch to 2. Touch the probes to the desired test points in the circuit. 3. Press the yellow function button to toggle between AC and DC voltage. Pocket Multimeter 5115... -
Page 15: Continuity Check
If there is continuity, the circuit’s resistance is displayed. If the reading is under 30Ω, the beeper sounds, indicating a potential short circuit. If the resistance is above 400Ω, the LCD displays OL, indicating the reading is out of range. Pocket Multimeter 5115... -
Page 16: Resistance Measurement
OFF and all capacitors are discharged. 1. Turn the rotary switch to 2. Connect the red test probe to the anode side and black test lead to the cathode side of the diode being tested. Pocket Multimeter 5115... -
Page 17: Non-Contact Voltage Detection (Ncv)
Point the top of the instrument (labeled NCV) towards the conductor to be tested, and approach the conductor with the instrument. If AC voltage is detected, the LCD backlight blinks red. NCV can detect voltages of 100V and higher. Pocket Multimeter 5115... -
Page 18: Maintenance
Do not use alcohol, chemical solvent or hydrocarbon solvent cleaners. 4.2. Battery Replacement To avoid false readings that could compromise safety, replace the batteries with CR2032 batteries as soon as the battery indicator appears. Follow the battery installation steps in §2.1. Pocket Multimeter 5115... - Page 19 CSA# on the outside of the shipping container. If the instrument is returned for calibration, we need to know if you want a standard calibration or a calibration traceable to N.I.S.T. (this includes a calibration certificate plus recorded calibration data). Pocket Multimeter 5115...
- Page 20 (603) 749-6434 (x360) Fax: (603) 742-2346 or (603) 749-6309 E-mail: repair@aemc.com (Or contact your authorized distributor) Costs for repair, standard calibration, and calibration traceable to N.I.S.T. are available. NOTE: You must obtain a CSA# before returning any instrument. Pocket Multimeter 5115...
- Page 21 ® ® Chauvin Arnoux , Inc. d.b.a. AEMC Instruments 200 Foxborough Boulevard, Foxborough, MA 02035 USA Phone: (800) 343-1391 (508) 698-2115 Fax: (508) 698-2118 E-mail: techsupport@aemc.com www.aemc.com NOTE: Do not ship instruments to our Foxborough, MA address. Pocket Multimeter 5115...
-
Page 22: Limited Warranty
LIMITED WARRANTY The Model 5115 is warranted to the owner for a period of two years from the date of original purchase against defects in manufacture. This limited warranty is given ® by AEMC Instruments, not by the distributor from whom it was purchased. -
Page 23: Warranty Repairs
Phone: (800) 945-2362 (x360) (603) 749-6434 (x360) Fax: (603) 742-2346 or (603) 749-6309 E-mail: repair@aemc.com Caution: To protect yourself against in- transit loss, we recommend you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. Pocket Multimeter 5115... - Page 24 06/18 99-MAN 100457 v3 ® Chauvin Arnoux Inc. ® d.b.a. AEMC Instruments 15 Faraday Drive • Dover, NH 03820 USA Phone: (603) 749-6434 • Fax: (603) 742-2346 www.aemc.com...
