INSTRUCTIONS
CONTROL UNIT
Your PICHLER comfort ventilation unit comes with a MINI remote controller.
These brief instructions focus on the most important functions of your MINI
remote controller, a square switching unit flush-mounted in the living area.

Key assignment MINI

Operation is via 4 push-buttons.
Summer operation
Winter operation
7 LEDs furthermore indicate the current status
of the ventilation unit, a filter check signal and
possible error signals.
1 Summer operation
2 Winter operation
3 Ventilation level 1 (absence mode)
4 Ventilation level 2 (Normal ventilation)
5 Ventilation level 3 (boost ventilation)
6 Filter check message
7 Malfunction

Operating the MINI

C H A N G E S R E S E R V E D . V E R S I O N J UNI 2 016
Arrow up key
Arrow down key
Switching on
Press the Arrow up key until the LED in the fan symbol turns green.
Continuous operation
Continuous operation of your comfort ventilation unit is
necessary to ensure that the unit functions properly.
Arrow keys
Arrow keys = for selecting ventilation levels 1 to 3
Up arrow key = increasing the ventilation level
Down arrow key = reducing the ventilation level
MINI
1
2
7
5
4
3
6
