M092 REV. C SAFETY WARNING: THE BLADES ARE VERY SHARP! BE SURE NOT TO TOUCH THE CUTTING EDGE OF THE BLADES. WARNING To avoid risk of electrical shock, this slicer must be grounded and plug must not be altered. Grounding/Earthing Instructions Slicer MUST be grounded.
3-1/2 inches in diameter. The 350 slicer throat length is 4.25”, while the 350 XL is 5.75”. The slicing of any hard, dense produce such as onions or potatoes will void the warranty and will severely damage the blades and the pusher fingers.
Page 4
M092 REV. C III. Operating Instructions CAUTION: WITH POWER SWITCH OFF, CHECK TO BE SURE THAT PUSHER SECURING KNOB IS TIGHT AND PUSHER FINGERS ARE CENTERED BETWEEN THE BLADES THE FIRST TIME SLICER IS USED AND AFTER CLEANING OR MAINTENANCE. FOR PUSHER ASSEMBLY ALIGNMENT AND ADJUSTING PROCEDURE, SEE PAGE 9.
M092 REV. C IV. Cleaning and Maintenance Instructions WARNING: NEVER CLEAN OR MAINTAIN THE ELECTRIC SLICER WITHOUT TURNING THE ON AND OFF SWITCH TO THE OFF POSITION AND UNPLUGGING POWER CORD FROM POWER SOURCE. 1. The pusher assembly, cover and blade carrier assembly is easily removed for cleaning.
Page 6
M092 REV. C WARNING: THE BLADES ARE VERY SHARP! BE SURE NOT TO TOUCH THE CUTTING SURFACE OF THE BLADES. Please read thoroughly before operation and keep for future reference...
Page 7
M092 REV. C Wash the pusher assembly, the cover and the blade carrier assembly in mild soap and water or in a dishwasher. The rest of the slicer can be wiped off using a damp cloth. WARNING: NEVER SUBMERGE OR PLACE ENTIRE ELECTRIC SLICER OR MOTOR HOUSING IN WATER.
Page 8
NOTE: If for any reason the Model 350, 350XL Slicer does not function properly, consult the trouble-shooting guide for assistance or call the factory or your local service center.
Page 9
M092 REV. C Pusher Assembly Alignment Check and Procedure 1. With the unit unplugged and the ON/OFF switch in the OFF position and the pusher assembly mounted to the unit check the alignment of the pusher fingers to the blades. The pusher fingers should be centered in the spaces between the blades.
Page 10
M092 REV. C Pusher Assembly Actuator Cam AC002 Adjustment The Pusher Assembly includes an easy adjustment for the triggering of the slicer blades to start operating. This can be adjusted for a particular size of food product you are slicing by having the slicing blades start operating earlier or later as the pusher is lowered down to slice food product.
Page 11
M092 REV. C Please read thoroughly before operation and keep for future reference...
M092 REV. C Trouble Shooting Guide Problem Cause Correction I. Slicer will not start. 1. Not plugged into outlet. 1. Plug cord set into grounded outlet with the same voltage as listed on the rating plate located on the side of the motor housing. 2.
Page 13
M092 REV. C 350 SLICER—115V A351DC Please read thoroughly before operation and keep for future reference...
Page 14
M092 REV. C 350 SLICER ASSEMBLY AND PARTS LIST—115V PART NUMBER DESCRIPTION A1500 ASSEMBLY, PUSHER HEAD W/ REMOVABLE INSERT A351DC ASSEMBLY, 350 MOTOR & FRAME A559 WELDMENT, COVER 350 L001 LABEL, WARNING L049 LABEL, NSF MARK 350 FRAME ASSEMBLY (A351DC)—115V...
Page 15
M092 REV. C 350 SLICER—230V A352DC Please read thoroughly before operation and keep for future reference...
Page 16
M092 REV. C 350 SLICER ASSEMBLY AND PARTS LIST—230V PART NUMBER DESCRIPTION ASSEMBLY, PUSHER HEAD W/ REMOVABLE A1500 INSERT A352DC ASSEMBLY, 350 W/230V MOTOR A559 WELDMENT, COVER 350 L001 LABEL, WARNING L049 LABEL, NSF MARK 350 FRAME ASSEMBLY (A352DC)—230V PART NUMBER DESCRIPTION...
Page 17
M092 REV. C 350XL SLICER—115V A357DC Please read thoroughly before operation and keep for future reference...
Page 18
M092 REV. C 350XL SLICER ASSEMBLY AND PARTS LIST—115V PART NUMBER DESCRIPTION ASSEMBLY, PUSHER HEAD W/ REMOVABLE INSERT, A1525 350XL A357DC ASSEMBLY, 350XL MOTOR/FRAME, 115v A559L WELDMENT, COVER, 350XL L001 LABEL, WARNING L049 LABEL, NSF MARK 350XL FRAME ASSEMBLY (A357DC)—115V PART NUMBER DESCRIPTION A6506 ASSEMBLY, FRAME, 350XL...
Page 19
M092 REV. C 350XL SLICER—230V A358DC Please read thoroughly before operation and keep for future reference...
Page 20
M092 REV. C 350XL SLICER ASSEMBLY AND PARTS LIST—115V PART NUMBER DESCRIPTION ASSEMBLY, PUSHER HEAD W/ REMOVABLE INSERT, A1525 350XL A358DC ASSEMBLY, 350XL MOTOR/FRAME, 230V MOTOR A559L WELDMENT, COVER, 350XL L001 LABEL, WARNING L049 LABEL, NSF MARK 350XL FRAME ASSEMBLY (A358DC)—230V PART NUMBER DESCRIPTION A6507 ASSEMBLY, 350XL FRAME W/SUCTION CUPS...
