- Page 1 BWC-040 BWC-060 Wood Chipper Operator’s Manual Parts Breakdown Publica on #: November 2013...
-
Page 2: Table Of Contents
Safety Decal Care Before Operation During Operation Highway and Transport Operations Operation Shortening PTO Start Up Starting up Machine Stopping the Machine Adjustments Feeding Plugging Sharpening Blades Blade / Anvil Clearance Twig Breaker Troubleshooting BWC-040 14-15 BWC-060 16-17 PTO Shaft Warranty... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing your Belco Resources Equipment BWC Wood Chipper. Your wood chipper is design to be used on Cat. 1 540 rpm tractors. It is important to properly maintain in keep in place all safety guards and shields that came with your chipper. -
Page 4: Safety Signal Words
SAFETY SIGNAL WORDS Note the use of the signal words DANGER, WARNING and CAUTION with the safety messages. The appropriate signal word for each has been selected using the following guidelines: DANGER: Indicates an imminently hazar dous situation that, if not avoided, will r esult in death or ser ious injury. -
Page 5: Safety Decal Care
SAFETY DECAL CARE Keep safety signs clean and legible at all times. Replace safety signs that are missing or have become illegible. Replaced parts that displayed a safety sign should also display the current sign. Safety signs are available from your Distributor or Dealer Parts Department or the factory. How to Install Safety Signs: ... -
Page 6: During Operation
Don’t hurry the learning process or take the unit for granted. Ease into it and become familiar with your new equipment. Practice operation of your equipment and its attachments. Completely familiarize yourself and other operators with its opera- tion before using. -
Page 7: Highway And Transport Operations
HIGHWAY AND TRANSPORT OPERATIONS Adopt safe driving practices: Keep the brake pedals latched together at all times. NEVER USE INDEPENDENT BRAKING WITH MACHINE IN TOW AS LOSS OF CONTROL AND/OR UPSET OF UNIT CAN RESULT. Always drive at a safe speed relative to local conditions and ensure that your speed is low enough for an emergency stop to be safe and secure. - Page 8 Watch for obstructions overhead and to the side while transporting. Always operate equipment in a position to provide maximum visibility at all times. Make allowances for increased length and weight of the equipment when making turns, stopping the unit, etc. ...
-
Page 9: Operation
Operation It is important that each operator of the Tar River Wood Chipper read and understand the operational pro- cedures and all related safety precautions outlined in this section. The following preoperation checklist is provided for the operator. It is important for both the personal safety and maintaining good mechanical condition that this checklist is followed. -
Page 10: Start Up
Do not shorten too much, the proper overlap is a minimum of 1/3 the length of each profile. Start up Although there are no operational restrictions on the Wood Chipper when used for the first time, it is recommended that the following mechanical items be checked: Before start up and after operating for 1 hour and every 5 Hours of operation ... -
Page 11: Feeding
Feeding The BWC may be available in either gravity or hydraulically feed. Danger: If gravity feed be careful not to reach into the feed hopper further than the curtain. To r each further, use a stick or branch to push any material into the disc that does not go in on its own. To begin operations, slowly slide the material to be chipped into the hopper. -
Page 12: Blade / Anvil Clearance
Anvil/Blade Clearance: It is recommended that the clearance between the rotor and anvil be set and maintained at 1/32 to 1/16 inch to obtain the best performance. Use the stationary blade mounting bolts to set the clearance as required. Twig Breaker: Caution: Clear the area of bystanders, especially small children. -
Page 13: Troubleshooting
Troubleshooting PROBLEM CAUSE SOLUTION Rotor not turning. Obstructed discharge. Shut down and clear debris. Rotor plugged. Clear rotor. Broken shear pin. Replace shear pin. ... -
Page 14: Bwc-040
Belco Resources Equipment BWC-040 ... -
Page 15: Bwc-040
Belco Resources Equipment BWC-040 Posi on Part # Descrip on 1 BX4‐0601 Deflector 1 2 BM0812516 Bolt ‐ 8x1.25x16 4 3 NM80000 Nut 8mm 2 4 BX4‐9313 Knob ‐ Deflector 2 5 BX4‐0600 Discharge Chute 1 6 BM610020 Bolt ‐ 6x1.00x10 ... - Page 16 Belco Resources Equipment BWC-060 ...
- Page 17 Belco Resources Equipment BWC-060 Posi on Part # Descrip on 1 BM610020 Bolt ‐ 6x1.00x20 4 2 BX6‐0607 Support ‐ Flap 1 3 BX6‐0903 2 Flap 4 BX6‐0101 1 Chute 5 BM1217535 Bolt ‐ 12x1.75x35 7 6 BX6‐0901 Anvil 1 ...
-
Page 18: Bwc-060
Belco Resources Equipment BWC-060 & BWC-060 8 Pos. Part # Description 1 DP1075‐40 PTO Yoke ‐ Series 40 1 2 DP1078‐40 Male Yoke and Tube (implement end) ‐ Series 40 1 3 DP1079‐40 Female Yoke and Tube (tractor end) ‐ Series 40 1 4 DP1074M‐40 Complete Male End PTO Shielding (implement end) ‐ Series 20‐40 1 5 DP1074F‐40 Complete Female End PTO Shielding (tractor end) ‐ Series 20‐40 1 6 DP1076‐40 Cross and Bearings ‐ Series 40 2 7 5SB3007 Safety Chain ... -
Page 19: Warranty
Warranted parts shall be provided at no cost to the user at an authorized Belco Resources Equipment dealer during regular working hours. Belco Resources Equipment reserves the right to in- spect any equipment or parts which are claimed to have been defective in material or work- manship. - Page 20 Increasing agricultural productivity since 1974 Belco Resources Equipment P.O. Box 8164 Tel: 252-442-0700 Rocky Mount, NC 27804 Fax: 252-442-0787 Sales@BRGlimited.com www.BR-Equipment.com...
