Shibuya Hoppmann L500A V2 Installation & Maintenance Manual

High speed labeler

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Refer all servicing to qualified personnel.

This manual is intended for use by qualified

mechanic and electricians who install or service

the L500A V2 High Speed Labeler.

Please copy this information from

the L500A V2 High Speed Labeler's

serial plate.

13129 Airpark Drive, Suite 120 • Elkwood, Virginia 22718 • USA

Tel: (540) 829-2564 • Fax: (540) 829-1726 • E-mail: publications@ShibuyaHoppmann.com

Duplication of this manual, in whole or in part, requires written consent of Shibuya Hoppmann Corporation.

L500A V2 High

Speed Labeler

Installation/Maintenance

Manual

Model Name:

Model Inventory Number:

Table of Contents

Need help?

Do you have a question about the L500A V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Shibuya Hoppmann L500A V2

Page 1 © 2011 Shibuya Hoppmann Corporation 13129 Airpark Drive, Suite 120 • Elkwood, Virginia 22718 • USA Tel: (540) 829-2564 • Fax: (540) 829-1726 • E-mail: publications@ShibuyaHoppmann.com Duplication of this manual, in whole or in part, requires written consent of Shibuya Hoppmann Corporation.
Page 2: Quick Start
The lightning bolt caution symbol denotes possible personal injury and/ or damage to the equipment from electrical hazards. Equipment Improvements & Shibuya Hoppmann Corporation (SHC) continually improves its products, and reserves the right to change Document Revisions Notice or discontinue specifications and designs shown in this manual without notice and without incurring obligation. SHC has made every effort to verify the information contained in this manual, but reserves the right to correct...
Page 3: Table Of Contents
Description and The Label Applicator Specifications 11 Applicator Specifications Figures/Tables: Figure 1‑1. Label Applicator Figure 1‑2. Side View of L500A V2 Labeler Figure 1‑3. Back View of L500A V2 Labeler 11 Table 1‑1. Applicator Specifications Safety Precautions Warnings and Conditions Figures: Figure 2‑1. Additional Warning Labels...
Page 4 L500A V2 High Speed Labeler Manual Page Chapter Applicator Setup Figures/Tables: 23 Table 4‑1. Label and Web Specifications Figure 4‑1. Web Path/Label Threading Path Figure 4‑2. Unwind Assembly/Installing New Labels Figure 4‑3. Lockout Knobs and Nip Rollers Figure 4‑4. Rewind Assembly/Threading Figure 4‑5. Light Tower Figure 4‑6.
Page 5 Table of Contents Page Chapter Operator Interface Operator Interface Map Operator Interface Operation Operating Mode Main Screen Parameter Display Screen Operational Modes ‑ Jog Operational Modes ‑ Label Auto‑Teach Operational Modes ‑ Auto‑Center Teach, Auto‑Center & Encoder‑Value Teach Operational Modes ‑ Wipe‑On Mode Operational Modes ‑...
Page 6: Terms And Definitions
Page Chapter Replacement Parts How to Order Spare Parts L500A V2 Recommended Replacement Parts List Figures: Figure 7‑1. L500A V2 Labeler ‑ Views with Parts Callouts Appendix Warranty Figures: Figure 8‑1. Wiring Diagram Figure 8‑2. Wiring Diagram Terms and Definitions...
Page 7: Description And Specifications
Description and Specifications The Label Applicator Thank you for purchasing a label applicator. The applicator will meet the needs of the single label, the stand alone applications or the integration into an inline product handling system. The applicator's patented head design has one of the lowest drive inertias in the industry.
Page 8 L500A V2 High Speed Labeler Manual UNWIND ASSEMBLY DANCER ARM ASSEMBLY DANCER ARM IDLER ROLLERS ROLLERS IDLER ROLLER TOUCHSCREEN (CONTROL PANEL) REWIND IDLER ASSEMBLY ROLLER NIP ROLLERS (2) (HIDDEN BY COVER PLATE) DRIVE ROLLER (HIDDEN BY TORQUE COVER PLATE) FORK...
Page 9 Chapter 1 Description and Specifications UNWIND ASSEMBLY TOUCHSCREEN (CONTROL PANEL) DANCER ARM ROLLERS REWIND ASSEMBLY DRIVE MOTOR NIP ROLLER LOCKOUT CAM FOR NIP ROLLERS DRIVE ROLLER PEELER PLATE LABEL (BOTTOM OF SENSOR WIPER ARM) Figure 1-2. Side View of the L500A V2 Labeler...
Page 10 L500A V2 High Speed Labeler Manual UNWIND ASSEMBLY DANCER ARM ASSEMBLY TOUCHSCREEN (CONTROL PANEL) REWIND ASSEMBLY DRIVE MOTOR IDLER ROLLER PEELER PLATE (BOTTOM OF WIPER ARM) TORQUE FORK ASSEMBLY Figure 1-3. Different Views of the L500A V2 Labeler (Back View)
Page 11: Applicator Specifications
Chapter 1 Description and Specifications Applicator Specifications The manufacturer or distributor may have changed specifications to match your application. Please refer to Table 1‑1 for applicator specifications. Applicator Specifications Accuracy ±0.02" (±0.5mm) depending on the application module Controls Dual processor Product Detection Photo sensor Label Sensor Capacitance Power Requirements 115 VAC, 60 Hz, single phase, 6 Amp Shop Air (For Modules Only) 80 psi minimum, 100 psi maximum to the filter/regulator Environment 41-104˚F (5 to 40˚C) operating temperature...
Page 12 L500A V2 High Speed Labeler Manual Notes...
Page 13: Safety Precautions
Safety Precautions Warnings and Conditions Turn Off Power! Before servicing, make sure you have turned off the compressed air and electrical power in a way which prevents accidental reactivation. Padlock and clearly tag the appropriate electrical and pneu‑ matic disconnects. Wait at least two (2) minutes after disconnecting the electrical power to discharge the motor start capacitor before performing any electrical servicing with the rear cover removed.
Page 14 L500A V2 High Speed Labeler Manual Notes...
Page 15: Applicator Installation
Applicator Installation This chapter covers unpacking, inspection, positioning and power hookups for the label applicator. Unpacking and Inspection Step 1. Check the Shipping Container. The shipping container protects the ap‑ plicator under most circumstances. Visually inspect the outside of the shipping container.
Page 16: Figure 3-1. Correct/Incorrect Positioning
L500A V2 High Speed Labeler Manual The labeler must be positioned so that labels are applied to the product with the proper orientation. Once the correct orientation is obtained, the labeler is ready to be placed into position. The product and labeling surface should be parallel with each other at point of contact.
Page 17: Figure 3-2. Rotation Adjustment
Chapter 3 Applicator Installation 103˚ PEELER WIPER ARM 90˚ PRODUCT Figure 3-2. Rotation Adjustment Rotation adjustment of the wiper arm and peeler tip (refer to Figure 3‑2) should be made to locate the flag of the label as close to the product as possible. The peeler tip should be located just above the product. A ref‑ erence of 0˚ (zero degrees) from the product is suggested on the wiper arm.
Page 18: Figure 3-3. U-Arm
L500A V2 High Speed Labeler Manual U-Arm & T-Stand If a T‑stand and/or U‑arm is purchased with your unit, refer to Figures 3‑3 and 3‑4 for proper positioning. To pivot the applicator up or down, loosen the large hex nut which fastens the U‑arm to the T‑stand.
Page 19 Chapter 3 Applicator Installation HEX NUT HANDLE FOR FOR PEELER VERTICAL TIP MOVEMENT MOVEMENT LOCK SOCKET HEAD BOLTS FOR TOP OR SIDE- LOCKING PANEL CASTERS LABELING ADJUSTMENTS MOUNTING BOSS FOR OPTIONAL LEVELING FEET Figure 3-4. Adjustment for T-Stand and U-Arm Use the handle at the top of the T‑stand to raise or lower the applicator to the desired height relative to the product.
Page 20: Remote Electrical Enclosure/Interface Panel
L500A V2 High Speed Labeler Manual Remote Electrical Enclosure /Interface Panel Connections for the interface panel are found on the remote electrical enclosure (see to Figure 3‑5.) These connections are easily accessible for quick changeover between modes of operation. The following is an...
Page 21: Power Supply
Chapter 3 Applicator Installation Power Supply Supplying the unit with the correct supply voltage and compressed air (if necessary) permits safe and efficient operation. (Refer to Table 1‑1 for exact specifications.) Note: Compressed air is only needed with certain applicator modules. Verify Main Power The applicator is supplied with a power cord for AC operation. Plug the power cord into an outlet with the proper voltage and ground.
Page 22 L500A V2 High Speed Labeler Manual Notes...
Page 23: Applicator Setup
Applicator Setup Label Threading Only use labels that can be stripped out. More information on label and web specifications are available in Table 4‑1. Before installing a label roll please read Table 4-1 to insure the selec- tion of proper label stock. Label & Web Specifications Label Style Stripped out form only, with a minimum spacing of 0.125"...
Page 24: Figure 4-1. Web Path/Label Threading Path
L500A V2 High Speed Labeler Manual Refer to Figure 4‑1 to assist in proper label threading. A label threading diagram is supplied on the front of the labeler. Store label stock in a cool, dry place to avoid heat damage.
Page 25: Figure 4-2. Unwind Assembly/Installing New Labels
Chapter 4 Applicator Setup Procedure Refer to the circled numbers (1 through 18) on the front of the Labeler as shown in Figure 4‑1 to assist you in following this label threading procedure. Step 1. Remove Outer Flange. With the power off, remove the outer disk from the unwind roller by releasing the handles and lifting the cover up and off the unwind extrusion.
Page 26 L500A V2 High Speed Labeler Manual Step 4. The Nip Roller. To thread the stock between the drive roller and the nip roller, you must first release the tension on the nip rollers. Lift up on the lockout knob on top of the face plate cover (see Figure 4‑3) and rotate them 180˚. Move each cam outward until the cams' locks drop back down into the slots. This locks the nip rollers away from the drive shaft.
Page 27: Figure 4-4. Rewind Assembly/Threading
Chapter 4 Applicator Setup Do not use foil or metal labels with capacitance sensor. They will dam- age the label sensor. Step 6. Second Nip Roller. Thread the label back up towards the drive shaft, feeding the label between the drive shaft and the 2nd nip roller (refer to position #12).
Page 28 L500A V2 High Speed Labeler Manual Step 9. Re-engage the Nip Roller Lockout Knobs. Re‑engage the nip roller lockout knobs by turning the knobs 180˚, lifting up on the knobs and pulling them center towards the drive shaft (this should be tight, and maintain a firm grip on the knobs). Once the nip rollers are in place, push the knobs down into the openings on the front cover (see Figure 4‑3).
Page 29: Light Tower (Optional)
Chapter 4 Applicator Setup Light Tower (Optional) The optional light tower (refer to Figure 4‑5) can be connected to the labeler to indicate different conditions of the labeler at any given time. RED - INDICATES LABELER IS NOT READY; FAULTED AMBER - INDICATES A LOW LABEL SITUATION...
Page 30: Rewind Clutch Adjustment
L500A V2 High Speed Labeler Manual Rewind Clutch Adjustment Adjust the rewind assembly so the label stock rewinds smoothly. No snapping or slack should occur. Adjust the rewind assembly by turning the hex nut on the end of the rewind shaft clockwise or counterclockwise.
Page 31: Product Sensor
Chapter 4 Applicator Setup Product Sensor The sensor supplied with the applicator is connected directly to the mod‑ ule interface panel. This allows for quick changeover of sensor style as applications dictate. (Note: This is not used when the labeler is used in Rotary applications.) The sensor is shipped with a mounting bracket that should be mounted slightly upstream from the applicator.
Page 32 L500A V2 High Speed Labeler Manual To select between sensing the leading edge or the trailing edge of a product leave the sensor operate switch set to "light operate" at all times. In the PRODUCT SENSOR EDGE screen of the operator interface select (0)
Page 33: Lion Lrd 2100 Label Sensor
Chapter 4 Applicator Setup should be on. If a red pulse is not observable, reduce the GAIN control (counterclockwise rotation) to obtain a countable pulse rate. Once you feel comfortable with the set GAIN, test by removing the object from the sensing position. The red LED indicator should go “off”. If the LED indicator does not go “off”, the sensor is reacting to light reflected from a background surface.
Page 34 L500A V2 High Speed Labeler Manual Setup The sensor is stable and should not require re‑adjustment after the first initial setup unless there is significant change in the shape and/or thick‑ ness of the label, or changes in power supply voltage. Step 1. Remove all material from sensor. Step 2. Gain Adjust. Center "GAIN ADJUST" (see Figure 4‑10) ‑ Turn GAIN ADJUST four (4) turns counter‑clockwise, then turn GAIN ADJUST two (2) turns clockwise.
Page 35: Setting The Labeling System
Chapter 4 Applicator Setup Step 4. Final Gain Adjust. Set GAIN ADJUST by inserting material into the sensor and moving them through the sensor. Set GAIN ADJUST at the point when the EDGE light starts to flash; then continue with a one‑half (1/2) clockwise turn. The sensor is now adjusted and should function correctly. Figure 4-11.
Page 36 L500A V2 High Speed Labeler Manual Step 4. Run Auto-Teach Function. Run the AUTO‑TEACH function. If sys‑ tem stalls, reduce the ACCELERATION/DECELERATION RAMP and START STOP SPEED until the stalling subsides. Note: Default setting for A CCELERATION/DECELERATION RAMP and START STOP SPEED is 50. Step 5.
Page 37: Right-Hand To Left-Hand Conversion
Chapter 4 Applicator Setup Right-Hand to Left-Hand Conversion The L500A V2 Applicator can be converted from dispensing labels from the right, to dispensing labels to the left. The disassembly and reassembly of the applicator requires no additional parts. Attention to detail, a large...
Page 38: Figure 4-12. Wiper Arm Assembly Removal
L500A V2 High Speed Labeler Manual Changeover Procedures Step 1. Turn the power off (using the disconnect switch) and disconnect all of the remaining external cables from the Remote Electrical Panel. Remove any label media and the label sensor, and place the labeler horizontally on a table where you are able to access the entire labeler.
Page 39: Figure 4-14. Side Cover Removal
Chapter 4 Applicator Setup DRIVE MOTOR BACK PLATES Figure 4-14. Side Cover Removal (STAINLESS STEEL) Figure 4-15. Side Cover Removal Step 4. Remove the Torque Fork Assembly by loosening and removing the two hex nut screws on the face of the assembly (see Figure 4‑16 and 4‑17). Set the assembly aside.
Page 40 L500A V2 High Speed Labeler Manual Step 5. Turn the labeler to an “upright” or vertical position. At the top of the back panel, remove the retaining (snap) rings from the Unwind Assem‑ bly shaft and the Dancer Arm shaft (see Figures 4‑18 and 4‑19). There may or may not be shims associated with the retaining rings.
Page 41 Chapter 4 Applicator Setup BELT TENSIONER DRIVE SOCKET HEADS BELT SOCKET HEAD BELT CAP SCREWS TENSIONER (MOTOR TO MOUNT) MOTOR BELT CABLE TENSIONER JAM NUT SOCKET HEAD CAP SCREWS (MOTOR MOUNT PLATE) 4-20. Belt Tensioner and Motor Mounting Plate with Motor Step 10. Mark the motor mounting plate opposite the current motor side with a magic marker to identify the flip side for reassembly.
Page 42 L500A V2 High Speed Labeler Manual Step 15. Remove the Rewind Flange (Assembly) from the front of the labeler by removing the screw located on the side of the Rewind Flange (the extrusion ‑ see Figure 4‑21). Note that the screw should be removed as shown in the drawing, in an “upside down”...
Page 43 Chapter 4 Applicator Setup Step 19. Remove the front cover‑to‑ back cover side standoffs REWIND CLUTCH ASSEMBLY and switch to the other side of the labeler (see Figure 4‑23). Move the three (3) motor standoffs on the rear of the labeler to the oppo‑ site side.
Page 44 L500A V2 High Speed Labeler Manual Step 21. Remove the cap plug from the opposite side bearing and reinstall the cap plug into the bearing where the Rewind Shaft and Clutch was re‑ moved in Step 18. Step 22. Slide the Rewind Shaft through the Clutch Assembly with the shim in‑...
Page 45 Chapter 4 Applicator Setup Step 25. Install the Rewind Clutch Bearing plate onto the end of the Rewind Shaft on the rear of the labeler. Step 26. Reinstall the retaining ring and shim, if applicable, onto the end of the Rewind Shaft.
Page 46: Figure 4-28. Unwind Flange Shaft Key
L500A V2 High Speed Labeler Manual BRAKE BELT UNWIND FLANGE SHAFT - KEY DANCER FRONT OF LABELER Figure 4-28 . Unwind Flange Shaft Key Step 33. Remove the unwind assembly (front of labeler) by unscrewing the knob until the extrusions comes off the shaft. There is a key on the shaft of the unwind flange ‑ set it aside (see Figure 4‑28).
Page 47: Figure 4-31. Removing The Brake Belt
Chapter 4 Applicator Setup Step 36. On the rear of the labeler, loosen the set screw in the cam at the end of the dancer BRAKE BELT arm shaft while supporting the control arm. Remove the cam (see Figure 4‑30). Step 37.
Page 48 L500A V2 High Speed Labeler Manual Step 40. Reinstall the dancer arm by positioning it between the two bumpers on the front of the labeler and using the socket head screw. Reattach the spring to the spring arm (reversal of Step 34.) Step 41.
Page 49 Chapter 4 Applicator Setup Step 49. Turn on the disconnect and power up the labeler. The applicator will take 30 seconds to boot up. Step 50. The motor direction needs to be changed. Enter the “PARAMETER SETUP” menu and enter the appropriate code to change the “Motor Direction”...
Page 50 L500A V2 High Speed Labeler Manual Notes...
Page 51: Operator Interface
Operator Interface �� LOW-SPEED HIGH-SPEED LAB. PITCH SINGLE STEP LABEL-TEACH START/STOP AUTO-CENTER AUTO-CENTER TEACH START AUTO-CENTER ON AUTO-CENTER OFF WIPE-ON ASYNCHRONOUS SPEED + / SPEED - DELAY + / DELAY - SYNCHRONOUS SPEED + / SPEED - DELAY + / DELAY - TAMP-ON STOP BLOW-ON...
Page 52 L500A V2 High Speed Labeler Manual Continued on From Previous Page �� PARAMETER TAMP DELAY PARAMETER - TAMP TAMP DWELL VACUUM DELAY VACUUM OFF DWELL AIR ASSIST DELAY AIR ASSIST DWELL PARAMETER - BLOW BLOW DELAY BLOW DWELL...
Page 53: Operator Interface Map
Chapter 5 Operator Interface Operator Interface Map The previous page contains a brief flow chart of the program layout. Please note that all the screens are accessible through the Operator’s Panel. Note: Turn the labeler off (via the Disconnect Switch) before plugging the remote operator panel into the port. Then turn the power back on to access remote operator panel.
Page 54: Main Screen
L500A V2 High Speed Labeler Manual The settings the operator enters into the operator panel will affect the labeler differently depending on the mode the operator has chosen. Main Screen Main Screen Once powering up the applicator, the main screen is accessible after thirty (30) seconds.
Page 55: Parameter Display Screen
Chapter 5 Operator Interface Parameter Display Screen Key Assignment of Parameter Display Menu: (shows the established values on the parameter screen for that parameter) Parameter Group Parameter Name PARAMETER - WIPE Parameter Unit START DELAY +00000 [Increm] Parameter -EXIT ENTER SCRUP SCRDN Value Press...
Page 56: Operational Modes - Jog
L500A V2 High Speed Labeler Manual Operational Modes - Jog The JOG function is used to manually position the label to the correct position at the peeler plate. It can also help to adjust the labeler dispens‑ ing speed (using a tachometer) while in asynchronous labeling mode.
Page 57: Figure 5-4. Label Auto-Teach
Chapter 5 Operator Interface There are two ways to enter the label pitch and stop distance for the Label‑Teach operation: Option 1. Measure label pitch (length + gap) and stop distance and enter as param‑ eters using the terminal. Note: All values are in motor steps. Option 2. Place label web with manual function to the dispensing position. Then activate the LABEL_TEACH to start teach in procedure (Note: motor moves with the low jog speed).
Page 58: Operational Modes - Auto-Center Teach, Auto-Center
L500A V2 High Speed Labeler Manual Operational Modes - Auto-Center Teach, Auto-Center and Encoder-Value Teach This function is used to “teach” the product length and is used in combi‑ nation with the AUTO‑CENTER function. (Refer to the Parameter‑Setup section later in this chapter for additional information on Auto‑Center parameter).
Page 59: Figure 5-5. Auto-Center Teach Screen
Chapter 5 Operator Interface 5. Put the product on the conveyor and run it past the product sensor at low speed. The controller measures the length of the product in encoder increments. Product length: Leading product edge to trailing product edge detected by the product sensor. 6.
Page 60: Operational Modes - Wipe-On Mode
L500A V2 High Speed Labeler Manual Operational Modes - Wipe-On Mode The WIPE‑ON mode can run in either synchronous or asynchronous dispensing mode. Both modes can be used to dispense labels up to a high speed range. While WIPE‑ON mode is running. The DELAY and the SPEED can be adjusted with the M188 terminal.
Page 61: Operational Modes - Tamp-On, Blow-On, Tamp-Blow
Chapter 5 Operator Interface How the adjust keys work: MOMENTARILY Push the adjust + or ‑ key momentarily advances the selected parameter by one increment. HOLD Push and hold the adjust + or ‑ key advances the selected param‑ eter slowly. HOLD 5 seconds Push and hold the adjust + or ‑ key for 5 seconds will advance the selected parameter fast. Note: It is recommended to set the delay in the parameter menu first as close as possible to the desired position. Especially when there is a high encoder line count the change of the label position on the product is minimal for a single encoder increment and it will take a long time to adjust the label position.
Page 62: Operator Screens
L500A V2 High Speed Labeler Manual Operator Screens Starting the Labeler When the operator starts the labeler, the first screen is the Parameter Access Screen which requires the operator to enter a password to ac‑ cess the other screens to operator the labeler. Use function keys below the message (q p + ‑ 8 ) to enter the password [default=00000].
Page 63: Parameter Menu - Wipe
Chapter 5 Operator Interface Parameter Menu - Wipe START DELAY PARAMETER - WIPE The Start Delay parameter is used to adjust position of the label on the START DELAY +00000 [Increm] product. SCRUP SCRDN -EXIT ENTER Asynchronous Mode: Value is a time‑delay. Increase value to position label closer to trailing edge of product.
Page 64 L500A V2 High Speed Labeler Manual STOP DISTANCE The Stop Distance parameter defines the position of the labels at the PARAMETER - WIPE peeler plate. It references the position from which each dispensing cycle STOP DISTANCE +00000 [Steps] is started.
Page 65 Chapter 5 Operator Interface START COMPENSATION The Start Compensation distance is the offset of the label position at the PARAMETER - WIPE maximum synchronous dispensing speed (see above). Without the use of START COMPENSATION [Increm] the controller, internal compensation routines the label placement varies with dispensing speeds.
Page 66 L500A V2 High Speed Labeler Manual STOP COMPENSATION The Stop Compensation sets up the maximum and minimum labeler PARAMETER - WIPE speed and measures the label flag change with respect to the peeler tip. STOP COMPENSATION [Steps] This value compensates for the reaction time of the label sensor and the controller input. -EXIT...
Page 67 Chapter 5 Operator Interface ASYNCHRONOUS SPEED Asynchronous speed is the speed at which the label dispenses from the PARAMETER - WIPE peeler tip. This speed is typically set to the product line speed. ASYNCHRONOUS SPEED +1000 [Hz] Min Value: 1 (Hz); Max Value: 20000 (Hz) SCRUP SCRDN -EXIT ENTER...
Page 68 L500A V2 High Speed Labeler Manual AUTO CENTER Auto Center enables the “AUTO‑TEACH” function of the system. PARAMETER - WIPE AUTO CENTER [ms] Setting: 0 = Auto Teach is NOT enabled. Setting: 1 = Auto Teach IS enabled. SCRUP SCRDN...
Page 69: Parameter Menu - Tamp
Chapter 5 Operator Interface RATIO ADJUST The Ratio Adjust is used to override the gear factor set by the gear nu‑ PARAMETER - WIPE merator and gear denominator (thereby overriding encoder values). It RATIO ADJUST +100 only works in synchronous dispensing mode. SCRUP SCRDN -EXIT ENTER...
Page 70 L500A V2 High Speed Labeler Manual VACUUM DELAY The Vacuum Delay is the amount of time once the tamp home sensor PARAMETER - TAMP goes "high" that the vacuum turns off. VACUUM DELAY +00000 [ms] Larger number to turn the vacuum off later.
Page 71: Parameter Menu - Blow
Chapter 5 Operator Interface AIR ASSIST DWELL Used to help push the label further onto the tamp pad. PARAMETER - TAMP AIR ASSIST DWELL +00000 [ms] Larger number to keep the air assist valve activated for more time. Smaller number to keep the air assist valve activated for less time. SCRUP SCRDN -EXIT ENTER...
Page 72 L500A V2 High Speed Labeler Manual VACUUM DELAY Delays activation of the vacuum that pulls the label onto the blow as‑ PARAMETER - TAMP sembly. VACUUM DELAY +00000 [ms] Larger number to turn the vacuum on later. SCRUP SCRDN -EXIT ENTER Smaller number to turn the vacuum on earlier.
Page 73: Parameter Menu - Jog
Chapter 5 Operator Interface AIR ASSIST DWELL Used to help push the label further onto the blow assembly. PARAMETER - TAMP AIR ASSIST DWELL +00000 [ms] Larger number to keep the air assist valve activated for more time. Smaller number to keep the air assist valve activated for less time. SCRUP SCRDN -EXIT ENTER...
Page 74: Parameter Menu - Setup
L500A V2 High Speed Labeler Manual Parameter Menu - Setup GEAR NUMERATOR This is the factory default value established from the size of the drive PARAMETER - SETUP roller and gearing of the labeler. GEAR NUMERATOR +00000 [select] Min Value: 1; Max Value: 99999...
Page 75 Chapter 5 Operator Interface LABEL PITCH The label pitch is the sum of the label length and the gap between the PARAMETER - SETUP label and the next label. The pitch can be entered as a parameter. LABEL PITCH +00000 [steps] This can also be done using the LABEL‑TEACH programming which -DIGIT ENTER...
Page 76 L500A V2 High Speed Labeler Manual LABEL SENSOR EDGE Toggles between Lead and Trail detection on the label sensor. PARAMETER - SETUP LABEL SENSOR EDGE +1 [select] (0) – Trail (1) – Lead (Default) DOWN +DIGIT -DIGIT ENTER Trail – Detects trailing edge of the label. Lead – Detects leading edge of the label. Min Value: 0 (select); Max Value: 1 (select)
Page 77 Chapter 5 Operator Interface MAX. MISSING LABELS Defines how many consecutive missing labels (on the web, or media) PARAMETER - SETUP that can occur before the controller will show a label error situation. MAX. MISSING LABELS +00000 [select] Min Value: 0 (select); Max Value: 99999 (select) SCRUP SCRDN -EXIT ENTER Default value: 0 AUTO WEB ADVANCE Sets the number of labels from the peeler plate to the sensor (not includ‑...
Page 78: Diagnostics
L500A V2 High Speed Labeler Manual TIMER 1 This parameter helps to solve the problem of over‑torquing the motor. PARAMETER - SETUP Set the value to allow the motor to come to rest before “ramping up” to TIMER 1 [ms] advance web if there is more than one consecutive missing label.
Page 79: Program Number
Chapter 5 Operator Interface Sensor Test In the DIAGNOSTICS screen the condition of the label and product sensor can be monitored. The DIAGNOSTICS screen displays TRUE if 24 VDC is active at the product or label sensor input and FALSE if the input is at 0 VDC level.
Page 80 L500A V2 High Speed Labeler Manual Notes...
Page 81: Preventive Maintenance
Maintenance & Troubleshooting Preventive Maintenance The following are guidelines for preventative maintenance on the applica‑ tor. This information can be used for producing a maintenance schedule, which should be performed routinely. Once familiar with the unit, opera‑ tors or technicians may add additional items to the list. If there are any service questions, please contact your distributor.
Page 82: Troubleshooting
L500A V2 High Speed Labeler Manual Troubleshooting Drive Errors Drive errors, or “fatal errors” that stop each action immediately and in‑ volve the stepper motor. If a “fatal error” occurs, your current label may not be applied properly. Stepper driver errors can be: over‑temperatures (of motor or power am‑...
Page 83 Chapter 6 Maintenance & Troubleshooting Motor Rotation Positive motor direction is defined as the direction on which the label web is moved forward towards the peeler plate. How to Check the Motor Rotation: Step 1. Make sure adequate jog speeds are set in the parameters. Recommended are 100 Hz for the slow speed and 1000 Hz for the high speed. Step 2.
Page 84 L500A V2 High Speed Labeler Manual Notes...
Page 85 FAX at the numbers listed below. Or, contact our Spare Parts Coordinator at our address. Email: spares@ShibuyaHoppmann.com Telephone: (540) 829‑2564 Fax: (540) 829‑1726 Shibuya Hoppmann Corporation Attn: Spare Parts Coordinator 13129 Airpark Drive, Suite 120 Elkwood, Virginia 22718 USA www.shibuyahoppmann.com...
Page 86 L500A V2 High Speed Labeler Manual L500A V2 Label Head Spares Part Number Description Quantity L030120106 Stepper Motor L020100001 Bearing Ball, 3/8”IDx7/8”ODx9/32” L020800505 Spring Collar, 1” BELTV1UK50 Timing Belt, Kevlar, 1/2”wide L030340102 Brake Armature BUMPRUB002 Rubber Bumper Tapered BUSHFB1012 Bearing, Flange TORQPOLY03 Slip Clutch 2-disc, 5/8”...
Page 87 L050490011 Drive Roller, 4” L050601703 Standoff Sleeve, 4” L050601330 2” Idler Roller Modified L500A V2 4" Head Spares (Head #2 - 4) Part Number Description MH0202826 Peeler Plate, Head 2&3 (Format 1 & 2) MH0202827 Peeler Plate, Head 2&3 (Format 3 & 4) MH0202828 Peeler Plate, Head 4 (Format 1 &...
