Rola 59516 Instruction Manual

Led light kit
Hide thumbs
1
2
3

Advertisement

Table of Contents

These instructions contain IMPORTANT safety information. Please read and keep for future reference.
The user must read and understand these Instruction Sheets and the Warranty.
Installation is the end user's responsibility and beyond Horizon Global's control. Therefore, Horizon Global exclusively limits its Warranty to the
repair or replacement of a defective product. Damage to your vehicle, your cargo or any person or property is excluded.
•
All connections must be complete to function properly. Test and verify installation with a test light circuit tester or trailer once installed.
•
Overloading circuit can cause fires.
•
DO NOT exceed lower of towing manufacturer rating or: Max. Right Turn, Stop and Tail Light Circuits: (7.5 amps).
•
Read vehicle's owner's manual and instruction sheet for additional information. Additional fusing may be required.
NOTE: 4-flat adapter may be required for some vehicles.
INSTRUCTION GUIDE FOR:
LED LIGHT KIT
59516
WARNING
Review all Warnings, Instructions, and Warranty information carefully.
Failure to follow these warnings and instructions will void the
Warranty.
PAGE 1
PAGE 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 59516 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rola 59516

  • Page 1 INSTRUCTION GUIDE FOR: LED LIGHT KIT 59516 These instructions contain IMPORTANT safety information. Please read and keep for future reference. WARNING The user must read and understand these Instruction Sheets and the Warranty. Installation is the end user’s responsibility and beyond Horizon Global’s control. Therefore, Horizon Global exclusively limits its Warranty to the repair or replacement of a defective product.

  • Page 2: Parts List

    WIRING INSTALLATION INSTRUCTIONS PARTS LIST Standard 4-Way Flat Grommets Waterproof LED Lights Wiring Harness 6- 8½” Cable Ties 3- 14½” Cable Ties 3 Prong Wiring Pigtails 1. Place grommets into opening on rear of cargo tray on each side. 2. Check to make sure the grommet is seated correctly from the inside of the cargo tray.
  • Page 3 WIRING INSTALLATION INSTRUCTIONS 4. Route the 3-way plug labeled “left” from under the cargo tray, and up through the steel mesh directly behind the tail lamp housing on the driver side of the cargo tray. 5. Plug the harness into the back of the tail lamp housing. 6.
