Aegisound Argonaut User Manual

Communication earplugs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
Argonaut
Communication
Earplugs
PIN 05-016017
INSIDE:
Overview . . . . . . . . . . . . . 2
Before Usage . . . . . . . . . 2
Attaching Eartips . . . . . . . 4
Fitting Earplugs . . . . . . . . 5
Cable Routing . . . . . . . . . 6
Fitting Headset . . . . . . . . 7
CE Marking . . . . . . . . . . . 8
Storage & Maintenance 9
Replacement Parts . . . . . 9
Warning . . . . . . . . . . . . . . 10
Caution . . . . . . . . . . . . . . 11
Contact . . . . . . . . . . . . . . 12
T H E S O U N D O F S A F E T Y
®
EN 352

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Argonaut and is the answer not in the manual?

Questions and answers

Related Manuals for Aegisound Argonaut

Summary of Contents for Aegisound Argonaut

  • Page 1: Table Of Contents

    T H E S O U N D O F S A F E T Y USER MANUAL Argonaut ® Communication Earplugs PIN 05-016017 INSIDE: Overview . . . . . . . . . . . . . 2 Before Usage .

  • Page 2: Overview

    The Aegisound Argonaut Communication Earplugs (ACE) are used with Aegisound’s Argonaut DHPC headset, providing incoming communciations to the ear. The Argonaut Communication Earplugs are also compatible with Aegisound’s DANR THPC headset but do not provide active noise reduction functionality when used with the DANR headset.

  • Page 3: Connecting Earplugs

    Connecting ACE to Headset Rotate the earcup to gain access to the earplug receptacle. Grasp the earplug connector and insert the connector into either earcup by aligning the red dot on the connector with the red dot on the receptacle. Gently press the connector until it snaps in place.

  • Page 4: Attaching Eartips

    LPCCE User Manual for more detailed instructions for Gentex’s compatible custom molded earplug products. • Generic foam tips for the Argonaut Communication Earplug (ACE) come in two different sizes: standard and slim • Standard foam tips fit most individuals •...

  • Page 5: Fitting Earplugs

    Fitting Earplugs See the LPCCE User Manual for more detailed earplug fitting instructions. The instructions below apply to foam eartips. Using the thumb and index finger, roll the foam tip into the narrowest possible crease-free cylinder Reach over your head with your free hand, pull your ear up and back, and before it expands, insert the compressed foam tip into your ear canal...

  • Page 6: Cable Routing

    Cable Routing The earplug cable can be oriented straight down or over the ear, depending upon the user’s preference. ARGONAUT COMMUNICATION EARPLUGS ®...

  • Page 7: Fitting Headset

    Fitting Headset Position the headset so that the microphone is on the left side Insert the right earplug into the right ear (Orientation not critical when using Generic Foam Earplugs) Insert the left earplug into the left ear Place the headset on the head Place the headset comfortably over the ears, ensuring that the outer ear is completely seated in the earcups.

  • Page 8: Ce Marking

    40 .9 38 .4 38 .4 45 .9 40 .8 SNR=41 dB H=40 dB M=39 dB L=37 dB CE Attenuation Argonaut/DANR Earmuff with Argonaut Communication Earplugs and Comply Foam Earplugs Attenuation values to EN 24869-1 Frequency (Hz) 1000 2000 4000...

  • Page 9: Replacement Parts

    Cleaning and Storage The Argonaut Communication Earplugs should be cleaned periodically with warm, soapy water and/or wiped with alcohol to prevent buildup of dirt and to disinfect. Reference the LPCCE User Manuals for custom earplug maintenance. Foam eartips should be disposed of and replaced once they become soiled. The ACEs should be stored in the protective case used for the headset.

  • Page 10: Warning

    The protection afforded by the earplugs will be severely impaired if: • The earplugs are not fitted and maintained in accordance with the manufacturer’s instructions • The earplugs are not regularly inspected for serviceability • The earplugs are not worn at all times in noisy surroundings ARGONAUT COMMUNICATION EARPLUGS ®...

  • Page 11: Caution

    Caution Inserting or removing the earplugs too quickly may result in air pressure or suction against the eardrum causing temporary pain. The earplugs should be inserted or removed slowly with a twisting motion to prevent excess pressure buildup. Gently moving the earplug while opening the jaw fully may remove excess pressure buildup.

  • Page 12: Contact

    Gentex Corporation 645 Harvey Road, Suite 102 (603) 657-1200 Manchester, NH 03103 USA sales@gentexcorp.com M A D E I N T H E U S A ARGONAUT COMMUNICATION EARPLUGS ®...
