SONIQ MB101K User Manual

Mini Bluetooth Speaker
Accessories
(1) Users' Manual: 1 piece
(2) Micro USB Line: 1 piece
(3) Warranty Card: 1 piece
Location of control
1
USB
LINE IN LINE OUT
POWER
ON OFF
2 3 4
1. CHARGE JACK(MINI USB JACK)
2. POWER OFF/ON SWITCH
3. LINE IN JACK(3.5MM JACK)
4. LINE OUT JACK(3.5MM JACK)
5. VOLUME UP(+) BUTTON
6. BUTTON
7. VOLUME DOWN(-) BUTTON
8. BUTTON
9. PLAY/PAUSE/PAIR(
10. RED & BLUE LED INDICATOR
Charging Instructions
This unit operated on the built-in Lithium-Ion battery
that can be recharged either using the USB port on your
computer or from a USB power adaptor (not included)
with a rated output of DC5V, 500mA and up.
HOTLINE: ● SINGAPORE: 65-64510221
10 5
9
V OL+
6
8
V OL -
7
) BUTTON
Note: The mini USB Charging Jack located on the unit is
only designed for charging the built-in Lithium-Ion
battery.
Charging the battery for first time
(1) Charge the built-in Lithium-Ion battery a minimum
of 3 hours prior to first use.
Plug the unit into the USB port on your computer or
into a USB power adaptor (not included) using the
includes USB cable.
(2) The charging LED indicator will turn red while
charging and turn off when the unit is fully charged.
Unplug the USB cable from the power source once
the battery is fully charged.
Recharge the internal battery
After prolonged use, the internal battery will become
weak and the operation may become intermittent. When
the internal battery charge is very low, a melody will
play alerting you to recharge the internal battery as
soon as possible.
Note:
1. Charging time will vary if you are listening to music
while charging the internal battery. We recommend
you switch off the speaker power during the charging
process.
2. Rechargeable batteries need to be cycled for
maximum performance and longer battery life.
3. To prolong the life of a rechargeable battery, it is
recommended to completely discharge it before fully
charging it again.
Note: The speaker is not magnetically shielded and may
cause colour distortion on the screen of some TVs
or video monitor. To avoid this, you may need to
move the unit further away from the TV or
monitor if any unnatural colour shifts or image
distortion occurs.
www.soniq.com
