Security Instructions
Read the instructions very carefully before the first
use and keep it for next uses.
Any use not in accordance with the instructions will
free the manufacturer from any responsibility.
The PerfectDry Lux® must be used by a person with full
intellectual capacities. No other restriction applies to
the user.
Keep out of reach of children.
Any intervention, other than usual cleaning and
maintenance from the user, must be operated by the
Aftersales Service or a professional.
Never put your PerfectDry Lux®, power supply or cable
under water or any other liquid. If the power plug or the
cable are damaged, do not use the device. Replace your
power supply with an original one. Never use detergent
or corrosive product to clean your PerfectDry Lux®.
Warning : Any use not in accordance with these
instructions will cancel the warranty.
The manufacturer cannot be held responsible for
damages caused by a misuse or bad manipulation of
the product.
Description
The PerfectDry Lux® is an electronic device for the
maintenance and the storage of all kind of hearing aids.
This maintenance is ensured by the combination of a
forced-air fan drying system and UV-C rays disinfection.
Note:
- The UV-C lamp is a surface disinfectant and it has few
or no penetrating qualities, which means it cannot
damage the earmold or plastics of the hearing aids.
UV-C disinfection
The PerfectDry Lux® is equipped with a short emitting
waves UV-C lamp, whose 360° circular disposition
enables to reach all the surfaces of the hearing aids.
The exposition of surfaces to the UV-C light allows to
destroy 99% of fungi and bacteria, and dramatically
reduces itchiness and infections of the ear canal.
The lamp will turn itself on during the first five minutes
of the drying cycle, then turn itself off automatically.
Dehumidification - Drying
The PerfectDry Lux® is equipped with a forced-air fan
drying system, which enables to reduce the power and
time necessary for the drying cycle.
The temperature of the drying chamber is controlled
by an electronic system in order to maintain a
constant temperature of 45°C, whatever the ambient
temperature surrounding the device, and to prevent
the hearing aids from any damages.
Technical data
Features
- External dimensions l x h x p (mm): 92 x 48 x 75
- Internal dimensions l x h x p (mm): 70 x 21 x 51
- Weight (g): 160
- Power supply: 5Vdc / 0,5A
- Maximum power: 2.5W
- Stand by power: <0.02W
- UV-C wavelength: 253.7nm
- Acoustic Level <20 dBA
- Drying temperature: 45°C +/-3
- Operating temperatures: from 12° to 40°C
- Storage conditions: from -20° to 65°C
- Software Version 01.00
- USB cable length: 1.5m
Power connector
- Input: 100-247Vac - 50-60Hz - 0.15A
- Output: 5Vdc / 1A
Guarantee
PerfectDry Lux® is guaranteed for 36 months, except for
the power supply (24 months), from the date of purchase.
For any failure or breakdown, contact your hearing aid
specialist. A purchase proof will be asked from Aftersales
Service during the guarantee period. This guarantee will
not be valid for any use not in accordance with these
Identifying information
You will find the data sheet under your
PerfectDry Lux®.
Abbreviation signification:
V
Volts (Power supply tension)
A
Ampère (Energy consumption)
USB power symbol
Inside use
This product is an ABS production recycled to 7%
This product complies with the applicable
European directives.
ELIMINATION
Throw the old material out in an ecological way.
The old devices are made with recycling material
which must be recycled. Be careful to throw your old
devices out in the right recycling system.
instructions, for an accident, a liquid introduction, a
negligence, a maintenance lack or any other circumstance
caused by the user. Furthermore the guarantee will not be
valid for any problem caused by lightnings or a variation in
the electrical voltage. As a precaution we recommend to
unplug the device in case of storms.
PerfectDry Lux
®
UV-C disinfection
and quick dehumidification
of hearing aids
This box set includes:
- 1 PerfectDry Lux®
- 1 USB cable
- 1 Power connector
- 1 User manual
