operating instructions
03.210
This product is made for inner room air circulation in conformity to the
current CE rules:
- EN 60335-1:2002+A1+A11+A12+A2+A13+A14
- EN 60335-2-80:2003+A1+A2
- EN 61233:2008
- Additional examination GPSG
IMPORTANT:
Do not use this fan for other applications without our agree-
ment.
Read and follow these instructions carefully to prevent per-
sonal injury and property damage. Keep always this instruc-
tion booklet
© Copyright
All Rights Reserved
Industrial ceiling fan 03.210 - 03.215
Installation and
Manual-03210-Eng-R(15) - 2013/10
Advertisement
Table of Contents
Summary of Contents for Winterwarm 03.210
-
Page 1: Operating Instructions
Industrial ceiling fan 03.210 - 03.215 Installation and operating instructions 03.210 This product is made for inner room air circulation in conformity to the current CE rules: - EN 60335-1:2002+A1+A11+A12+A2+A13+A14 - EN 60335-2-80:2003+A1+A2 - EN 61233:2008 - Additional examination GPSG... -
Page 2: Table Of Contents
Industrial ceiling fan 03.210 - 03.215 Index Installation safety - must be followed........1 Operational safety - must be followed........2 Contents of the package............2 Mount of the ceiling j-hook........... 2 Mount of the blades..............3 Hang the fan and connect wiring..........3 Mount of the safety wire............ -
Page 3: Installation Safety - Must Be Followed
Installation safety - must be followed 1. Choise of placement: • The ceiling structure must be able to support at least 50kg/m² moving weight. • Choose a place where there is no risk for people or objects to contact with rotating blades. •... -
Page 4: Operational Safety - Must Be Followed
Operational safety - must be followed 1. Do not work near a running fan. Turn power off before. 2. Do not bend the blades and do not push any object between the running bla- des. Never stop the blades with hands. 3. -
Page 5: Mount Of The Blades
Mount of the blades - Use a soft underlay to place the motor for assembling with blades. - The blades are assorted by weight to prevent wobbling. Do not exchange blades from one set to another. - Mount the three fan blades (blade holder upside) to the motor using the blade screws, spring rings, washers and blade holder underlay cards, same as the dra- wing. -
Page 6: Mount Of The Safety Wire
Mount of the safety wire - Choose a screw or a screw eye, suitable for the safety wire and the kind of ceiling. - Fix the safety wire with the screw or the screw eye to the ceiling, 10cm besi- de the upper canopy. -
Page 7: Troubleshooting
Troubleshooting URGENT: Before checking the fan, make sure power is off at the main service panel. Tag it to prevent unexpected power on. - The motor housing must not be opened. Fan will not start. Suggested remedy - Check main and branch circuit fuses or circuit breakers. - Check line wire connections to fan and switch wire connections in switch housing. -
Page 8: Specifications
Specifications Model 03.210 03.211 03.214 03.215 Color white black white white Voltage 230 V, 50 Hz Power 75 W Max. current 0,35 A Speed 300 rpm 15.000 m 3 /h Air Volume Performace max. 10 m 10 m 10 m...
