Roominator Performance Series
EACH KIT INCLUDES:
Project ➋
(24) 2'x2'x2" Studiofoam
(8) LENRD
Bass Traps
®
(144) EZ-Stick Pro
INSTALLATION:
Studiofoam Wedge, LENRD Bass Traps and T'Fusor Diffusors can be
mounted to standard drywall with the included EZ-Stick Pro Tabs. Be advised
that the EZ-Stick Pro Tabs are designed for permanent installations and will
damage drywall and painted surfaces when removed.
Mark the target position on your wall or ceiling where the product will be
mounted using small pencil marks, pieces of masking tape or any similar
non marring method. Be sure the surface where the EZ-Stick Pro Tabs will
adhere is free of dirt, dust or other oily contaminants by spot cleaning with
rubbing alcohol.
Each Studiofoam Wedge panel and T'Fusor Diffusor use 4 EZ-Stick Pro
Tabs, each LENRD Bass Trap uses 6 tabs.
Remove one of the release layers on the EZ-Stick Pro Tabs and affix it to the
rear side of the Studiofoam Wedge perimeter, usually near the corners. On
LENRDs, place the tabs along the thin edge as shown below. For all Studiofoam
products, apply very firm pressure for 30 seconds in order to ensure the
EZ-Stick Pro Tabs properly adhere to the Studiofoam. Not using adequate
pressure will cause the EZ-Stick Pro Tabs to fail.
Remove the second layer of the release paper from each of the EZ-Stick Pro
Tabs, carefully orient the panels position prior to contact with the wall, then
press in place with firm pressure for 30 seconds.
STUDIOFOAM
WEDGE
®
™
(24) 2'x2'x2" Studiofoam
Wedge
®
Tabs
™
Auralex
1-800-959-3343 / 317-842-2600 / Auralex.com
9955 Westpoint Drive, Suite 101, Indianapolis IN USA 46256
™
USER GUIDE
Deluxe Plus
™
Wedge
®
(8) LENRD
Bass Traps
®
(6) T'Fusor
Diffusors
™
(168) EZ-Stick Pro
Tabs
™
T'FUSOR
™
Acoustics, Inc.
®
Pro Plus
(36) 2'x2'x2" Studiofoam
(12) LENRD
®
(8) T'Fusor
™
(248) EZ-Stick Pro
INITIAL APPLICATION (Without Applying Firm Pressure)
FINAL APPLICATION AFTER APPLYING FIRM PRESSURE
EZ-STICK PRO
™
LENRD
®
(EZ-Stick Pro Tab Placement)
LENRD
BASS TRAP
®
™
Wedge
®
Bass Traps
Diffusors
Tabs
™
ADHESIVE
ADHESIVE
