Sper scientific 800013 Instruction Manual

Datalogging rh / temperature pen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Datalogging
RH / Temperature Pen
800013
Instruction Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 800013 and is the answer not in the manual?

Questions and answers

Related Manuals for Sper scientific 800013

Summary of Contents for Sper scientific 800013

  • Page 1 Datalogging RH / Temperature Pen 800013 Instruction Manual...
  • Page 2 Datalogging RH / Temperature Pen 800013 Copyright ©2014 by Sper Scientific ALL RIGHTS RESERVED Printed in the USA The contents of this manual may not be reproduced or transmitted in any form or by any means electronic, mechanical, or other means that do not yet exist or may...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ....4 2. MATERIALS SUPPLIED ... . . 4 3.

  • Page 4: Introduction

    INTRODUCTION This Sper Scientific RH/Temperature Datalogger Pen 800013 is an extremely fast and accurate meter with multiple functions. The meter reads and records relative humidity, air temperature, dew point, and wet bulb. The datalogger records up to 32,000 data points which can be downloaded by plugging the pen directly into a USB port.

  • Page 5: Features

    FEATURES • Displays current readings of RH & Temperature, can be programmed to log date, time, humidity, air temperature, dew point, and wet bulb readings. • Highly accurate microcomputer circuit • Direct upload of data to Excel • Manual datalogger option •...

  • Page 6: Meter Components

    METER COMPONENTS 3a. 3b. 4. 1. Sensor 2. LCD Display 3. LED Indicators a. Green LED flashing: Logging is in progress b. Red LED flashing: Reading exceeds Hi/Lo alarm threshold 4. Power Button / Key Start 5. Battery Compartment 6. USB Drive 7.

  • Page 7: Wrist Strap Installation

    WRIST STRAP INSTALLATION 1. Grasp the thinner thread loop attached to the wrist strap so that your thumb and forefinger press the end of the loop flat. 2. Guide the closed loop into the small receptacle on the underside of the datalogger pen near the USB.

  • Page 8: Software Installation

    You can download the software that came with your meter directly. Go to the www.sperdirect.com/software. htm and find your meter or search for you meter (800013) and download from product page. Installing the Software Package 1. Open the Downloaded software file.

  • Page 9: Running The Software

    RUNNING THE SOFTWARE 1. Insert the USB drive into the USB port. 2. Open the Start Menu and select the “Data Logger” Icon from the programs list. 3. The USB Data Logger Monitor screen displays. Note… If the datalogger is not plugged into the USB port, an error message will appear.

  • Page 10: Datalogger Settings

    DATALOGGER SETTINGS NOTE: To Access Setting Options: If software message box show as pic2.Follow the next s Select “Setting” from the header options on the upper 1.click “My computer””Content” in hardware content,c left-hand side of the USB Data Logger Monitor screen. find the listed (COMx) listed under Ports(COM &...
  • Page 11 Troubleshooting the Communication Port Setting If the software does not recognize that the logger is plugged into the USB port you should verify that the communications port number is correct. Note… The port information is found on the computer under “Device Manager.”...

  • Page 12: Basic Logger Setting

    Basic Logger Setting The basic menu allows you to designate a name for your logger and specify the current date and time. Logger Setting 1. Select “Log Setting” from the BASIC etting options. The Logger 1:ID s Setting menu appears. Maxim 2.

  • Page 13: Logger Sampling Setting

    Logger Settin 3. Use the mouse to select the alarms you want to set. 1:ID Once you have selected the desired alarm(s), specify the desired values using the ▲ or ▼ indicators. to c 4. Select the parameters you wish to record. The meter can take readings for temperature, humidity, dew point, and wet bulb.

  • Page 14: Setting Start Modes

    Setting Immediate Start Mode This option will cause the meter to begin taking readings as soon as the option is confirmed. Reading will continue if the meter is detached from the USB port. SETT 1. Adjust the ▲ or ▼ indicators 1: Se to specify the number of sample points, in thousands,...
  • Page 15 Setting Real-Time Start Mode This option is used with the datalogger connected to the computer, through the USB port. Note… The meter may not be disconnected from the computer during real-time sampling. 1. Adjust the ▲ or ▼ indicators to specify the number of sample points, in thousands, from 1000 to 32,000.
  • Page 16 Setting Roll Over Mode This option allows for continued recording even when the meter is full. After the data limit has been reached, new readings will be recorded over the earliest previous records. 1. Adjust the ▲ or ▼ indicators to specify the number of sample points, in thousands, from 1000 to 32,000.

  • Page 17: Data Sampling And Recording

    3. The fields for the start date and time and the stop date and time will be automatically populated with default values. Click on any of these fields and use the computer keyboard to make changes as desired. 4. Select “Ok” to save the settings and exit the menu, or “Cancel”...
  • Page 18 Real-time (PC is always connected  Key start (Start recording by pres  Roll-over (when memory are full,  Sampling and Recording in Real-Time Mode earliest memory automatically) 1. Recording will begin automatically as soon as the setting is 3.Select Unit : Select Temperature u (Pic.5) confirmed.
  • Page 19 Sampling and Recording in Roll Over Mode 1. The green LED will flash to indicate that the logger is recording data. 2. Remove the datalogger from the computer as desired. Recording will continue. 3. The datalogger will record up to 32,000 data points. When the memory is full, the meter will continue recording over the oldest records.

  • Page 20: Downloading Data

    Select the mode to record when the data is full, it will c After download the data , long press grey button to rec parameter and selection. DOWNLOADING DATA 1. If the datalogger is not currently connected to the LOGGER Status: computer, insert the USB drive into the USB port.
  • Page 21 • To read each measurement: Use the left and right arrow keys. • To reset the size of the graph to the default: 1. Click on the colored bar to the left of one of the data parameters under the graph (Temp., Humidity, Dew Point, or Wet Bulb).

  • Page 22: Battery Replacement

    Saving the Data 1. Click the Save button (floppy disc icon) to save the data. 2. Enter a unique name for the file. 3. Click “OK” to confirm. Retrieving Stored Files 1. Click the “File” button (open folder icon). 2. Select the file you want to open. 3.

  • Page 23: Specifications

    SPECIFICATIONS Range Resolution Accuracy Temp -40 to 85°C 0.1 °C&°F ±0.6°C / 0.9°F -40 to 185°F (-20 to 50°C) otherwise ±1.2°C, ±2°F 0.1 to 99.9% 0.1% ±3% (@25°C & 10 to 99% RH) otherwise ±5% Display Type Sampling Interval 1 second to 6 hours Measurement Units °C &...

  • Page 24: Warranty

    WARRANTY Sper Scientific warrants this product against defects in materials and workmanship for a period of five (5) years from the date of purchase, and agrees to repair or replace any defective unit without charge. If your model has since been discontinued, an equivalent Sper Scientific product will be substituted if available.
