TV Stand
INSTALLATION GUIDE
Congratulations
on the purchase of your new Serano TV Stand. Before commencing assembly,
please check that you have all the parts and familarise yourself with this Installation Guide. Should
any of the parts on the Speci ed Part List be missing, please contact the below Help Line number or
email address (Available to UK customers only).
44207 147 4871(UK)
2 people required to lift the unit during assembly.
ATTENTION:
• Only use this product when full assembled. If any part is missing or damaged stop the assembly and contact the
helpline.
• Do not place very hot or very cold items on the glass surface unless adequately thick tablemats are used to prevent
such items from coming into contact with the glass.
• Do not sit or stand upon the glass surface.
• Do not strike the glass with hard or pointed items.
• When cleaning glass panels use a damp cloth or leather with washing liquid or soft soap. Do not use washing powder
or any other substances containing abrasives since these substances scratch glass.
1
4
L
PARTS LIST
S105BG09
S105CG09
75
MAXIMUM
Kg
LOAD
2
M
5
M4 (x1)
J
M6/L28mm (x2)
K
(x8)
L
M6/L25mm (x2)
M
Use the ruler to help identify parts.
3
6
H
50
40
30
20
10
0
(mm)
H
H
H
