MODEL PA1FS
FLOOR SCRAPER
OWNER'S/OPERATOR'S MANUAL
SERIAL
NUMBER -
You should record the Serial Number of your Floor Scraper on this
Owner's/Operator's Manual and on the Warranty Card. The Warranty
Card must be sent back with all the required pertinent information for
the warranty to take effect.
Caution!
Read Safety and General Instructions carefully before using saw for the first time.
REV. 1
Made in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA1FS and is the answer not in the manual?

Questions and answers

Related Manuals for Pearl PA1FS

Summary of Contents for Pearl PA1FS

  • Page 1 MODEL PA1FS FLOOR SCRAPER OWNER'S/OPERATOR'S MANUAL SERIAL NUMBER - You should record the Serial Number of your Floor Scraper on this Owner's/Operator's Manual and on the Warranty Card. The Warranty Card must be sent back with all the required pertinent information for the warranty to take effect.
  • Page 2 INTRODUCTION We at PEARL want to congratulate you on selecting the PA1FS Floor Scraper. We are certain that you will be pleased with your purchase. PEARL takes pride in producing the finest products in the industry. Operated correctly, your PA1FS Floor Scraper should provide you with years of quality service. In order to help you, we have included this manual.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SAFETY Page Safety Message/Alert Symbols, Warnings Hazard Symbols General, Maintenance, Saw Safety California proposition 65 Message Electrical Requirements and Grounding Instructions Safety Label Locations OPERATION Wheel and Handle Adjustment and Transportation 11-12 Blade Changing / Installation Blade Usage TYPE OF TEAROUTS Removal Materials Subfloor Surfaces...

  • Page 4: Safety Message/Alert Symbols, Warnings

    This Operation and Parts Manual has been developed to provide complete instructions for the safe and efficient operation of the PA1FS Floor Scraper. Before using this machine, ensure that the person operating the machine has read and understands all instructions in this manual.

  • Page 5: Hazard Symbols

    PA1FS FLOOR SCRAPER SAFETY Potential hazards associated with the PA1FS Floor Scraper operation will be referenced with Hazard Symbols which appear throughout this manual, and will be referenced in conjunction with Safety Mes- sage/Alert Symbols. HAZARD SYMBOLS ALWAYS read this Owner’s Manual before operating the machine.

  • Page 6: General, Maintenance, Saw Safety

    Failure to follow instructions in this manual may lead to serious injury or even death! This equipment is to be operated by trained and qualified personnel only! This equipment is for industrial use only. The following safety guidelines should always be used when operating the PA1FS Floor Scraper. GENERAL SAFETY • DO NOT operate or service this equipment before reading this entire manual.
  • Page 7 • Unauthorized equipment modifications will void all warranties. Manufacturer does not assume respon- sibility for any accident due to equipment modifications. • NEVER use accessories or attachments, which are not recommended by PEARL for this equip- ment. Damage to the equipment and/or injury to user may result.

  • Page 8: California Proposition 65 Message

    PA1FS FLOOR SCRAPER SAFETY SAFETY WARNINGS SILICA DUST WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis.

  • Page 9: Electrical Requirements And Grounding Instructions

    PA1FS FLOOR SCRAPER SAFETY ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS In order to prevent potential electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! WARNING In case of a malfunction or breakdown, grounding provides a path of least resistance for electric cur- rent to reduce the risk of electric shock.

  • Page 10: Safety Label Locations

    Safety labels contain important safety information. Please read the information contained on each safety label. These labels are considered a permanent part of your saw. If a label comes off or becomes hard to read, contact PEARL or your dealer for a replacement. Label C...

  • Page 11: Wheel And Handle Adjustment And Transportation

    PA1FS FLOOR SCRAPER GENERAL OPERATION WARNING Do not operate machine around excessive moisture areas, such as abatement work and flooded pool areas without GFCI wall plug. Failure to do so could cause damage in machine or injury to operator. WHEEL ADJUSTMENT Adjusting the wheel angle will change the blade angle to the floor.
  • Page 12 PA1FS FLOOR SCRAPER GENERAL OPERATION HANDLE ADJUSTMENT AFTER THE PROPER WHEEL ADJUSTMENT IS ACHIEVED, ADJUST THE HANDLE LENGTH Simply loosen the thumbscrews located on the frame and the handle will slide up and down. Locate the most comfortable height and tighten the thumbscrews to lock the handle in place.

  • Page 13: Blade Changing / Installation

    PA1FS FLOOR SCRAPER BLADE INSTALLATION BLADE CHANGING / INSTALLATION CAUTION Blades are sharp. Handle with care. Failure to do so could cause bodily injury. • Dull blades greatly reduce cutting ability. Re-sharpen or replace as needed. • Proper blade size and placement per job type greatly affects performance.

  • Page 14: Blade Usage

    PA1FS FLOOR SCRAPER BLADES BLADE USAGE Start with a narrow blade, then increase blade size to optimize cutting pass. Narrower blades work easier than wider blades and usually clean the floor better. Wider is not always better or faster. Proper blade size and placement, depending on material and sub-floor type, greatly affects performance.

  • Page 15: Removal Materials

    PA1FS FLOOR SCRAPER TYPES OF TEAROUTS REMOVAL MATERIALS Never remove flooring containing asbestos without fully understanding proper WARNING state and federal procedures and guidelines. • Sheet vinyl, solid vinyl, rubber tile, urethane or PVC sheet roofing, will need to be scored for best removal results.

  • Page 16: Subfloor Surfaces

    PA1FS FLOOR SCRAPER TYPES OF TEAROUTS SUBFLOOR SURFACES • WOOD: When working over plywood sub-flooring, try to run machine in the same direction as the grain in the wood. Blade in most cases should be bevel down. On solid wood floors, like plank, run in the same direction as the plank, not cross grain or cross plank.

  • Page 17: Cleaning

    REPAIRS If your tool is damaged, contact PEARL for a return authorization number and return the entire tool. • Shipments are not accepted without a return authorization number. • COD or freight collect shipments will not be accepted.
  • Page 18 PA1FS FLOOR SCRAPER PARTS LIST...
  • Page 19 SCR/CAP HEX .250 - 20 X .625" G5 STL PA 5001730 HANDLE/GRIP 4.5 LONG X 7/8: ID PA004024 PANEL/ELEC. CONTROL - PA1FS 120V/60HZ PA004942 PLATE, SWITCH COVER PLATE / PA1FS PA-10544 ECCENTRIC / PA1FS PA 06-550-101 PLATE/SERIAL-NUMBER USF/SAWTEC PA 05-55501...
  • Page 20 PA1FS FLOOR SCRAPER PARTS LIST ITEM PART OR QTY. DESCRIPTION IDENTIFYING NO. REQ. VINYL COATED LOOP STRAP FOR 1/2" OD PA800756 MANUAL-PA1FS PA167790 30L X 16W X 19.5H DBL WALL W/HANDLES SHIPPING BOX PA-10122 TUBE/MANUAL PA003235 BOTTOM COVER / PA1FS PA-10599...

  • Page 21: Ordering Information

    • The Part Description for the part(s) being ordered NOTE: There is a $25.00 minimum order when ordering direct from PEARL. A $5.00 charge will be added to orders having a net billing value under $50.00. All purchases must be made using VISA, MasterCard or American Express.

  • Page 22: Contact& Limited Warranty

    The parts involved or the unit in question should be returned to PEARL or to a point designated by us, transportation prepaid.
  • Page 23 NOTES...
  • Page 24 6210 SOUTH GARFIELD AVENUE, COMMERCE, CA 90040-0031 TEL 562-927-5561 • FAX 562-928-3857 800-969-5561 www.pearlabrasive.com GEORGIA • USA ONTARIO • CANADA 4963 SOUTH ROYAL ATLANTA DRIVE 375 PIDO ROAD TUCKER, GA 30084-3006 PETERBOROUGH, ONTARIO K9J-6X7 ©2012 PEARL ABRASIVE CO., COMMERCE CA 90040 PA1FSMANV1...
