Switronix Powerbase 70-GH4 Instruction Manual

1. Using conversion box GP-DV-GH4 the Powerbase 70
can supply 9V for Panasonic GH3/GH4 with a the appropriate
dc pin connection. It can also supply 12V for accessories
through the conversion box PT socket.
2. Included conversion box/cable applicable camera
models:
-Panasonic GH3
-Panasonic GH4
Specifications
Rated Voltage: 14.8V
Rated Capacity: 70Wh
Charge Time: 3~5 hrs
Dimensions: 6.25in x 3.4in x 2in
Weight: 1.5lbs
Four step LED power indication
Switronix, Inc.
87 Garden St
Westbury, NY 11590
Tel: 1-800-613-7948, 516-750-9675
Fax: 516-594-1414
Website: http://www.switronix.com
Powerbase 70-GH4
Instruction Manual
1. Can be used as normal V type brick battery
2. Built-in PT port can supply power for accessories
or charging.
3. Quick release plate can be used to install wireless
reciever, hard drive or other equiptment or to connect
two batteries.
4. Both sides have a 1/4" 20 insert for installing other
equipment
