Onn ONA18AA019 User Manual

Bluetooth Status Light
Volume DOWN Button /
Previous Track (2s)
POWER BUTTON:
Press and hold the button for 2 seconds to turn device ON/OFF.
VOLUME UP +:
Short press (< 0.5s) the button to turn up volume. Press and hold the button (2s) to go to
the next track.
VOLUME DOWN –:
Short press (< 0.5s) the button to turn down volume. Press and hold (2s) the button to go
to the previous track.
INDICATOR LIGHT STATUS:
Power ON – When the speaker is turned on, a solid blue light will appear momentarily.
Bluetooth pairing indicator – When the speaker is turned on, a flashing blue and red light
indicates speaker is ready to pair. Once paired, the light will slowly pulse blue.
Power OFF – When the speaker is turned off, the indicator light will momentarily turn solid
blue, then turn off.
Battery charging – While speaker is charging, the indicator light will turn solid red. Once
speaker is fully charged, the light will turn off.
SPEAKER PAIRING:
To pair the speaker, follow these simple steps:
1. Make sure the smartphone, tablet, or computer you're using with the speaker has
Bluetooth.
2. Turn on the speaker (press and hold the PLAY/PAUSE button for 2 seconds) and look for
the little blinking light.
3. Look for the speaker in your device's Bluetooth list, or click YES. See list below for device
pairing names.
The device and Bluetooth will find each other every time, so long as the speaker is set to
Bluetooth and your device's Bluetooth is on. If you're connecting to a computer, you may
have some extra steps on that end. You'll have to get that information from the computer
company.
DEVICE PAIRING NAMES:
ONA18AA019 (Black): Onn SPKR A019
ONA18AA020 (Pink): Onn SPKR A020
ONA18AA021 (Blue): Onn SPKR A021
Integrated Carry Strap
Play/Pause
On/Off (2s)
Volume UP Button /
Next Track (2s)
Microphone
USB Charging Port
(300mA)
Line In Port
Charging Indicator
Auto off: If the speaker is on but is not connected to Bluetooth, it will shut down after 2
minutes. Once paired, if the speaker is paused for 15 minutes or more, it will automatically
shut down.
INTEGRATED CARRY STRAP:
Integrated carry strap allows you to attach
the speaker to luggage, backpacks, hang in
a shower and more.
DISCONNECTING DEVICE:
Press + and – buttons at the same time for
up to 4 seconds to disconnect the speaker from the device and enter into Pairing mode.
CALL HANDLING:
INCOMING CALL:
Answering and hanging up a call – When speaker is paired to your phone, short press the
PLAY/PAUSE button to answer the call. To hang up, short press the PLAY/PAUSE button.
Move call from speaker to device – If you are on the call and wish to move the call from the
speaker to your device, long press the PLAY/PAUSE button (3s).
Reject an incoming call – To reject an incoming call, long press the PLAY/PAUSE button (3s).
First incoming call
USB CABLE:
25 cm Micro USB cable.
ONA18AA019, ONA18AA020, ONA18AA021
MINI BLUETOOTH® SPEAKER
AUX IN CHARGE
Short Press
Situation
PLAY/PAUSE Button
Pick up call
On call End call
Integrated Carry Strap
Port Cover
Open Close
Long Press
PLAY/PAUSE Button
Reject call
Move call from speaker to device
