Jupiter Creations Flying Eagle 90100 Instruction Manual

Jupiter Creations, Inc.
275 West 96th Street, New York, NY 1002
Email: sales@jupitercreations.com
Website: www.jupitercreations.com
All rights reserved

Key Features

For Flying Eagle Helicopter:
- Extra wide IR control
- Precision design for indoor flying
- Built-in Li-poly battery for long flying time
- Advanced rotor-blade system for ultra control and steady lifting-up
- Impact resistant durable body
- Recharges through transmitter
Safety Precautions
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
- Keep hands, hair and loose clothing away from the propeller when power
switch is turned ON.
- Turn off transmitter and helicopter when not in use.
- Remove battery from transmitter when not in use.
- Parental guidance is recommended for the flight.
- Keep your helicopter in your sight so that you can supervise it all the time.
- New and alkaline batteries are recommended for use in transmitter to obtain
best and maximum performance.
- You are advised to replace with new batteries as soon as the function becomes
impaired.
- Users should keep and retain this information for future reference.
- Users should keep strict accordance with the instruction manual while
operation the product.
- Your Transmitter charger is tailor-made for the Li-Poly rechargeable battery
used in Flying Eagle. - Do not use it to charge any battery other than that in
the helicopter.

FCC Statements

This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this

Care and Maintenance:

- Always remove batteries from the toy when it is not being used for a long
period of time. (Transmitter only)
- Wipe the toy gently with a clean damp cloth.
- Keep the toy away from direct heat.
- Do not submerge the toy into water that can damage the electronic
assemblies.

Battery Cautions:

- Non-rechargeable batteries are not to be recharged.
- Rechargeable batteries are to be removed from the toy before being
charged (Transmitter only).
- Rechargeable batteries are only to be charged by an adult.
- Different types of batteries or new and used batteries are not to be mixed
(Transmitter only).
- Only batteries of the same or equivalent type as recommended are to be used.
- Batteries are to be inserted with correct polarity.
- Exhausted batteries are to be removed from the toy (Transmitter only).
- The supply terminals are not to be short-circuited.
WARNING:
CHOKING HAZARD -
Not for Children under 3 years.
This product is in compliance
with the essential requirements
and other relevant provisions of
Directive 1999/5/EC.
Do not touch the running propeller!
Do not play above someone's head!
Item No.: 90100 Made in China
Adult supervision is required!
For Transmitter:
- Digital control
- Tri-band A, B, C
- Alignment Trim
- Charging/power indicator
Helicopter is equipped with a Li-Poly rechargeable battery,
please also pay attention to the following cautions for safety use:
- Do not dispose the battery in fire or heat.
- Do not use or leave the battery near a heat source such as fire or heater.
- Do not strike or throw the battery against hard surface.
- Do not immerse the battery in water, and keep the battery in a cool dry
environment.
- When recharging, only use the battery charger specifically for that purpose.
- Do not over-discharge the battery.
- Do not connect the battery to an electrical outlet.
- Do not directly solder the battery and pierce the battery with a nail or other
sharp object.
- Do not transport or store the battery together with metal objects such as
necklaces, hairpins etc.
- Do not disassemble or alter the battery.
- Charge the battery every 6 months.
- Turn off your equipment power switch after use.
- As for a used battery, please recycle after covering the battery terminals
with insulation tape or inserting it to an individual poly-bag.
Note:
- Parental guidance is recommended when installing or replacing batteries.
- Under the environment with electrostatic discharge, the sample may
malfunction and require user to reset the sample.
Special Note to Adults:
- Regularly examine for damage to the plug, enclosure and other parts. In the
event of any damage, the toy must not be used with the transmitter
charger until the damage has been repaired.
- This toy is not intended for children under 3 years old.
- This toy must only be used with the recommended charger.
- Do not try to charge other batteries with transmitter Charger.
Battery requirement for Flying Eagle:
Power Supply :
Rating : DC 3.7 V, 1,8 W
Batteries : 1 x 3.7 V Li-Poly Rechargeable Battery Pack
Requires 1 x 3.7 V Li-Poly Rechargeable Battery Pack
(included)
Battery requirement for Transmitter:
Power Supply :
Rating : DC 9 V, 0,45 W
Batteries : 6 x 1.5 V "AA"/LR6/AM3
Requires 6 x 1.5 V "AA" size batteries
(not included)
Small parts.
Helicopter
Power Light
ON/OFF
Throttle Stick
Tri-Band Selector
Battery Installation – Transmitter
1. Use a Phillips head (Cross-Head) screwdriver to loosen the screws on the battery case anti-clockwise (pic.1).
2. Put 6 AA size batteries in the battery compartment as per the polarity shown inside (pic.2).
3. Tighten the screw in clockwise (pic.3).

Charging The Flying Eagle

1. Pull out the cover and take out the
charging wire
2. Turn off the power of the Flying
Eagle. Insert the charging plug into
the socket under the Flying Eagle
3. Turn ON the transmitter. The
green LED on the transmitter will
light up when charging. Once
completed, the green LED will
turn off. Pull the plug out of the
socket under the Flying Eagle
Note: If the power of the transmitter
flashes, please replace the batteries
for new ones

Pack List

Transmitter Screwdriver Spare blades
Transmitter
Infrared Lights
Direction Stick
Trimmer
Recharging Indicator
Slide open -Recharging
Connector Wire
BATTERY INSTALLATION
pic.1 pic.2
Charging socket Power Switch
Instructions Manual
Minimum Throttle Position
Battery Cover
pic.3
Charging Line
Power Light Power light
