S&K TV Systems TVS 5000A Operation Instructions

Cable Box/Remote Operation instructions
Turns TV On and Off
Cycle through Video Inputs on TV
(TV should always be on ______ to Watch Cable
Change between days in guide
("A" for Previous Day. "B" for Next Day)
Display Daily Program Guide
Display Info on Selected Program
Control and Mute TV's Volume
Direct Entry of Channel Numbers
Return to Last Channel Viewed
Operation:
Turn on TV and Cable Box.
Tune the channel number using the number pad or channel up/down buttons. Refer to printed listing on back of this card.
Optional: Press Guide or OK button to access Program Guide or Channel listing. Choose your channel by navigating through
guide or channel listing. Hit select to tune channel. (You can hit exit at any time to stop navigation and tune the channel number
using the number pad or channel up/down buttons.)

Trouble shooting:

TV is on but there is no picture:
No lights on cable box – Make sure box is plugged into a working power outlet.
Time and flashing red light on cable box – Turn on cable box using "Cable" power button on remote.
Program # & solid red light & flashing green light on box – Check to see if coax connector is
Program # & solid red & green lights on box – Verify TV is on the correct video input (_______) use
TV has a frozen picture (or you have verified the steps above and still have no picture):
Power cycle the cable box – Turn the cable box off using the power button on front left corner of box.
If you are still having problems contact us at 1-800-924-7880.
S & K TV Systems
High Definition Box (TVS 5000A)
)
Turn box on using power button on the front left corner of the box.
Connected tightly to wall outlet and RF input on box.
Input button on the remote to cycle through available inputs.
Check HDMI (or 5 wire Component) connection from cable box to TV for tightness. Replace
cables if necessary.
Leave off for 30 seconds.
Turn the Cable box on using the power button on front left corner of box.
Allow 1 minute to start up.
Allow 30 minutes for all guide data and program information to reload.
Turns Cable Box On and Off
Open On-Screen Channel List
(
Or Select a Channel from Guide or Channel List)
Move around Guide or Channel List (Arrow Keys)
(Right & Left arrows will change Cable Box Volume when not in
Guide. -Should only be used for Balancing Levels- Use VOL +\- to
Control TV's Volume)
Exit from Menu, Guide, or Channel List
Move around Guide or Channel List a Page at a
Time
Move Up or Down to Next Channel
Switch Between TV and Digital Music Services
