ASSEMBLY INSTRUCTIONS
Underdesk Compact Exercise Bike
CAUTION!
Please make sure that the pedals are attached to the correct sides, L to left
and R to right. Screw in the right pedal clockwise and the left counter clockwise. Check
if the straps are tightly secured on the pedal before using the bike for the rst time.
Dazadi.com is not responsible for damages caused by incorrect assembly.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
Thank you for your purchase of this Harvil product!
We work around the clock and around the globe to ensure that Harvil products maintain
the highest possible quality. However, in the rare instance that your product is defective
or missing parts, contact your retailer to submit parts requests or warranty claims.
Please read the warranty information at the back of these assembly instructions
for further details.
The information contained in this manual is subject to change without notice.
UD-B
UD-B
1
Advertisement
Summary of Contents for Harvil UD-B
- Page 1 IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT. Thank you for your purchase of this Harvil product! We work around the clock and around the globe to ensure that Harvil products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, contact your retailer to submit parts requests or warranty claims.
-
Page 2: Important Safety Instructions
This product could expose you to one or more chemicals known to the State of California to cause cancer and birth defects or reproduction harm. To reduce the risk of electrical shock, always unplug this unit from its power source before cleaning or performing any maintenance tasks. UD-B... -
Page 3: Expanded-View Drawing
EXPANDED-VIEW DRAWING UD-B... -
Page 4: Parts List
Split pin Computer sensor Flange Screw M6X12 Screw M5X10 Support bar Spacer Flywheel Non-slip pad Peda crank Battery, AAA Screw M6 X14 Band brake bracket Screw driver Rivet Brake band Wrench Screw M5X25 Washer M6 Screw M5X20 Screw M4X7 UD-B... - Page 5 CAUTION: Make sure the pedals are attached to the corresponding sides correctly. Screw in the right pedal clockwise, and the left pedal counter-clockwise with hands rst, and tighten up with wrench. STEP 4 Attach Battery (26) to Monitor (1) UD-B...
-
Page 6: Operational Instructions
OPERATIONAL INSTRUCTIONS Mile Mile/h UD-B... -
Page 7: 90-Day Limited Warranty
Harvil reserves the right to make substitutions to warranty claims if parts are unavailable or obsolete. Harvil shall not be liable for loss of use of the product or other consequential or incidental costs, expenses or damages incurred by the consumer of any other use. The user assumes all risk of injury resulting from the use of this product.
