- Page 1 USER GUIDE PUREPOWER SERIES CENTRAL VACUUM POWER UNITS PP500, PP600 & PP650 AB0039 FOR RESIDENTIAL USE ONLY 30042509E SFDB-DQ, SFDB-DR SFDB-DS ODELS...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE When using an electrical appliance, basic precautions should always be followed, including the following: WARNING 14. When performing installation, servicing or cleaning the unit, it is recommended To reduce the risk of fire, electric to wear safety glasses and gloves. -
Page 3: Grounding Instructions
GROUNDING INSTRUCTIONS WARNING Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the appliance –... -
Page 4: Operation And Maintenance
OPERATION AND MAINTENANCE Open the inlet cover and insert the end of the hose into the inlet to turn on the vacuum. For non-switched hoses, inserting the hose automatically turns on the power unit; removing the hose shuts off the power unit. Some hoses have switches which can be used to activate power unit. -
Page 5: Sealed Hepa Permanent Filter
OPERATION AND MAINTENANCE ( ’ CONT SEALED HEPA PERMANENT FILTER (PP600 AND PP650 POWER UNITS ONLY) This filter protects the motor and stops small particles from escaping to the outside of the power unit without the need to replace it. The filter cleans itself by moving up when the power unit starts, and dropping down when the unit is turned off. -
Page 6: Motor Foam Filter ( All Units )
OPERATION AND MAINTENANCE ( ’ CONT FOAM MOTOR FILTER (ALL UNITS) A foam motor safety filter, located at the top of the vacuum chamber provides protection against dirt being pulled into the motor if the disposable bag or sealed HEPA permanent filter should accidentally be torn. -
Page 7: Removal & Installation Of Secondary Hepa Filter (Pp650 Power Unit Only )
OPERATION AND MAINTENANCE ( ’ CONT REMOVAL AND INSTALLATION OF SECONDARY HEPA FILTER (PP650 POWER UNIT ONLY) NOTE: This is a disposable HEPA filter; do not attempt to wash it since this will damage it. This HEPA filter should be replaced every 5 years. Proceed as follow: ... -
Page 8: Service Parts
SERVICE PARTS PP650 UNIT PP500 AND PP600 UNITS AL0021... - Page 9 In order to ensure your unit remains in good working condition, you must use NuTone genuine replacement parts only. NuTone genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
-
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE ROBLEMS OSSIBLE CAUSES OSSIBLE REMEDY 1. Loss or • Debris pail or disposable • Change the disposable bag or empty decrease bag is completely full. debris pail as described on page 5. of suction • Debris pail gasket •... - Page 11 TROUBLESHOOTING GUIDE ( ’ CONT ROBLEMS OSSIBLE CAUSES OSSIBLE REMEDY 2. Power • Defective inlet. Check • Replace defective wall inlet. unit does other wall inlets. not start • Power unit internal • Push or stops circuit breaker has been circuit suddenly.
