Summary of Contents for GOPURE UF-5
- Page 1 5-Stage Water Purifier USER GUIDE UF-5 5-Stage Ultra Filtration...
-
Page 3: Table Of Contents
CONTENTS FLOW DIAGRAM ............1 BEFORE YOU START ............2 WHAT’S IN THE BOX ............3 WHAT’S IN THE BOX ............4 INSTALLATION ..5 (connecting Tee Fitting & Tubing) INSTALLATION ......... 6 (installing the Tap) INSTALLATION ...... 7 (installing the Pre-Filters) INSTALLATION .... -
Page 4: Flow Diagram
Congratulations on purchasing the GOPURE UF-5 WATER PURIFIER! You have taken your first step towards cleaner, better tasting water and a healthier life for your family. Your new GOPURE UF-5 WATER PURIFIER comes equipped with an ADVANCED 5-STAGE ULTRA FILTRATION SYSTEM (items 2 - 6 below). -
Page 5: Before You Start
Follow all the steps exactly to avoid damaging the system. The GOPURE UF-5 WATER PURIFIER contains filters that need to be replaced at certain intervals. Replacement intervals will vary according to use, for more details see page 8 of this manual. -
Page 6: What's In The Box
WHAT’S IN THE BOX A) GOPURE UF-5 Water Purifier Unit B1) Spun PP Filter B2) Granular Carbon Filter B3) Block Carbon Filter B4) UF Membrane B5) Mineral Ball Filter C) Blue Tubing D1) White Tubing D2) Transparent Self-Sealing Ring D3) Transparent Tube Reinforcing Insert... -
Page 7: What's In The Box
WHAT’S IN THE BOX... -
Page 8: Installation (Connecting Tee Fitting & Tubing)
Connecting the Tubing (water supply to Unit) • Place the GOPURE UF-5 Water Purifier Unit under your counter and as close to the Tee Fitting (G) as possible • Measure the length of Blue Tubing (C) needed to join the Tee... -
Page 9: Installation (Installing The Tap)
Installing the Tap: • Select a convenient location near your sink to place the Tap (E1) • Drill a hole 12mm in diameter in the counter top (drill & bit not included) • Place the Cover Plate (E2) and one Rubber Washer (E3) on the Tap thread as shown below •... -
Page 10: Installation (Installing The Pre-Filters)
• Attach the end of the White Tubing (assembled as on page 5) to the bottom of the Tap by tightening the Steel Fastening Nut • Attach the other end of the White Tubing to the output side of the Mineral Ball Filter and fasten with a Circlip in the slot provided as shown below Installing the Pre-Filters: •... -
Page 11: Installation (Installing The Uf Membrane)
Flushing the system: Once the GOPURE UF-5 WATER PURIFIER is fully installed, flush it by running 10 litres of water through the system. This must be done before consuming water from the unit. -
Page 12: Installation (Installing The Drain Clamp)
Installing the Drain Clamp: To prolong the life of your UF Membrane, follow the instructions below to install the Drain Clamp (J): • Position the Drain Clamp (J) on your drain pipe above the drain trap and tighten it securely with the screws and nuts provided. •... -
Page 13: Maintenance
12 months. However, if at any stage you find that the water pressure from the tap of your GO PURE UF-5 WATER PURIFI- ER has been negatively affected, it means that your filters are clogged up and need to be replaced irrespective of age. -
Page 14: Safety Instructions
SAFETY INSTRUCTIONS This appliance is intended to operate as per the instructions in this manual. It is not designed to operate outside the specifications listed and any attempt to do so, or tamper with the unit can cause damage and will void the warranty. This unit is not a toy. - Page 16 Go pure, advanced 5-stage ltration process Go clear, removes harmful impurities Go healthy, adds essential minerals Go better, improves water taste Go easy, so simple to install Brought to you by: 0861 77 88 88 www.tevo.co.za | info@tevo.co.za...
