Summary of Contents for Seicane AL-82 series
- Page 1 Android Navigation User Manual English For Models：AL-82 series Version：V0.1...
-
Page 2: Table Of Contents
Catalog Navigation …………………………..………………….1 Main Menu / How to use Navigation Music Player…………………………………………….3 Music Player interface / Interface Introduction HD Video Player………………………………….…….5 Video Player interface / Interface Introduction PIP Settings (Picture in Picture) Bluetooth telephone and Music……………………….7 Bluetooth connection / Bluetooth Music Bluetooth Settings Phone-link ………………………………………..…..09 IOS Phone connection... -
Page 3: Navigation
Navigation 1.Main Menu First Page Second Page 2. How to use Navigation Enter the first page. Click icon “Navigation”,access into Navigation function. -
Page 4: Music Player
Music Player 1.Music Player Interface 2.Interface Introduction Previou Pause Next Track Loop Sourse Local Memory Play 3.Support Audio Format APE/FLAC/WMA/AAC/OGG/RA/WAV/MP3/MP2... -
Page 5: Hd Video Player
HD Video Player 1.Support Video Format 4.PIP settings (Picture in Picture) H.263/H.264/MPEG1/MPEG2/MPEG4/RMVB/AVI/WMV/3GP/MP4/MOV /MPG/VOB/MKV/FLV/TS/TP/DAT etc.. 2.Video player Interface Select this icon for achieving PIP function. 3.Operation Menu 5.Full Screen Play Previous Play and Pause Next Cycleplay Sourse Local Touch an arbitrary point within this area for achieving playing in full screen. -
Page 6: Bluetooth Telephone And Music
Bluetooth Telephone and Music 1.Connection 3.Missed/Received call Turn on the Phone Bluetooth and search for Bluetooth devices; Note: Only can check the call log that called after connecting Bluetooth.. 4.Bluetooth music (*Phone should with Music Player and turn it on) Default Device name:GocAndroid Password：0000 2.Dial... -
Page 7: Phonelink
Phonelink 1.Introduction It can map the phone screen to the device screen and display it. Supppot IOS 7.0 version and Android 5.5 verison or above or above *Note: 1)Android version: Must connect by USB cable for the first time. 2)Android version: Must connect Bluetooth first 3) If sharing the HOTSPOT from mobile phone, it would quick connect well. -
Page 8: Dvr
3.Setttings for AV DVR *Must install DVR device before using this function.. In Factory Settings - DVR - CVBS DVR (√) 1.Connecting method of USB 2.0 DVR Connect USB DVR with USB connector, install APK of DVR. 1) Connect USB Cable with android device. 2) Connect USB DVR with USB connector, After installing, click the DVR icon then it can show the current picture. - Page 9 Reversing camera 3.Reversion display If you need check the reversing info, Car should be with camera. Support Original camera/Aftermarket camera/and 360 Camera 1.Connecting Settings Display Radar You can settings the Brightness/contrast and the path line/Radar Only can show the display of Radar if the original car with Radar. Steering Wheel Control Video Input Power...
-
Page 10: Settings
Settings 4.Time 1. Settings Please set it according te the preference of the customers 5.Audio Previous/Next Sub menu Preview 2.Navi Settings You can choose one navigation as default navi. 3. Language Please set it according te the preference of the customers. The volume of Bluetooth and navigation can be set here. -
Page 11: System Info
Settings 6.System System info is the version of the Device. 8.More settings 1) Rear view mirror camera The camera ,right and left is the opposite 2）Video while driving ban It is Android original settings.Please set it according te the *For your safety, watching Video is forbidden when driving. preference of the customers 3) Rear view camera type *Note:... - Page 12 Feature and Accessories 2.Accessories 1.Feature 1) Hardware CUP: A9 1.2G Quad core Power Harness X1 RAM: 1G(or higher) ROM:16G(or higher) Display :24:9 Resolution:1280*480 RGB Touch screen: G+G capacitive touch screen 2)Software USB cable X1 Android 4.4.4 or higher version 3)Specification Woring Voltage :DC 10.8-16V Working Temperature:-20---+60℃...
- Page 13 FAQS Reason: Did not remove the optic fiber from Original power harness and 1:Wrong Display or showing not correctly. plug it into our power harness. Solution：remove the optic fiber from Original power harness and plug it into our power harness. Reason:wrong resolution Solution: Select the correct Cantype in FACTORY SETTINGS Steps: Factory Settings - Cantype.
- Page 14 Important statements: Android devices are with faster upgrading, Product you buy might not completely the same as the this user manuals. If any difference, please refer to the actual products.If any questions,pleae feel free to contact us.
