Mobinil MF190 Quick User Manual

Mobinil MF190 HSUPA USB Modem
Quick User Guide
No.55, Hi-tech Road South, ShenZhen, P.R.China
Zip Code: 518057 Service Hotline: +86-755-26779999
http://www.zte.com.cn E-mail: mobile@zte.com.cn
Introduction
The Mobinil MF190 USB modem is a multi-mode 3G USB modem, work-
ing in HSDPA/HSUPA/WCDMA/EDGE/GPRS/GSM networks. With USB
interface connecting to a laptop or a desktop PC, it integrates the func-
tionality of a modem and a mobile phone (SMS), and combines mobile
communication with Internet perfectly. It supports data and SMS services
through the mobile phone network, enabling you to communicate anytime
and anywhere.
Specification
The following table shows the specification of your device.
Interface type
USB2.0 HIGH SPEED
Network Standards
HSDPA/HSUPA/WCDMA/EDGE/GPRS/GSM
HSDPA/UMTS2100MHz;
Frequency
EDGE/GPRS/GSM1800/900MHz
HSUPA 5.76Mbps UL
Transmission (Max. data rate)
HSDPA 7.2Mbps DL
Expandable with mircroSD(Can be used as a
Memory
memory stick)
USIM&SIM Standard 6 PIN Interface
Red Turn on and not register
LED
Green Register to network
Green twinkling Data interchange
Auto Installation
Support
Antenna Internal antenna
Equalization
Support
Temperature
-40°C ~ +80°C
-Storage temperature
-10°C ~ +60°C
-Operation temperature
Windows XP(SP2 and later), Vista, Windows 7,
System Required
MAC OS 10.4, 10.5, 10.6
Dimensions About 89mm x 26mm x 11mm
Weight About 26g
Certification & Approval
CE certification, ROHS, WEEE
MSM6290
Chipset
Getting to know your device
The following figure shows the appearance of the MF190. It is only for
your reference. The actual product may be different.
1. Indicator
2. Front Cover
3. Modem Cap
4. USIM/SIM Card Slot
5. microSD card slot
6. USB Port
