OPERATION AND PARTS MANUAL
SERIES
MODEL MVH128GH
REVERSIBLE PLATE COMPACTOR
(HONDA GX160UT2SCM GASOLINE ENGINE)
Revision #0 (03/08/18)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVH128GH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MQ Multiquip MVH128GH

  • Page 1 OPERATION AND PARTS MANUAL SERIES MODEL MVH128GH REVERSIBLE PLATE COMPACTOR (HONDA GX160UT2SCM GASOLINE ENGINE) Revision #0 (03/08/18) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 3 NOTES MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 3...

  • Page 4: Table Of Contents

    Specifications and part numbers are subject to change Electric Device Assembly ......... 42-43 without notice. Operation Assembly ......... 44-47 Nameplate And Decals Assembly ....48-49 PAGE 4 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 5: Parts Ordering Procedures

    All orders are treated as Standard Orders and will ship the same day if received prior to 3PM PST. WE ACCEPT ALL MAJOR CREDIT CARDS! MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 5...

  • Page 6: Safety Information

    COULD result in DEATH or SERIOUS INJURY. CAUTION Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE INJURY. NOTICE Addresses practices not related to personal injury. PAGE 6 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 7: Safety Information

     ALWAYS clear the work area of any debris, tools, etc. that would constitute a hazard while the equipment is in operation. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 7...
  • Page 8 MV H-3 06 the engine start diffi cult. and serious damage to the equipment or engine. PAGE 8 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 9  ALWAYS keep battery cables in good working condition. hot engine. Repair or replace all worn cables. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 9...
  • Page 10  Contact your country's Department of Public Works or recycling agency in your area and arrange for proper disposal of any electrical components, waste or oil associated with this equipment. PAGE 10 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 11: Specifications

    Environment by equipment for use outdoors. Products are tested for hand/arm vibration (HAV) level in accordance with European Directives 2002/44/EC and EN500-4 and ISO 5349-1:2001, ISO 5349-2:2001. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 11...

  • Page 12: Dimensions

    DIMENSIONS Figure 1. Dimensions Table 4. Dimensions REF. DES. IN. (MM) 15.75 (400) 23.23 (590) 40.55 (1030) 38.00 (965) PAGE 12 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 13: General Information

    The resulting vibrations cause forward motion. The engine the function of all the controls and components. and handle are vibration isolated from the vibrating plate. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 13...

  • Page 14: Components

    COMPONENTS Figure 2. Plate Compactor Components PAGE 14 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 15 7. Throttle Lever — Controls speed of the plate compactor. Place straight vertically to start, push fully counterclockwise for full throttle and fully clockwise to stop plate compactor. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 15...

  • Page 16: Basic Engine

    Reference the maintenance section in this manual for servicing. PAGE 16 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 17: Inspection

    Table 5. Oil Type Season Temperature Oil Type Summer 25°C or Higher SAE 10W-30 Figure 7. V-Belt Location Spring/Fall 25°C~10°C SAE 10W-30/20 Winter 0°C or Lower SAE 10W-10 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 17...
  • Page 18 3. When the handle bar is raised to the desired height, tighten the wing nut. Grip V-BELT VIBRATOR Wing nut PULLEY Figure 9. V-Belt Tension Figure 11. Handle Height Adjustment PAGE 18 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 19: Startup

    5. Place the engine ON/OFF switch (Figure 16) in the "ON" position. THROTTLE LEVER IDLE POSITION Figure 13. Throttle Lever (Idle Position) Figure 16. Engine ON/OFF Switch (ON Position) MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 19...

  • Page 20: Startup

    (Figure 18) as the engine warms up. If the engine has not started, repeat steps 1 through 6. CHOKE LEVER OPEN CLOSE Figure 18. Choke Lever (Open) PAGE 20 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 21: Operation

    REVERSE OPERATION POSITION NEUTRAL THROTTLE LEVER FORWARD IDLE DIRECTION POSITION CONTROL LEVER Figure 21. Direction Control Lever Figure 22. Throttle Lever (Idle) MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 21...

  • Page 22: Operation

    Figure 24. Fuel Valve Lever (OFF) Emergency Shutdown 1. Move the throttle lever quickly to the IDLE position, and place the engine ON/OFF switch in the OFF position. PAGE 22 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 23: Maintenance

    Ensure that the maintenance area is well ventilated. Gasoline engine exhaust contains poisonous carbon monoxide gas that can cause unconsciousness and may result in DEATH. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 23...
  • Page 24 2. These items should be serviced by your service dealer, unless you have the proper tools and are mechanically proficient. Refer to the HONDA Shop Manual for service procedures. 3. For commercial use, log hours of operation to determine proper maintenance intervals. PAGE 24 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 25 Bolt threads used with this machine are all right handed Material and quality of material is marked on each bolt, and screw. Figure 25. Engine Air Filter MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 25...
  • Page 26 Table 5. For engine oil capacity, see Table 2 (Engine Specifications). DO NOT overfill. 3. Reinstall drain bolt with sealing washer and tighten securely. CYLINDER Figure 29. Removing Hydraulic Hose PAGE 26 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 27 Visually examine the V-belt (Figure 31) and determine if it ARRESTER is full of tiny cracks, frayed, has pieces of rubber missing, is peeling or otherwise damaged. Figure 32. Spark Arrester Removal MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 27...
  • Page 28 6. Reinstall the spark arrester and muffler protector in reverse order of disassembly. PAGE 28 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 29: Troubleshooting (Compactor)

    Piston inside hydraulic pump not Adjust or replace. moving smoothly? Direction Control Lever operating resistance for reverse is high. Vibrator cylinder piston does not move Adjust or replace. smoothly MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 29...

  • Page 30: Troubleshooting (Engine)

    Fuel fi lter/lines clogged? Replace fuel fi lter. Fuel tank cap breather hole clogged? Clean or replace fuel tank cap. Air in fuel line? Bleed fuel line. PAGE 30 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 31 Check cable connections. Charge or replace Will not start, no power with key "ON". (if Battery disconnected or discharged? applicable) battery Ignition switch/wiring defective? Replace ignition switch. Check wiring. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 31...

  • Page 32: Explanation Of Code In Remarks Column

    “Remarks” Column. assembly/kit that can be purchased, or is not available for sale through Multiquip. PAGE 32 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)

  • Page 33: Suggested Spare Parts

    1....17620Z4H900 ..CAP COMPLETE, FUEL TANK 1....17672Z4H000 ..FUEL FILTER, FUEL TANK Part numbers on this Suggested Spare Parts list may supersede/replace the part numbers shown in the following parts lists. MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 33...

  • Page 34: Vibrating Plate Assembly

    MVH-128 VIBRATING PLATE ASSY. VIBRATING PLATE PAGE 34 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 35 BOLT, 12X30 030212300 WASHER, LOCK M12 471354550 COVER, VIBRATOR 050710080 O-RING .............1....REPLACES P/N 050710160 001220820 BOLT, 8X20 030208200 WASHER, LOCK M8 031108160 WASHER, FLAT M8 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 35...

  • Page 36: Vibrator Assembly

    MVH-128 VIBRATOR ASSY. VIBRATOR PAGE 36 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 37 WASHER, LOCK M8 472355220 GUIDE, BELT COVER 001220820 BOLT, 8X20 030208200 WASHER, LOCK M8 031108160 WASHER, FLAT M8 472219870 BELT COVER, LOWER 001520851 SOCKET HEAD BOLT, 8X55 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 37...

  • Page 38: Base And Engine Assembly

    MVH-128 GH BASE AND ENGINE ASSY. BASE AND ENGINE (HONDA: GX160) PAGE 38 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 39 WASHER, LOCK M12 031112230 WASHER, FLAT M12 472219860 CENTER COVER 001521030 SOCKET HEAD BOLT, 10X30 031110160 WASHER, FLAT M10 030210250 WASHER, LOCK M10 020310080 NUT M10 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 39...
  • Page 40 MVH-128 GH BASE AND ENGINE ASSY. CONT'D. BASE AND ENGINE (HONDA: GX160) PAGE 40 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 41 WASHER, LOCK M6 022710607 NYLON NUT M6 371467760 RETURN SPRING 031105080 WASHER, FLAT M5 2067550101 CLAMP, COMPLETE 959407260 CLIP D6 001221015 BOLT, 10X15 030210250 WASHER, LOCK M10 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 41...

  • Page 42: Electric Device Assembly

    MVH-128 GH ELECTRIC DEVICE ASSY. ELECTRIC DEVICE (HONDA: GX160) ENGINE PAGE 42 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 43 2067550101 CLAMP COMPLETE 955301010 STOP SWITCH, ENGINE 468467570 READ CORD 467466980 LEAD WIRE (SW-GROUND) 020308060 NUT M8 959021827 SPIRAL TUBE 515450380 WIRE HARNESS 506010070 CLAMP MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 43...

  • Page 44: Operation Assembly

    MVH-128 GH OPERATION ASSY. OPERATION PAGE 44 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 45 471354800 LEVER, TRAVEL 001220830 BOLT, 8X30 031108160 WASHER, FLAT M8 030208200 WASHER, LOCK M8 022710809 NYLON NUT M8 030208200 WASHER, LOCK M8 458337480 PUMP HOLDER MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 45...
  • Page 46 MVH-128 GH OPERATION ASSY. CONT'D. OPERATION PAGE 46 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 47 MALE CONNECTOR, O-RING 1/4" 2067550101 CLAMP COMPLETE 001220615 BOLT 6X15 030206150 WASHER, LOCK M6 459219610 HAND PUMP 001520510 SOCKET HEAD BOLT 5X10 463455950 SPACER,THROTTLE 956100078 THROTTLE WIRE MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 47...

  • Page 48: Nameplate And Decals Assembly

    MVH-128 GH NAMEPLATE AND DECALS ASSY. NAMEPLATE AND DECALS PAGE 48 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 49 DECAL, MQ MARK 920218390 DECAL, CAUTION 920218130 DECAL, E/G RPM 3600 920208350 DECAL, V-BELT RPF3330 920221750 PLATE, SERIAL NO./MQ 920211690 DECAL, LEVER OPERATION 920220810 DECAL, CAUTION, LEVER MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 49...

  • Page 50: Cylinder Head Assembly

    HONDA GX160UT2SCM ENG. — CYLINDER HEAD ASSY. PAGE 50 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 51 FLANGE BOLT 6X12 90043ZE1020 STUD BOLT 6X112 90047ZE1000 STUD BOLT 8X32 9430110160 KNOCK PIN 10X16 957010806000 BOLT, FLANGE 8X60 0650140480 SPARK PLUG, BPR6ES 9500280000 CLIP, TUBE MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 51...

  • Page 52: Cylinder Barrel Assembly

    HONDA GX160UT2SCM ENG. — CYLINDER BARREL ASSY. PAGE 52 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 53 O-RING 14MM ...........1....REPLACES P/N 91353671004 9405010000 FLANGE NUT M10 9410106800 WASHER, FLAT 6MM 9425108000 LOCK PIN 8MM 957010601200 FLANGE BOLT 6X12 35480Z0T003 SWITCH ASSY., OIL LEVEL MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 53...

  • Page 54: Crankcase Cover Assembly

    HONDA GX160UT2SCM ENG. — CRANKCASE COVER ASSY. PAGE 54 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 55 PACKING, OIL FILLER CAP 91201Z0T801 OIL SEAL 25X41X6 9430108140 KNOCK PIN 8X14 957010803200 FLANGE BOLT 8X32 961006205010 BALL BEARING ..........1....REPLACES P/N 961006205000 15625Z0T800 PACKING, OIL FILLER CAP MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 55...

  • Page 56: Crankshaft Assembly

    HONDA GX160UT2SCM ENG. — CRANKSHAFT ASSY. PAGE 56 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 57 HONDA GX160UT2SCM ENG. — CRANKSHAFT ASSY. PART NO. PART NAME QTY. REMARKS 13310Z4M880 CRANKSHAFT COMPLETE 90741883810 KEY 5X5X33 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 57...

  • Page 58: Honda Gx160Ut2Scm Engine

    HONDA GX160UT2SCM ENGINE — PISTON ASSY. PAGE 58 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 59 PISTON 0.25 13103Z4M800 PISTON 0.50 13111Z4M000 PIN, PISTON 13200Z0T900 ROD ASSY., CONNECTING ......1....INCLUDES ITEM W/$ 90001Z4M000 BOLT, CONNECTING ROD 6X34.5 90551ZE1000 CLIP, PISTON PIN 18MM MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 59...

  • Page 60: Camshaft Assembly

    HONDA GX160UT2SCM ENG. — CAMSHAFT ASSY. PAGE 60 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 61 VALVE, EXHAUST 14751ZF1000 SPRING, VALVE 14771Z0T900 RETAINER, SPRING VALVE 14771Z0T900 RETAINER, SPRING VALVE 14791Z4M000 PLATE, PUSH ROD GUIDE 90012ZE0010 BOLT, PIVOT, 8MM 90206ZE1000 NUT, PIVOT ADJUSTING MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 61...

  • Page 62: Recoil Starter Assembly

    HONDA GX160UT2SCM ENG. — RECOIL STARTER ASSY. PAGE 62 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 63 28442ZH8003 SPRING, RECOIL STARTER 28443Z1T701 SPRING, RETURN 28462ZH8003 ROPE, RECOIL STARTER 90003ZH8801 SET SCREW 957010600800 BOLT, FLANGE 6X8 28461Z4M305 KNOB, RECOIL STARTER 28463Z4M003 KNOB, REINFORCEMENT MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 63...

  • Page 64: Fan Cover Assembly

    HONDA GX160UT2SCM ENG. — FAN COVER ASSY. PAGE 64 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 65 SHROUD COMPLETE 34150ZH7023 ALERT UNIT, OIL 35120Z0T831 SWITCH ASSY., E/G STOP 90013883000 FLANGE BOLT 6X12 90022888010 FLANGE BOLT 6X20 90601ZH7013 CLIP, HARNESS 957010600800 FLANGE BOLT 6X8 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 65...

  • Page 66: Carburetor Assembly

    HONDA GX160UT2SCM ENG. — CARBURETOR ASSY. GASKET SET NOTICE Gasket set, item 1 included with items 4, 7, 8, 13, 23, 30 and 31. PAGE 66 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 67 MAIN JET #72 30❉ 99204ZE20400 PILOT, JET SET #40 ........1 ...INCLUDES ITEM W/% 31❉ 16141Z0S003 WASHER, FLAT ..........1 ...INCLUDES ITEM W/% 32❉ 16959Z5T901 FILTER, CUP MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 67...

  • Page 68: Air Cleaner Assembly

    HONDA GX160UT2SCM ENGINE — AIR CLEANER ASSY. PAGE 68 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 69 17238ZE7010 COLLAR 17239ZE3840 COLLAR B 17410Z0V780 ELBOW COMPLETE .........1....INCLUDES ITEMS W/% 90300Z4M800 WING NUT 90325044000 WING NUT 9405006000 FLANGE NUT 6MM 957010602000 FLANGE BOLT 6X20 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 69...

  • Page 70: Muffler Assembly

    HONDA GX160UT2SCM ENGINE — MUFFLER ASSY. PAGE 70 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 71 18522ZE1000 GUIDE, MUFFLER 90002Z0T800 SCREW, TAPPING, 4X8 90016ZE1000 FLANGE, BOLT 6X13 90050ZE1000 SCREW, TAPPING, 5X8 90055ZE1000 SCREW, TAPPING, 4X6 94001080000S NUT 8MM 18310Z4MV51 MUFFLER COMPLETE MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 71...

  • Page 72: Fuel Tank Assembly

    HONDA GX160UT2SCM ENGINE — FUEL TANK ASSY. PAGE 72 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 73 CAP COMPLETE, FUEL TANK ......1....INCLUDES ITEM W/% 17672Z4H000 FUEL FILTER, FUEL TANK 17510Z4M000ZB FUEL TANK COMPLETE, NH1, BLK 90503898000 WASHER, TANK CUSHION 91302Z4M003 O-RING 5.5X1.5 MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 73...

  • Page 74: Flywheel Assembly

    HONDA GX160UT2SCM ENGINE — FLYWHEEL ASSY. PAGE 74 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 75 HONDA GX160UT2SCM ENGINE — FLYWHEEL ASSY. PART NO. PART NAME QTY. REMARKS 13331357000 WOODRUFF KEY 25X18 19511ZE1000 COOLING FAN 28451Z4M003 STARTER, PULLEY 31110Z4M000 FLYWHEEL COMPLETE 90201Z0T800 NUT, SPECIAL 14MM MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 75...

  • Page 76: Ignition Coil Assembly

    HONDA GX160UT2SCM ENGINE — IGNITION COIL ASSY. PAGE 76 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 77 PART NAME QTY. REMARKS 957010602500 FLANGE BOLT 6X25 .........2....REPLACES P/N 90121952000 30500Z0T003 COIL ASSY., IGNITION 30700Z0T812 CAP ASSY., NOISE SUPPRESSOR 32195Z0T003 CORD, STOP SWITCH 370MM MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 77...

  • Page 78: Control Assembly

    HONDA GX160UT2SCM ENGINE — CONTROL ASSY. PAGE 78 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 79 LOCK NUT 6MM 90605230000 CIR CLIP 0043504060 SCREW 4X6 ............1....REPLACES P/N 93500040060H 0202005T125 SCREW 5X16 ............1....REPLACES P/N 93500050160A 93500050250H SCREW 5X25 9405006000 FLANGE NUT 6MM MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 79...

  • Page 80: Decals Assembly

    HONDA GX160UT2SCM ENGINE — DECALS ASSY. PAGE 80 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 81 PART NAME QTY. REMARKS 87521Z4M000 EMBLEM (GX160) 87528Z4M000 MARK, CHOKE 87532ZH7000 MARK, THROTTLE INDICATION 87602Z0V780 MARK, SALES POINT 87516Z4H010 MARK, OP CAUTION 87539Z4M000 MARK, EX. CAUTION MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 81...

  • Page 82: Terms And Conditions Of Sale - Parts

    Multiquip’s designated receiving point. PAGE 82 — MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18)
  • Page 83 NOTES MVH128GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (03/08/18) — PAGE 83...
  • Page 84 OPERATION AND PARTS MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Corporate Offi ce MQ Parts Department 18910 Wilmington Ave. Tel. (800) 421-1244 800-427-1244 Fax: 800-672-7877 Carson, CA 90746 Fax (310) 537-3927 310-537-3700 Contact : mq@multiquip.com...

Table of Contents
