- Page 1 Prime 1.65 (VS) INSTALLATION AND USER GUIDE Model (PL2605)
-
Page 2: Read And Follow All Instructions
READ AND FOLLOW ALL INSTRUCTIONS ATTENTION INSTALLER This manual contains essential information about the : installation, operation, and safe use of this pool pump. Please remember to furnish this manual and all other instructional documents to the end user of this product. The Pureline Prime Variable Speed Pump is specifically engineered for today’s inground swimming pools and spas. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS General Warnings ● Never open the inside of the drive motor enclosure ● The pump is not submersible ● Code requirements for the electrical connection differ from state to state. Install equipment according to the National Electrical Code. ●... - Page 4 WARNING- T he pump can produce high levels of suction within the suction side of the plumbing system. These high levels of suction can post a risk if a person comes within close proximity of the suction openings. A person can also be seriously injured by the high level of vacuum or may become trapped and drown.
- Page 5 causing a mechanical bind or swelling of the limbs. This is typically caused when a drain cover is missing, broken, cracked, or not secured properly. Body Suction Entrapment- A portion of the body is held against the drain cover, trapping the swimmer underwater.
-
Page 6: General Information
General Information This manual contains essential information about the installation, operation, and safe use of this pool pump. F ailure to install according to the defined instructions will void your warranty. The PureLine Prime Pump is our newest, premiere pump that rivals top brands like Hayward, Pentair, Sta-Rite, Jacuzzi, and Waterway. - Page 7 ● Easy access to all internal parts for servicing Product Dimensions Pump Performance Chart PURELINEPOOL.COM TEL: 407-834-2200...
-
Page 8: Installation Instructions
Installation Instructions W ARNING- T his product should only be installed and serviced by a qualified professional. Please refer to “General Warnings” for additional safety information. Pump Location Before installing the pump, selecting a proper location for your pump is essential to prolonging the overall lifespan of your pump. -
Page 9: Fittings And Valves
Fittings and Valves 1. Fittings restrict flow so for better efficiency, use the fewest possible fittings (but at least 2 suction outlets). 2. Pool and spa fittings MUST conform to the International Association of Plumbing and Mechanical Officials (IAPMO) standards. 3. - Page 10 Mains Connection Pin # Wire Color Description Black Hot 1 Red or White Hot 2 Green Screw Green Earth Communication Connection Pin # Wire Color Description J201-1 +12 V J201-2 Black J201-3 Yellow J201-4 Green Voltage Voltage at motor cannot exceed more than 10% above or below the rating listed on the motor label.
- Page 11 around the pool with a continuous wire. Bonding also reduces the risk of a current passing between bonded metal objects, which could potentially cause electrical shock if shorted. Reference NEC codes for all wiring standards including, but not limited to, grounding, bonding, and general wiring procedures.
-
Page 12: Start-Up And Operation
● Manual override ● Compatibility with V-Green 270 user interface (sold as separate accessory) ● High efficiency electromechanical motor and control design Benefits of adding an optional V-Green 270 user interface ● Ability to conduct field troubleshooting (i.e., view fault codes and real time operating parameters) ●... - Page 13 WARNING- D o N OT a dd chemicals to the pool/spa directly in front of pump suction. Adding chemicals may damage pump and void your warranty WARNING- B EFORE r emoving strainer cover 1. STOP p ump 2.
- Page 14 V-Green 165 Quick Start Guide (Default Schedule) The V-Green quick start up uses the factory default schedule. The following table describes the factory settings for DURATION and SPEED order. Button Duration Speed (in Hours) (in RPMs) Step 1 3100 Step 2 2600 Step 3 1850...
- Page 15 Press STEP 1 key. The STEP 1 button and the DURATION setting LEDs will light up. The bar graph will show the default DURATION for STEP 1. 1. Press the UP (+) or DOWN (-) arrows to change the DURATION 2.
- Page 16 ** An additional V-Green User Manual is included with this manual, as well. Statement of Warranty Policy The pump was inspected before shipment from the warehouse. To original purchasers of this pump, Pureline Products warrants its products free from defects in materials and workmanship for a period of ...
