- Page 2 TABLE OF RECOMMENDED TORQUE VALUES DESCRIPTION TORQUE Stem Expander Bolt 20Nm (where fitted) A-Head Steerer Clamp Bolts 20Nm (where fitted) Stem Binder Bolt 15Nm Brake Fixing Bolt (non disc) Applies to both front and rear brake Front Axle Nut 30Nm Front QR Axle Chain Wheel Securing Bolt 38Nm Pedal 40Nm F/Derailleur Cable Fixing Bolt R/Derailleur Cable Fixing Bolt Rear Axle Nut 30Nm Rear QR Axle Seat Pin (Allen Head) 20-35Nm Front and Rear Reflector Mounting Nut Saddle Clamp Bolt 30Nm F/Derailleur Clamp Bolt 5.5Nm Page 1...
- Page 3 Warranty Land Rover bikes are guaranteed against material defects or faults of manufacturing from the date of the original purchase as follows. Frame & forks. Land Rover frames and forks are warranted against failure or defects for a period of following years. 1 year on double suspension frames. 1 year on suspension forks. 5 years on rigid frame & forks. Component Parts Land Rover component parts are warranted against failure or defects for a period of up to one year. Note: This warranty applies only to the original owner and is not transferable. Claims under this warranty must be made through the original place of purchase or an authorised dealer. Proof of purchase is required. This warranty does not apply to damage or failure due to accidents, misuse, abuse or neglect. Modification of the frame or components shall void this warranty. This warranty does not cover normal wear and tear, improper assembly by a third party or poor maintenance or installation of parts or accessories not originally intended or compatible with the cycle. This bicycle has been designed to meet or exceed the requirements relevant to its intended use and catagorization within the ISO standard. As part of this process this bicycle has been assigned to one of the specific categories.
- Page 4 Page 3...
- Page 5 YOUR BICYCLE — OWNER’S RESPONSIBILITY Owner’s Responsibility and Important Points Point 1 Carefully and thoroughly read this manual and follow the instructions. Point 2 Any major service or adjustments on your bicycle should be carried out by a professional repairer; however if this service is not available and you wish to make adjustments yourself, this manual contains important tips on how to do it.
- Page 6 Every six months (more frequently if high mileage or subject to heavy use) your bicycle should be professionally checked to ensure that it is in correct and safe working order. But remember, it is the responsibility of the rider to ensure all parts are in working order, prior to riding the bike.
- Page 7 General Suspension Units Notes Your cycle may be fitted with suspension units built into parts of the frame and forks We recommend these are serviced by your dealer as required. More information may be found in the suspension manufacturers details supplied with your cycle. Riding Position It is important that you and your bicycle are fitted to each other, not only for comfort and riding ease but for control and safety.
- Page 8 HANDLEBARS AND STEMS As your cycle may be fitted with a standard ‘quill’ stem or an A-Head stem, you must always check that all the bolts are tight before cycling. Standard Stem: Loosen expander bolt so that expander wedge is not tight in bottom of handlebar stem.
- Page 9 Recessed Type Standard Stem Stem Expander Binder Bolt 6mm Allen Key Bolt Handlebar Stem Bolt (Allen Head) Minimum Insertion Mark A-Head Type Compression Cap Compression Bolt 5 Star Washer Stem Bolts Steerer Clamp Bolts Extension Spacers Bearing Seat Top cup with Bearings BRAKES inside WARNING...
-
Page 10: Brake Maintenance
BRAKE MAINTENANCE 1. Check cables are corrosion free and lubricated to maintain smooth function. 2. Check all cables are free of kinks or frayed section, replace as necessary. 3. From time to time check all the retaining bolts are secure including those of the pads. - Page 11 Brake Pipe 4. Locate the brake cable wire into position behind Hanger the pinch bolt (some have a hole to thread the wire through). Loosely secure the wire in position. 5. Locate the curved lead pipe into the brake lead pipe hanger.
-
Page 12: Pad Replacement
9. It is possible to alter the rest position of the brake lever by screwing in the reach adjuster screw which pushes the lever nearer to the handlebars. If you utilise this function take care to perform all the adjustments from your preferred rest position. Be aware that this adjustment uses up brake lever potential travel and requires more regular maintenance and fine adjustment of the brake system. -
Page 13: Chain Tension
CHAIN TENSION If your cycle has a single rear gear sprocket (internal gears or single speed cycles). You may need to adjust the chain tension from time to time or after rear wheel removal. To adjust the chain tension correctly both wheel retaining nuts should be loose. Pull the wheel back into the frame dropouts to take up the chain slack. - Page 14 Page 13...
-
Page 15: Gear Changing
DERAILLEUR GEARS INTRODUCTION The derailleur gear is so named because it works on the derailing principle to move the chain from one sprocket to another. The number of gears is determined by multiplying the number of sprockets on the rear freewheel by the number of chainrings on the front crank set. - Page 16 Page 15...
- Page 17 TYRE CARE AND WHEEL ADJUSTMENTS CONTINUED QUICK RELEASE FRONT WHEEL To remove the front wheel, first release the front wheel brake. The release the quick-release lever on the axle and pull the wheel from the forks. To install, fit wheel into forks with quick release lever on the left side. Close quick- release, and tighten adjuster until snug.
- Page 18 STANDARD WHEEL ADJUSTMENT & REMOVAL To Remove Rear Wheel Move the chain onto the smallest rear sprocket. Disengage the brake quick release lever if your bicycle is so equipped. Loosen both axle nuts by turning in a counter clockwise direction. Pull the derailleur mechanism gear for additional clearance. Remove the rear wheel by sliding forward and out of the frame.
- Page 19 BIKE CARE Page 18...
-
Page 20: General Maintenance
GENERAL MAINTENANCE WARNING: As with all mechanical components, the bicycle is subjected to wear and high stresses. Different materials and components may react to wear or stress fatique in different ways. If the design life of a component has been exceeded, it may suddenly fail possibly causing injuries to the rider. - Page 21 Page 20...
-
Page 22: Tyre Care
TYRE CARE To obtain maximum life and full benefit from your tyres, it is essential to maintain the recommended pressure indicated on the tyre sidewall. Unnecessary hard braking and skidding greatly reduces tyre life. Make sure your tyres do not come into contact with oil, petrol, paraffin or other rubber solvents. Make sure that your wheels run true and are in correct alignment to avoid chafing the tyre sidewall against the bicycle frame or fork tubes. - Page 23 BIKE CLASSIFICATION Our Bicycles are manufactured to comply with ISO 4210:2014, this encompasses the following classification of product. Mountain Bike ISO 4210 A bicycle designed for use off road on rough terrain, on public roads and on public rights of way. It will be equipped with a suitably strengthened frame and other components, and, typically, with wide section tyres with coarse tread patterns and a wide range of transmission gears. Off road terrain is where you can expect to encounter coarse pebble tracks, forest trails, and general off road tracks where tree roots and rocks are likley to be encountered. It does not apply to racing cycles and specialised types of bicycles designed and equipped for use in severe applications such as sanctioned competition events, stunting or aerobatic manoeuvres.
