Griffin Technology AirClick Quick Start Manual

AirClick

What Do I Need?

To use AirClick, you'll need either:
• iPod with dock connector (not included); or...
• iPod mini (not included).

What Is All This Stuff?

AirClick features two key pieces: the Remote Control
and the Receiver Module. Let's take a look:

Remote Control

Play/Pause
Next/Fast Forward
Previous/Rewind
Volume Up
Hold Switch (Orange = Hold)
Volume Down

Receiver Module

• Headphone Jack (connect headphones or speakers)
• LED (illuminates when receiving a command)
• Pairing Switch (Back of unit. See PAIRING)
AirClick
Let's Install it!
To install the AirClick, simply plug the receiver module
into the top of your iPod or iPod mini. That's it!
AirClick

How Do I Use it?

Controlling your AirClick is as simple as using your
iPod. Here's how:
Turn iPod On:
Turn iPod Off:
Play a Song:
Pause a Song:
Go to Next Song:
Go to Previous Song: Press the Rewind
Fast Forward Song: Press/Hold the Fast Forward
Rewind Song:
Increase Volume:
Decrease Volume:
Quick Start Manual
Press any button on the Remote
Control to wake the iPod.
Press and hold the Play/Pause
( ) Button for two seconds.
( )
Press the Play/Pause Button.
Note: If the iPod is at the Main
Menu, pressing Play/Pause will
cause the iPod to start playing
all of its music.
( )
Press the Play/Pause Button
while a song is playing.
( )
Press the Fast Forward Button.
( )
Button.
( ) Button.
Press/Hold the Rewind ( ) Button.
( )
Press the Volume Up Button.
( )
Press the Volume Down Button.

Pairing

By default, all AirClicks work on the same "channel."
If you have more than one AirClick Remote Control
within range of an AirClick Receiver, the Receiver will
happily take commands from both Remotes.
Since you probably don't want this to happen (unless
you like your neighbor controlling your iPod), you can
tell the Receiver to accept commands only from a spe-
cifi c AirClick Remote Control through a process called
Pairing. Use Pairing whenever more than one AirClick
Remote Control will be used in the same area.
You'll fi nd the pairing button on the back of your receiver.
To Turn Pairing On:
• Press the Pairing Switch on the Receiver
Module by inserting a paper clip or similar device.
The LED on the Receiver will light up.
• Press any button on the Remote within fi ve seconds
• The LED on the Receiver will fl ash rapidly for one
second, indicating that the Pairing was successful
Turn Pairing Off:
To reverse the process, allowing the Receiver Module
to once again be controlled by any Remote Control,
simply use a straightened paper clip or similar device
to press the Pairing Switch on the Receiver Module
and DO NOT press any buttons on the Remote Control.
After fi ve seconds, the LED on the Receiver will turn
off, and it will again respond to any AirClick Remote.

Photo Browsing:

AirClick can be used to display images on your iPod
Photo. To do so, you'll need to put the AirClick Remote
Control into Photo Mode:
• Set the Hold Switch on the AirClick Remote
(an orange dot will appear).
• Press and hold the Play/Pause button.
• With the Play/Pause button depressed, slide the
Hold Switch to Active.
You can now browse forward or backward through
photographs by pressing the Volume Up and Volume
Down buttons, respectively. (Not enabled for TV out.)
To exit Photo Mode, just slide the Hold Switch from
Active to Hold, then back to Active.
