OVERVIEW
Below are the steps you need to follow to begin using your Kensington KS-SAL-20 pocket salinity tester. This manual
will cover how insert the batteries, using the function keys, making measurements, calibration and sensor replacement.
PACKAGE CONTENTS
1. Conductivity calibration solutions (1413 µS/cm, 12.88m µS/cm, 111.8 S/cm,)
2. AAA batteries
3. Carrying case
INSERTING THE BATTERIES
1. Your Kensington Pocket KS-SAL-20 pocket salinity tester uses two AAA batteries.
2. Remove the button cap found on the bottom of the tester as shown in the above image.
3. Place the battery into its designated slot. Take note of the proper position of the battery to ensure the polarities
placed correctly.
4. Replace the battery cap.
KEYPAD INDEX
Key
Function
1. Serves as the power button of the tester
2. Initiates Data Hold. Press once to hold the current reading, press again to resume making
measurements.
3. Exit button during calibration
1. Press once to conduct calibration of the instrument
2. Press and hold to enter setup menu
3. In calibration mode, press to set calibration values.
4. In setup mode, press to select default option
Kensington Scientific
22a Cavan Rd, Dry Creek
South Australia, 5094
helpme@kensingtonscientific.com.au
www.kensingtonscientific.com.au
User Manual
KS-SAL-20 |Pocket
Salinity Tester
Advertisement
Table of Contents
Related Manuals for Kensington KS-SAL-20
Summary of Contents for Kensington KS-SAL-20
- Page 1 Salinity Tester OVERVIEW Below are the steps you need to follow to begin using your Kensington KS-SAL-20 pocket salinity tester. This manual will cover how insert the batteries, using the function keys, making measurements, calibration and sensor replacement. PACKAGE CONTENTS 1.
- Page 2 2. Toggles between conductivity, TDS and salinity measurement modes. DISPLAY The KS-SAL-20 is built with a clear LCD display that shows the measured value, various mode indicators and units. Below is a summary to describe the meaning behind each notification on the display.
- Page 3 User Manual KS-SAL-20 |Pocket Salinity Tester SETTING OF DEFULAT PARAMETERS 1. Press the CAL button to enter setup menu. The first display should be the default number of calibration points. 2. Press the CAL key again to change the default calibration point, selecting 1, 2 or 3 points. Press the ENTER key to confirm.
- Page 4 16. The tester will automatically go to measurement mode. CONDUCTIVITY CALIBRATION It is recommended that the KS-SAL-20 should be calibrated regularly to ensure accurate measurements. The KS-SAL- 20 allows up to 3 points calibration and it is recommended to use 3 points calibration before measurement.
- Page 5 User Manual KS-SAL-20 |Pocket Salinity Tester Below is a chart showing acceptable conductivity standard solutions during calibration. Measuring range Calibration solution range Default 200~2000 µS/cm 700~1700µS/cm 1413 µS/cm 2~20 mS/cm 7~17 mS/cm 12.88 mS/cm 20~200 mS/cm 70~170 mS/cm 111.8 mS/cm Single Point Calibration 1.1 Make sure to choose the 1 point calibration and in the settings.
- Page 6 User Manual KS-SAL-20 |Pocket Salinity Tester 2.3 Rinse the electrode with distilled water and with a small amount of the next calibration solution. 2.4 Dip the electrode into the 12.88 mS/cm buffer solutions Stir the tester gently and make sure the electrode is completely submerged into the solution.
- Page 7 ELECTRODE REPLACEMENT One of the advantages of using the Kensington KS-EC-10M-E is that the sensor can be replaced instead of buying a new tester when the sensor fails during calibration. Removing and installing the sensor is easy and convenient and also increases the utility of the instrument as additional sensors can be purchased for different applications.
- Page 8 User Manual KS-SAL-20 |Pocket Salinity Tester 2. Align the new electrode into the same spot, push, and turn clockwise to keep it secure. SPECIFICATIONS Salinity Range 0.00~80.00ppt Accuracy ± 1% F.S Resolution 0.01 ppt Calibration points 1 to 3 points Calibration solutions 10µS/cm, 84µS/cm, 1413µS/cm, 12.88mS/cm...
