Summary of Contents for Lippert WIFI ON-THE-GO
-
Page 1: Wireless Hotspot
Quick Start Guide Wireless Hotspot CCD-0001336... - Page 2 The weatherproof, external cellular antenna array increases your signal range far beyond a simple “off-the-shelf” mobile hotspot. WiFi On-the-Go utilizes Direct Link Technology specifically designed to go wherever you go. Direct Link Technology provides the fastest 4G LTE connectivity available, up to 150Mbps per second, so you’re connected wherever the...
-
Page 3: Key Features
Key Features: • Direct Link Technology provides the fastest 4G LTE connectivity available, up to 150Mbps • Weatherproof externally mounted 4G antenna provides superior coverage • Designed and engineered for the mobile lifestyle • 2.4 GHz WiFi antennas designed to provide coverage at a longer range. •... -
Page 4: Additional Information Sources
WiFi On-the-Go is compatible with AT&T and T-Mobile cellular ® ® service using LTE bands 2,4 & 12. In order to activate your WiFi On-the-Go hotspot, the owner will need to purchase their own AT&T or T-Mobile nano Sim card and data package. ® ®... -
Page 5: Parts List
Parts List Fig.1 Letter Part# Description 715645 Coax Cable, 10’ 722255 External Cellular Antenna 383635 #8 x 3/4” Stainless Steel Pan Head Screw 722251 2.4 GHz WiFi Antenna 722252 4.0G Cellular Antenna 716722 12V DC/DC In-line Power Supply 722250 Cellular Gateway 722253 120V AC/DC Adapter... - Page 6 Introduction The WiFi On-the-Go is a portable device but can be fastened to a mounting surface if desired. If the external cellular antenna is not a permanent mount there are a number of methods of temporary mounting that can be utilized at the retail customer’s discretion, i.e. hook and loop material, two-sided tape, etc.
- Page 7 Fig.2 Activation Using AT&T ® or T-Mobile ® SIM Card...
-
Page 8: Installation
® ® • Android, iOS smart device or personal computer • Ethernet cable (optional) Installation For more comprehensive instructions, visit Lippert Components website https://www.lci1.com/assets/content/support/manuals/Electronics/ WiFi_On_the_Go____Aftermarket_Manual.pdf or for immediate use of WiFi On-the-Go: NOTE: Not all components will be needed for the initial set-up. - Page 9 8. Plug the 120V AC/DC adapter into a wall outlet or connect the red and black wires of the 12V DC/DC adapter to a 12V power source. 9. Verify power and connectivity with the Wifi On-The-Go LEDs (Fig.3C). Lights will flash when connected.
-
Page 10: System Configuration
System Configuration After successful activation of Wifi On-The-Go, use a mobile device or an Ethernet cable and personal computer to connect to the 4G LTE wireless hotspot. NOTE: For the best security, the settings should be configured with the WiFi On-the-Go wired via Ethernet cable and a personal computer. - Page 11 Fig.5 3. At the top menu bar select “System” dropdown menu (Fig.6A). Fig.6 4. Click on “Administration” (Fig.6B).
- Page 12 5. Enter a new administrator password and confirm (Fig.7A and Fig.7B). NOTE: For security purposes use a strong password. For easy retrieval of a forgotten password, it is recommended to write down and store the new password in a secure location or use a password management encrypted database that may be located on your personal computer or mobile device.
- Page 13 7. At the top menu bar select “Network” dropdown menu (Fig.9A). 8. Click on “Wifi” (Fig.9B). Fig.9 A. Click on the Edit button under the “Wireless Overview” section (Fig.10A), then scroll to the Interface Configuration at the bottom of the page. Fig.10...
- Page 14 B. If preferred, rename the hotspot (ESSID) here (Fig.11A). C. Click on “Save” (Fig.12A). Fig.11 Fig.12 D. Click on the “Wireless Security” tab (Fig.13A) to ensure Wi-Fi security. I. From the menu, select the desired level of security. LCI recommends WPA2-PSK (Fig.14A).
- Page 15 (step 8DII), enter the new password. NOTE: Do not press “RESET” on the back of the cellular gateway unless directed by Lippert Customer Service. Reset will take the device back to factory settings and make the device inoperable.
- Page 16 FCC 15B statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These |limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 17 IC User manual notice: This device contains licence-exempt transmitter(s)/receiver(s) that com- ply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 18 Notes...
- Page 19 Notes...
- Page 20 722050 Contact Lippert Components Incorporated Should you have any questions, please do not hesitate to contact us at (574) 537-8900 or by email at customerservice@lci1.com. Self-help tips, technical documents, product videos and a training class schedule are available at lci1.com...
