Summary of Contents for JMC SC560N4 HDMI
-
Page 1: User Guide
SC560N4 HDMI HDMI User Guide 101-SC560-3-4 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se... -
Page 2: Table Of Contents
........................6 ONNECTION IAGRAM 4.3. P ............................6 RECAUTION 4.4. PCI/PCIE ............................7 5. SOFTWARE INSTALLATION (SC DEVICE) .................. 8 5.1. S OS ..........................8 UPPORTED 5.2. D ........................8 RIVER NSTALLATION JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se... -
Page 3: Product Introduction
3. PRODUCT INTRODUCTION 3.1. Product Brief SC560N4 HDMI is a high-quality, high-performance capture device which is specially designed for high-definition video capture applications. It supports up to 4 channel of high-definition, 2160p30 video from HDMI1.4B source and HDMI embedded audio source. -
Page 4: S Pecification
PCIe x4 (Gen2) Video Input 4 × HDMI 1.4B Display Video YV12,NV12,YUY2,RGB24,RGB32 Format HDMI 1.4B 4096×2160@30/25/24fps 3840×2160@30/25/24fps 2560x1600@60fps 2048x1152@60fps 2560×1440p@60fps Video RAW 1920×1440p@75/60/50fps Data 1920×1200p@85/75/60/50fps Resolution 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se... - Page 5 720×576i@50fps Audio Input 4 × HDMI Embedded audio Audio Stereo / 16-bit / 32000 ~ 48000Hz Format WatchDog ✓ Multiple ∞ Cards VC++ / C# / .NET / VB / V4L2 JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se...
-
Page 6: Hardware Installation
Figure below is the connection diagram for supported signal and interface. Signal Connection diagram 4.3. Precaution Before proceed, make sure touch a safely grounded object or metal object before touching the device. JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se... -
Page 7: Pci/Pcie
Install PCI/PCIE card to available motherboard PCI/PCIE slot and fasten the screw on the device and back plate. Close the chassis and connect signal source to the device. Turn on the system. JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se... -
Page 8: Software Installation (Sc Device)
• Control Panel • System • Device Manager • And user can find device from the device manager dialog (see below figure, device number will different by channel numbers). SC560 Series JMC Systems Engineering AB www.jmc.se +46-8-82 82 70 info@jmc.se...
