IDN EL730SLR User Manual

Electronic pushbutton locks
Hide thumbs
Table of Contents

Advertisement

Quick Links

Electronic Pushbutton Locks
USER S GUIDE
security
I MP O RT A N T S A F ET Y IN S TR UC TIO N
1. To prevent damage to the finish, DO NOT use any abrasives, sharp objects or harsh chemical
products containing alcohol, petroleum solvents, acids or acetone to clean this lockset.
！
2. To prevent damage to the sensitive electronic components, DO NOT allow any liquids to enter
lockset while installing or cleaning.
1. Do not attempt to disassemble any internal components of this lockset as this WILL void the
limited warranty.
2. Do not drop or hit /strike the lockset as excessive shock may result in permanent damage.
3. Do not use sharp objects to press key buttons.
CAUTION
4. It is Strongly recommended that you always create a written backup of the programming code
and individual user codes. Please use the last page of this booklet as your reference.
5. For your Security, please remember to change this lockset's factory default programming code to
a PERSONAL programming code prior to normal day to day use of this product.
6. It is STRONGLY recommended that you use only ALKALINE BATTERIES to operate this product.
'
technology
01A
EL730SLR
© 2017 IDN, Inc. All rights reserved.
0817

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL730SLR and is the answer not in the manual?

Questions and answers

Related Manuals for IDN EL730SLR

Summary of Contents for IDN EL730SLR

  • Page 1 5. For your Security, please remember to change this lockset's factory default programming code to a PERSONAL programming code prior to normal day to day use of this product. 6. It is STRONGLY recommended that you use only ALKALINE BATTERIES to operate this product. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 2: Table Of Contents

    07. HOW TO DELETE AN INDIVIDUAL EXISTING PROXIMITY CARD 08. HOW TO DELETE AN INDIVIDUAL EXISTING REMOTE CONTROL 09. HOW TO DELETE ALL EXISTING USER CODES AT ONCE 10. HOW TO DELETE ALL EXISTING PROXIMITY CARDS/ REMOTE CONTROLS AT ONCE © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 3 4. To lock the lockset by pressing Lock Button Key Override To unlock the lockset by a valid key. Thumbturn Thumbturn To lock or unlock the lockset manually. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 4: Main Operating Instructions

    3. The lockset cannot be programmed by entering any of the user codes. 4. The lockset will be unlocked by entering one user code. Note: User code capacity: 10 sets maximum. Proximity card capacity: 10 sets maximum. Remote control capacity: 10 sets maximum. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 5: Components

    Q. Key (2) G. Interior Assembly H. 5/16” (7.8mm) Screw (2) R. Drive in Collar (Optional) S. Bottom Plate (Optional) I. 13/16” (20mm) Screw (1) T. Square or Radius Faceplate (Optional) U. Screw post © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 6: Installation Instructions

    ( 75 mm to 150 mm ) above the entry knob or lever. INSTALLATION INSTRUCTIONS DRILL PILOT HOLES Select a backset. Mark and drill pilot holes as shown below. Drill a 1/8 pilot hole Drill a 1/8 pilot hole © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 7 Use the faceplate as a template for mortise and pilot holes. Chisel 1/8”( 3 mm) deep. Faceplate should fit flush. d. Install the appropriate latch type as shown below. Note: For a drive-in latch, please refer to page 14. © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 8 Latch backset adjustment only needs to be made if your door needs a 2-3/4” ( 70 mm ) backset. Please follow diagrams below as referece. ( Skip this if your door has a 2-3/8” ( 60 mm ) backset ) © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 9 If a drive-in latch is used, please tap it into the appropriate position. Faceplate Drive-in Latch Tap Latch Flush Backset Wood Block (not included) 13/16” (20 mm) screws (See before installation of drive-in latch) © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 10 Thread the tailpiece through the latch in horizontal position. Thread the cable through the hole and under the latch. INSTALLATION INSTRUCTIONS Slide cable through the notch of mounting plate. The bulged part of mounting plate must face toward the door. © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 11 Note: Screw (E) is an optional screw. We recommend using screw (E) for the stability of the lockset. INSTALLATION INSTRUCTIONS REMOVE THE DECORATIVE COVER 1. Hold on the lip of the 2. Put the thumbs on 3. Remove the decorative cover decorative cover. the thumbturn. by pushing the thumbturn. © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 12 The metal connector side should face outside. Note: The red portion of the cable is aligned with the red portion of the connector port. INSTALLATION INSTRUCTIONS The cable must be arranged as shown in the diagram. © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 13 2. Enter 123456 (or current programming code) and then press button. Enter [00] and press button. The Red LED will light up for 10 seconds. The lockset will have the bolt direction set. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 14: Setup Mode

    1.The lockset will go back to the standby status if no button is pressed in 10 seconds after accessing setup mode. 2.If you enter new programming code in 10 seconds after accessing setup mode, the last programming code will be stored in the lockset. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 15: How To Add An User Code

    10 seconds after accessing setup mode. 2.Please use or purchase proximity cards compatible with standard Mifare -13.56 MHz if you want to have more than one proximity card. 3.Proximity card capacity: 10 sets maximum. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 16: How To Add A Single-Use User Code/ Proximity Card/ Remote Control

    6. Do not use your multiple-entry user code/ multiple-entry remote control/ multiple-entry proximity card to facilitate single-entry operation, or your user code/ remote control/ proximity card will become invalid after only one-time use (entry). © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 17: How To Delete An Individual Existing User Code

    1.The lockset will go back to the standby status if no button is pressed in 10 seconds after accessing setup mode. 2.If any card is lost, for your safety, please delete all cards and re-add current cards excluding the lost one. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 18: How To Delete An Individual Existing Remote Control

    The Red LED will light up for 10 seconds. The lockset will delete all existing user codes. Note: 1.The lockset will go back to the standby status if no button is pressed in 10 seconds after accessing setup mode. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 19: How To Delete All Existing Proximity Cards/ Remote Controls At Once

    If you will be away from your home for a period of, it is a good idea to use vacation mode to prevent repeated access attempts. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 20: How To Disable Button Sound (Mute Mode)

    2.The lockset will auto-lock in 10 seconds (default value) without flashing and beeping after unlocking if you turn on auto-lock mode. 3.The lockset can still be locked by pressing button manually even if you turn on auto-lock mode. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 21: How To Setup Auto-Lock Time Delay

    10 seconds after accessing setup mode. 2.Please make sure that both user code and card, or both user code and remote control, are stored in the lockset before you turn on double authorization mode. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 22: How To Restore Factory Setting

    PCB and the electrode terminal. 4. Push into the new battery. 5. Replace the PCB. 6. Place the bottom shell back and tighten the Battery box screws. CR2032 Battery Shell © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 23: Operation Mode

    4.If you do not press button to clear previous incorrect codes, the red LED will light up and you have to wait until the red LED lights off, then the lockset is allowed to re-enter codes. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 24: Safe Mode

    1. Do not lock (or unlock) the door consecutively. This will cause a bump. Feel a bump while turning 2. If feeling a bump, press button while the door is unlocked to allow the thumbturn or the key? the motor to reposition. © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 25 I am unable to reset the sure all steps are followed correctly. lockset. 2. Check to see if the Yellow LED light is flashing or not. It means "low battery" if the light keeps flashing. © 2017 IDN, Inc. All rights reserved. 0817...
  • Page 26 3. Please touch the inductive zone with the card to unlock. If the lock appears to be damaged or does not function properly, please contact your local provider for more help. © 2017 IDN, Inc. All rights reserved. 0817...

  • Page 27: Declarations And Safety Statements

    3. The memory capacity for user codes is 10 sets. 4. It is STRONGLY recommended changing all codes if any security information in the table is lost. Programming code Name User code Name User code © 2017 IDN, Inc. All rights reserved. 0817...
