• This guide is designed as a supplement to the complete user's
manual for the USB bridge, located on the included CD-ROM
• Installing this device may require that you have administrator privi-
leges on your PC.
• It is highly recommended that you install the included software be-
fore making the hardware connections to your PC.
• Do not connect the included USB cable or the hardware interface to
your PC until after the software installation has completed. Failure to
follow these instructions may cause your PC to "freeze" or cause the
USB Bridge and software to incorrectly function.
• Should you need assistance installing the included software, please
seek the assistance of a trained computer specialist or contact our
technical support department:
Quick Start Guide
BEFORE YOU BEGIN:
(800) 440-9476 (US Office, toll-free)
(714) 465-3400 (outside the US)
evsupport@enhancedvision.com
Advertisement
Table of Contents
Related Manuals for ENHANCED VISION USB BRIDGE
Summary of Contents for ENHANCED VISION USB BRIDGE
-
Page 1: Quick Start Guide
Quick Start Guide BEFORE YOU BEGIN: • This guide is designed as a supplement to the complete user’s manual for the USB bridge, located on the included CD-ROM • Installing this device may require that you have administrator privi- leges on your PC. • It is highly recommended that you install the included software be- fore making the hardware connections to your PC. • Do not connect the included USB cable or the hardware interface to your PC until after the software installation has completed. Failure to follow these instructions may cause your PC to “freeze” or cause the USB Bridge and software to incorrectly function. • Should you need assistance installing the included software, please seek the assistance of a trained computer specialist or contact our technical support department: (800) 440-9476 (US Office, toll-free) (714) 465-3400 (outside the US) evsupport@enhancedvision.com... - Page 2 Software inStalation 1. Start up your PC as normal. Load the included CD-ROM containing the Viewer Application software and USB drivers into the CD-ROM drive of your PC as shown (See Figure 1). Figure 1 2. The installation should start automatically. If not, you may need to browse and double-click on the “ViewerSetup.exe”...
- Page 3 Hardware inStalation 7. If you are setting up the USB Bridge for the first time, please insert the lithium battery into the charger base of the USB Bridge so that it can fully charge (See Figure 7) Figure 7 8. Connect the camera output cable of your compatible Enhanced Vision product to the “CAMERA”...
- Page 4 15. Momentarily, the camera image should appear on your PC screen (See Figure 15). Figure 15 For detailed operating instructions of your USB Bridge and its functions, please consult the electronic version of the owner’s manual, located on the included CD-ROM www.enhancedvision.com (800) 440-9476 (US Office, toll-free)
