Revolution Multiducer SSP6 Installation Manual

INSTALLATION GUIDE
Please Read
®
SSP6
Multiducer
REVOLUTION ACOUSTICS SSP6 MULTIDUCER™
The SSP6 Multiducer™ (multifunctional transducer)
miraculously transforms nearly any panel structure into an
audio speaker. Revolutionary thinking has created one of
the most compact and powerful "invisible" audio systems
available today. Embedding the SSP6 Multiducer™ into
walls, ceilings, glass, furniture, vehicles and other
products transforms non-acoustic materials and devices
into high fidelity audio speakers. Using an entirely different
subset of acoustical physics, the SPP6 is able to "ergo-
nomically" project sound unlike any other conventional
speaker filling the space with rich audio content in ways
never before tought possible.
Fast and easy installation using the RevLoc™ mounting
plate (included). Water and dust resistant coupled with
solid-state construction for consistent and reliable service
over many years. A true lifestyle solution, the SSP6 Multi-
ducer™ delivers true full frequency audio, ease of installa-
tion, and value unlike anything in its class or all others. It is
simply magical. Invisible audio, which is, literally out of
sight with performance to match.

TECHNICAL SPECIFICATION

• Next generation and new level of sophistication patented
invisible embedded audio technology.
• SSP6 with new RevLoc™ universal screw on mounting
plate for unparalleled ease of installation to virtually all
substrates in less then 3 minutes.
• Incredible class leading acoustic fidelity while driving
materials including glass, drywall, wood, fiberglass, metal,
or....
• Highest power density, best sounding transducers avail-
able using high energy magnet structures.
• Proprietary cooling technologies for better efficiency and
reliability.
• Frequency range full bandwidth: (unequalized) 45Hz –
20KHz.
• 70V compatible with Revolution Acoustics RA-T1 multi-
tap transformer.
• Revolution Acoustics part RA-HPL to be used with SSP6
if third party amplifiers are used greater than 150W/ch.
• Subwoofer not required for general purpose audio but
recommended for home theatre installations.
• Power handling up to 400W (instantaneous peak).
• Compact Ø2.7" X 2.29" high - RevLoc™ included
(Ø69mm X 58.1mm high).
• RevLoc™ Mounting Plate Ø4.0" (Ø102mm).
• Weight (Individual): 0.72 Kg / 1.6 Lbs.
• Impedance: 6Ω.
• Recommended amplifier per channel wattage: 60W -
150W.
• Max. Continuous Thermal Power: 15W totally
enclosed, 24W unenclosed.
• Transducer Accelerated Life test: fully enclosed passes
EIA 426B at 9.4V (recommended amplifier power rating
of 30W) 8 hour test 23C ambient.
• Transducer Accelerated Life test: unenclosed passes
EIA 426B at 12.0V (recommended amplifier power rating
of 48W) 8 hour test 23C ambient.
• UL 2043 fire and smoke certified for return air plenums.
• IP65 Ingress protection certified - water and dust proof.
• Packaging: 2 per box.
• Package weight: 1.65 Kg / 3.65 Lbs.
INSTALLATION INSTRUCTIONS
Your SSP6 Multiducers™ can transform many materials
into high fidelity audio emitters. Drywall panels (plaster
board), glass panels, wood, MDF, fiberglass, and even
some steel sheet can become large acoustic radiators
using your SSP6 Multiducers™. If possible, pre-test
your installation by handholding a Multiducer™ to the
material in which you wish to install to and sound-check.
Check surrounding surfaces and material as well and
install to the most desirable surface.
The SSP6 Multiducers™ will not function on brick, stone
or cinderblock, or materials lamented to them. Walls,
wood floors, quality build and framed windows,
fiberglass, and some furniture are typically good
choices.
The RevLoc™ mounting plate ensures a fast and easy
installation. The RevLoc™ must always be firmly
glued to the material being driven by the SSP6 Multi-
ducers™. Quick setting glue is to be applied essentially
over the entire bottom surface of the RevLoc™. Then
firmly press the RevLoc™ to the surface and let glue set
before screwing on SSP6 Multiducer™. Exceptions are
intra-wall retrofits where the RevLoc™ and SSP6 Multi-
ducer™ are typically installed together during the gluing
process.

Adhesives

One of 3 glues will cover all installations. In ALL cases,
once glues are set and hardened simply screw on the
SSP6 giving it a final screw torque by twisting the black
metal base of the Multiducer™ only hand tight, not
the plastic housing. This will activate the Loctite®
thread locking glue on the Revoc™ stud portion.
(please read)
