BeoWorld BeoCom 1401 User Manual

1 2 3
ABC DEF
4 5 6
GHI JKL MNO
7 8 9
PQRS TUV WXYZ
0
R
Rdl Mem
Flash
Vol Vol Enter
Beocom
Beocom
BeoCom 1401
RINGING SIGNAL
BeoCom 1401 has 10 different settings
of the ringing signal, combined from 3
levels and 3 melodies, and the tone
ringer disconnected.
Low Medium High
Slow 1 2 3
Normal 4 5 6
Fast 7 8 9
Disconnected 0
SETTING THE RINGING SIGNAL
Press Enter
Press
Press 0-9 to select the setting of your
choice.
Press Enter
When the ringing signal is disconnected
(setting 0), it is automatically reconnected
the first time you lift off the handset and
place it in the base again.
ADJUSTING THE VOLUME
During a call, you can adjust the
handset volume in 5 steps by pressing
+ –
the and buttons. All calls start at
the medium volume level.
+
Press to increase the volume.
–
Press to decrease the volume.
REDIALING
Press Rdl to call the last number
called.
Telephone numbers exceeding 31 digits
cannot be redialed.
In order to ensure that the last number
is stored and can be redialed, the
handset must be placed in the base (or
press the switch off key on the lower
side of the handset) for at least 1
second.
MICROPHONE
Press to mute the microphone.
A beep signal in the handset indicates
that the microphone is muted.
Press to connect the
microphone.
Please note! Pressing other keys one
or two times will connect the micro-
phone as well.
MEMORY
BeoCom 1401 memorizes 10 tele-
phone numbers which can be stored
under the code numbers from 0 to 9.
Numbers of up to 21 digits can be
memorized.
PLEASE NOTE!
If the telephone is disconnected from
the line for more than 1 hour,
numbers stored in the memory may
be erased. This may also happen
when using a computer modem or
another telephone on the same line.
STORING PHONE NUMBERS
Press Enter
Press Mem
Enter the code number (0-9)
Enter the phone number
Press Enter
DIALING A STORED NUMBER
Press Mem
Enter the code number (0-9)
DELETING A STORED NUMBER
A stored number is deleted by storing
a new number under the same code
number.
WALL HOLDER
The package contains a wall holder
that consists of one faceplate which
holds the handset and a choice of
two backplates which attach to the
wall.
The wider backplate is designed to fit
over the wall phone jack. It will slide
down and snap into place over the
pegs on the wall phone jack.
There are tabs inside this backplate
that allow for excess cord to be
wrapped inside the backplate. If you
wrap the cord clockwise then lead
the cord out in the bottom left
channel of the holder and if you
wrap the cord counterclockwise, then
lead the cord out in the bottom right
channel.
The faceplate will then slide down
and lock into place over the clips on
the backplate.
The narrow backplate is designed to
be screwed into the wall if no wall
phone jack is available. Please see the
enclosed instructions for details.
