30W Audio Amplifier DIN rail mounting
TECHNICAL MANUAL – INSTALLATION
Recommendations
1.
Use only original spare parts and consumables supplied by Tema Telecomunicazioni Srl for this equipment. The company shall
not be held responsible for any damage caused by the use of materials that they have not supplied.
2.
The device has been carefullly manufactured and tested. In any case, the product is not recommended for use in situations in
which incorrect operating may result in damage to persons and/or property.
3.
We recommend that you carefully read all this manual before starting to use the device.
4.
Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents.
5.
This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as
storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
Revision
Date
1
03/04/2018
MAS-AD301R-REV01EN
TEMA TELECOMUNICAZIONI S.r.l.
Telecommunications - Electronics
AD301R
AD301R - Version HW 1.0 – Version FW 1.0
Made in Italy by TEMA TELECOMUNICAZIONI S.r.l.
Revision reason
Update
Prepared
DP
Checked/Approved
FL
Page 1 of 12
Advertisement
Summary of Contents for tema AD301R
- Page 1 Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents. This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
- Page 2 Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL R&TTE DECLARATION OF CONFORMITY (DoC) We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: product name AD300 trade name TEMA TELECOMUNICAZIONI Srl type or model...
- Page 3 Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL I. IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS ELECTRONIC DEVICE The crossed-out wheeled bin symbol below indicates that this electronic equipment is intended to be dis- posed in a separate collection and not in an unsorted municipal waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic Equipment) using best available recovery and recycling tech- niques.
-
Page 4: Table Of Contents
Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL INDEX PAGE 1. PRESENTATION OF THE AD301R AUDIO AMPLIFIER ............. 5 2. MAIN FEATURES..........................5 3. PARTS COMPRISING THE SYSTEM (PACKING LIST) .............. 6 4. TECHNICAL SPECIFICATIONS ...................... 6 5. OPERATION ............................7 6. DESCRIPTION OF THE CONNECTION TERMINALS..............8 7. -
Page 5: Presentation Of The Ad301R Audio Amplifier
1. PRESENTATION OF THE AD301R AUDIO AMPLIFIER AD301R is an audio amplifier designed for the audio paging of messages and music. It is housed in a standard container suitable for DIN rail mounting and has 2 audio inputs and a speaker output. -
Page 6: Parts Comprising The System (Packing List)
Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL 3. PARTS COMPRISING THE SYSTEM (PACKING LIST) The AD301R system consists of the parts included in the following list: • One AD301R device (30W audio amplifier) • One DIN rail segment • Two anchors and two screws •... -
Page 7: Operation
Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL 5. OPERATION Please refer to the following block diagram of the device to describe the system. The "Equalizer" block realized with analog technology manages the inputs, the tone controls, the level signaling on the LED and passing the signals to the final stage of amplification, completely digital, in D class. -
Page 8: Description Of The Connection Terminals
*** Note. The playback will take place on the only SPK output in mono mode because AD301R will add the channel L (IN1) and the R channel (IN2) input, ensuring the exact reproduction of the content of the stereo source. -
Page 9: Installation Examples
Note that the connection of the speakers in parallel (could be the model AD333/30T) reduces the total impedance of the speaker system to 4Ω that however is perfectly suited to the output impedance of AD301R by being able to take all the available power. MAS-AD301R-REV01EN... -
Page 10: Basic Connection With 4 Horn Speakers
Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL 7.2. Basic connection with 4 horn speakers 15W-8 Ohm It is possible to double the number of speakers compared to the previous example in order to have a better sound distribution. However, to comply with the characteristics of the minimum output impedance of the system (minimum 4Ω) it is necessary to adopt a series/parallel connection of the speakers, it is not... -
Page 11: Basic Connection With Use Of The Aa-10/Pa And Aa-11/Pa Interfaces To Send Announcement From Telephone/Pbx
Basic connection with use of the AA-10/PA and AA-11/PA interfaces to send announcement from telephone/PBX An interesting application can be the use of the TEMA AA-10/PA or AA-11/PA interfaces as the audio source, allowing to interface a telephone system with the paging sound system. -
Page 12: Connection With Different Power Speakers On The 100V Speaker Line
Audio Amplifier AD301R TEMA TELECOMUNICAZIONI SRL 7.4. Connection with different power speakers on the 100V speaker line This connection example uses the output transformer AD320/30 which allows to exceed the 30mt limit of cable between the amplifier and the speakers suitable to be connected to the 100V line such as horn loudspeakers AD330/15T and AD330/40T and the rectangular or round speakers AD332/60T and AD333/30T.
