Voxx PNP100 Quick Start Manual

What's in the box?
(1) Projector (1) Power adapter (3) Image wheels

Getting started

1. PLUG IN THE PROJECTOR

Plug the right-angle end of Bottom of the projector
the power adapter into the
DC IN jack on the bottom of
the projector.
Run the cable through the
cable trough on the bottom
of the projector. Then place
Cable trough
the projector on a flat
surface.
Plug the other end of
the power adapter into a
working outlet or surge
protector.

2. LOAD AN IMAGE WHEEL

Back of the projector
On the back of the projector,
slide the image wheel door
into the FOR DISC ACCESS
position.
Take out the wheel drawer
above the image wheel door.
Wheel drawer
Please an image wheel on
the wheel drawer. Make sure
the UP label is facing up.
Put the wheel drawer back
into the image wheel door.
Slide the image wheel
Image wheel door
door up, into the FOR
(down position)
PROJECTION position.
IMPORTANT: The projector
will not illuminate unless
the image wheel door is in
the up (FOR PROJECTION)
position.

3. TURN ON THE PROJECTOR

To turn the projector on: Press the Front of the projector
PROJECTOR button on the front
of the projector.
To adjust brightness of the
projector (or turn it off): Press the
PROJECTOR button repeatedly to
cycle through the settings (high,
medium, low, and off).

4. ADJUST THE PROJECTOR POSITION

Back of the projector
Make sure the image wheel door
on the back of the projector is in
the FOR PROJECTION position
(pushed up).
Pull the projector lever below the
image wheel door to adjust the
projector position so that it points
where you want.
Image wheel door
(up position)
Projector lever

Everyday use

PLAYING SOUNDS

The Project Nursery Sight + Sound Projector offers a variety
of soothing lullabies and nature sounds, as well as white
noise, to calm baby.
Front of the projector
To cycle through these
sounds: Press the SOUND
button on the front of the
projector. Each press goes to
a different selection.
To adjust the volume: Press
the VOLUME – or + button.
To turn sounds off: Press the
SOUND OFF button on the
top of the projector
