RVC900N Rotary Valve Controller
Rev. A - Nov. 10
RVC900N Series
ROTARY VALVE CONTROLLER
U
s
e
r
M
a
n
u
a
l
U
s
e
r
M
a
n
u
a
l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVC900N Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FISNAR RVC900N Series

Summary of Contents for FISNAR RVC900N Series

  • Page 1 RVC900N Rotary Valve Controller Rev. A - Nov. 10 RVC900N Series ROTARY VALVE CONTROLLER...
  • Page 2 RVC900N Rotary Valve Controller Rev. A - Nov. 10 This page intentionally left blank...

  • Page 3: Table Of Contents

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 1. TABLE OF CONTENTS 1. Table of contents 2. Designated use 3. For your safety 4. Technisa data 4.1 Parts & description 5. Included parts 6. Start operation 7. Operation 7.1 Display 7.2 Status LED´s 7.3 Operation keys 8.

  • Page 4: Designated Use

    If the RVC900N is used for other functions as described below, it could come to personal or material damage. Use the RVC900N controller only for the functions, which are explained in this user manual. Fisnar Inc. is not responsible for personal or material damages, which happen because of incorrect usage.

  • Page 5: Technisa Data

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 4. TECHNICAL DATA : 9 ¼” x 8 ¼” x 2 ¾” (235 x 210 x 70mm) Measurements Weight : 3.6lbs. (1.65kg) : 100 – 240V AC 50/60Hz Power Supply Internal Voltage : 24V DC Voltage Rotary Valve : 0 ...

  • Page 6: Parts & Description

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 4.1 PARTS & DESCRIPTION [Front Side] Air pressure regulator Operating keys Pressure gauge for air outlets Graphic display Status LED´s [Back Side] Rotary valve Footswitch Power Air outlet Air outlet 0-24V DC (PWM) switch continuous pulsed...

  • Page 7: Included Parts

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 5. INCLUDED PARTS: RVC900N Controller Power Inlet cable Tube for Air Inlet User Manual Foot Pedal 6. START OPERATION: Connect the power inlet cable to the power inlet connector on the backside. Connect the air inlet tube from the compressor to the air inlet on the backside of the RVC900N.

  • Page 8: Operation

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 7. OPERATION: 7.1 Display: (values can be different) Marking Selected values Parameters Dispense 002.55 s Speed Wait time 0.20 s Retract 0.50 s Mode Prog: 1 P-IN 80psi C: 000027 Program Rotating Cyclecounter Display:...

  • Page 9: Operation Keys

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 7.3 Operating keys: PROG - switches to the next program SAVE - saves the actual parameters. Press the SAVE key for 2 sec. and select the wanted program with the UP / DOWN keys and press SAVE again to store the parameters.

  • Page 10: Parameter

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 8. PARAMETER: Select mode Pressing the PROG key switches to the next program and to manual mode Manual: In this mode, the dispense time does not get saved and the rotary valve dispenses as long as the dispense signal is activated by one of the following: footswitch / purge key / I/O-start.

  • Page 11: Service Menu

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 Keylock: By pressing SAVE + PRG at the same time, a key lock for the RVC900N can be activated. An activated key lock is shown in the display (lower right hand corner) with the symbol: By pressing SAVE + PRG again, the keylock is deactivated.

  • Page 12: Electrical Connections

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 10. ELECTRICAL CONNECTIONS 10.1 Rotary Valve: type: LEMO connector female 2-pol: EGG.00.302.CLL pins: pin 1 (red) 0-24V rotary valve Pin 2 0V (GND) rotary valve mating connector: LEMO connector male 2-pol. FGG.00.302.CLAD35 10.2 Footswitch: pins: connection between Pin 1 + 3 starts dispensing...

  • Page 13: Wiring Diagrams

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 10.4 Wiring Diagrams: Digital Inputs: A digital input is active, if the opto coupler is ON. If the opto coupler is connected to GND, the input is activated: Digital Outputs: If the digital output is active, the opto coupler is electro conductive.

  • Page 14: Maintenance And Cleaning

    RVC900N Rotary Valve Controller Rev. A - Nov. 10 11. Maintenance and cleaning The RVC900N is maintenance free Repairs should only be done by the manufacturer. Clean the RVC900N controller only with a clean, smooth and dry cloth. Do not use dissolvent material to clean the RVC900N controller. The foil at the front / back plate or the housing paint can be destroyed.
