Summary of Contents for Sitec STCU DS1
- Page 1 User Manual STCU DS1 Reading master with display for M-Bus devices...
-
Page 3: Table Of Contents
SOMMARIO SOMMARIO ............................... 3 INTRODUCTION ............................... 4 TECHNICAL SPECIFICATIONS ........................4 FUNCIONAL SPECIFICATIONS ........................4 DIMENSIONAL CHARACTERISTICS ......................4 PRODUCT CODE ............................4 RELATED PRODUCTS ..........................5 CONFORMITY TO REGULATION STANDARDS ..................5 SUPPORTED DEVICES..........................5 FRONT PANEL, TERMINAL BOX AND CONNECTION DIAGRAMS .............. 6 FRONT PANEL DESCRIPTION ........................ -
Page 4: Introduction
INTRODUCTION The STCU DS1 LOG is an M-Bus network hub, designed to gather data from connected meters, and show them to the user via the display of which is provided. Alternatively, logs may be made using the “STCU Reader” user program, provided separately. -
Page 5: Related Products
Apator Socomec Countis E26 (Other devices, not included on the list, may have been added after the printing of this manual, or may be compatible even if not listed. Contact Sitec Srl to verify or add other devices). 5/10 R4.A... -
Page 6: Front Panel, Terminal Box And Connection Diagrams
FRONT PANEL, TERMINAL BOX AND CONNECTION DIAGRAMS FRONT PANEL DESCRIPTION • LCD Display. • Keypad. • USB Interface Connector. TERMINAL BOX DESCRIPTION • Device Power Supply • Ground. • 230VAC 50Hz Power Supply. • 230VAC 50Hz Power Supply. • Communication port with the M-Bus network •... -
Page 7: Installation And Testing
INSTALLATION AND TESTING • Place hub at least two meters from power devices (pumps, inverters, etc.). • Fasten hub using the fastening supports inside the package. • Make the connections following the directions in the chapter: “Front Panel, Terminal Box and Con- nection Diagrams”. -
Page 8: Use
The STCU DS1 LOG can be commanded directly through the keypad found under the display. KEYPAD Meaning Description The “Enter” key is used to open the menu and start the selection processes. Enter The “Up” key is used for scrolling up in the menu, and for increasing the values inside specific menus. -
Page 9: Brightness Menù
BRIGHTNESS MENÙ To access this menu, from the “Settings” menu, select “Brightness” and press [Enter]. The screen that appears will be like the one here to the left. As indicated by BRIGHTNESS the screen, press the [Up] button to increase the value, and [Down] to decrease UP:+ DOWN:- F1:Exit... - Page 10 Internet: www.teleletture.it E-mail: info@sitecsrl.it Sitec Srl reserves the right to modify this document as necessary, without notice, in order to adapt it to future developments and/or new business needs; has prohibited the disclosure, although partial, if not expressly permitted. Also Sitec Srl assumes no liability arising from the use of this document.
