Tall Humidified Holding Cabinet
FSHC-12W1, FSHC-12W2,
FSHC-17W1, and FSHC-17W2 Series
Model FSHC-12W1
This manual contains important safety information
concerning the maintenance, use, and operation of
this product. Failure to follow the instructions
contained in this manual may result in serious
injury. If you're unable to understand the contents of
this manual, please bring it to the attention of your
supervisor. Do not operate this equipment unless
you have read and understood the contents of this
manual. Keep this manual in a safe location for
future reference.
FLAV-R-SAVOR
Installation and
Operating Manual
I&W #07.05.169.00
Model FSHC-17W1D
®
Model FSHC-17W2
Este manual contiene importante información
sobre
seguridad
mantenimiento, uso y operación de este
producto. Cualquier falla en el seguimiento de
las instrucciones contenidas en este manual
puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual
por favor pregunte a su supervisor. No opere
este equipo al menos que haya leído y
comprendido el contenido de este manual.
Almacenar este manual en una localización
segura para la referencia futura.
Model FSHC-17W2D
concerniente
al
