Good Way Technology FG3200 User Manual

Z-wave home gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Z-Wave Home Gateway
™
FG3200
®
( Z-Wave
Home gateway )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FG3200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Good Way Technology FG3200

  • Page 1 Z-Wave Home Gateway ™ FG3200 ® ( Z-Wave Home gateway )

  • Page 2: Table Of Contents

    Index INDEX ..............0 INTRODUCE ............1 PRODUCT DESCRIPTION AND SPECIFICATION ..2 PACKAGE CONTENTS ........... 3 ICON AND COMMAND CLASSES ......3 CONNECTION: ............7 1. A APP D ....... 7 NDROID OWNLOAD 2. A ..........8 ATEWAY 3. D ...........

  • Page 3: Introduce

    Introduce This gateway is a Z-Wave® enabled controller and security enabled Z-Wave plus product. Z-Wave® enabled devices displaying the Z-Wave® logo can also be used with it regardless of the manufacturer, and ours can also be used in other manufacture’s Z-Wave® enabled networks. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.

  • Page 4: Product Description And Specification

    Product Description and Specification...
  • Page 5 Item Description 1 Antenna 2.4GHz Wi-Fi 2 Wall Mount Hole Mounts the device to the wall 3 RJ45 port Connects to an Ethernet 4 DC-in jack Connects to the power adapter 5 Reset Restores to the default settings Power (Red); LAN / WAN (Green); 6 LED ®...
  • Page 6 Channels modes 2.422, 2.437, 2.452, in 802.11n HT40 mode Interface RJ-45 Ethernet Standard IEEE 802.3 Speed 10/100Mbps For Bridge or Wireless ISP Mode For Gateway Mode ® Z-Wave 908.42 MHz (US) RF Frequency 868.42 MHz(EU) 922.5 MHz (JP) Data Rate 9.6 / 40 / 100 kbit/s Output Power -21…+2.5 dBm...

  • Page 7: Package Contents

    Power Normal Mode 1.70W Consumption Housing Material ABS (Plastic) Physical Properties Dimension 104(L) x 50(W) x 17.5(H) mm Weight 64.5g Working Operation 0~60 degree Environment Temperature Storage -20~85 degree Temperature Relative 5~90% (Non-condensing) Humidity CE, FCC Compliance Package Contents  Z-Gate ...

  • Page 8: Icon And Command Classes

    Icon and Command Classes Heat(Sensor) Luminance Smoke Power Humidity Water PM25 Tamper Distance Door Window Ultraviolet Motion General Alarm Heat Air temperature Siren Non Support Notification...
  • Page 9 Gateway Z-Wave Support Command Classes COMMAND_CLASS_ZWAVEPLUS_INFO COMMAND_CLASS_VERSION COMMAND_CLASS_MANUFACTURER_SPECIFIC COMMAND_CLASS_DEVICE_RESET_LOCALLY COMMAND_CLASS_ASSOCIATION COMMAND_CLASS_ASSOCIATION_GROUP_INFORMATION COMMAND_CLASS_APPLICATION_STATUS COMMAND_CLASS_CRC_16_ENCAP COMMAND_CLASS_POWERLEVEL COMMAND_CLASS_SECURITY Gateway Z-Wave Controlled Command Classes: COMMAND_CLASS_ZWAVEPLUS_INFO COMMAND_CLASS_ASSOCIATION COMMAND_CLASS_ASSOCIATION_GROUP_INFORMATION COMMAND_CLASS_BASIC COMMAND_CLASS_BATTERY COMMAND_CLASS_SWITCH_BINARY COMMAND_CLASS_SENSOR_BINARY COMMAND_CLASS_CONFIGURATION COMMAND_CLASS_CRC_16_ENCAP COMMAND_CLASS_MANUFACTURER_SPECIFIC COMMAND_CLASS_METER COMMAND_CLASS_MULTI_CHANNEL COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION COMMAND_CLASS_SENSOR_MULTILEVEL COMMAND_CLASS_SWITCH_MULTILEVEL COMMAND_CLASS_NOTIFICATION COMMAND_CLASS_NO_OPERATION COMMAND_CLASS_SECURITY...
  • Page 10 COMMAND_CLASS_VERSION COMMAND_CLASS_WAKE_UP If FG3200 controller receives a Basic command, it will ignore the command. Z- Wave’s Groups (Association Command Class Version 2) The gateway will send DEVICE_RESET_LOCALLY_NOTIFICATION to associated Z-Wave devices when it is reset or factory-reset. It supports 1 association group which supports only one (maximum) associated node.

  • Page 11: Connection

    NOTE: Before using APP, please activate the Wi-Fi function of mobile device. The device should be able to locate the network FG3200, please input the default password 89191200, and make sure it is successfully connected.

  • Page 12: Add Gateway

    2. Add Gateway 1. Start Z-Butler app. Follow the instruction to Add New Gateway. You can search gateway signal. 2. Click the pop-up gateway information bar. 3. Setup name, account and password. Account and password default as “admin”/ “1234”.

  • Page 13: Dashboard

    3. Dashboard Enter Home page when Gateway is connected, Home page shows Dashboard, Device, Setting Scenarios, IP Camera, Settings, total 4 sections.

  • Page 14: Edit

    4. Edit On Homepage, top center shows connected Gateway, click top right corner Refresh/Add Gateway.

  • Page 15: Setting

    5. Setting pages Including “Notification Settings”, ”Version Update”.

  • Page 16: Gateway Management

    5.1 Gateway Management Including “Edit Gateway”, ”Remove Gateway”, ”Inclusion”, ”Exclusion”, ”Reset”, ”Set learn Start”, ”Set learn Stop”.

  • Page 17: Add(Inclusion)

    5.1.1 ADD(Inclusion) Ensure Gateway is connected, enter device page and click “Inclusion” to include devices. After the inclusion show window is finished, you can view the device at the device interface.

  • Page 18: Remove(Exclusion)

    5.1.2 Remove(Exclusion) Ensure Gateway is connected, enter device page and click “Exclusion” to exclude devices. After the exclusion show window is finished, you can view the device is remove from the device interface.

  • Page 19: Learn Mode

    5.1.3 Learn Mode Ensure the Gateway not include any device or Reset the Gateway. You can review and control the device for learned Gateway. Into the Learn Mode, show “Processing…”, operate another Controller into add device mode, after the completion of the study to be prompted to add success. When you need initiate a replication of network information from the controller to another controller or want to receive network information, please enter "include"...

  • Page 21: Reset

    5.1.4 Reset Click “Reset”, show “Are you sure to reset Z-Dongle?”and click OK to reset the Z-Wave network. 5.1.5 Factory Reset: FG3200 Reset button 10 seconds after the reset to reset the factory default Reset...
  • Page 22 * If this controller is the primary controller for your network, resetting it will result in the nodes in your network being orphaned and it will be necessary after the reset to exclude and re-include all of the nodes in the network. If this controller is being used as a secondary controller in the network, use this procedure to reset this controller only in...

  • Page 23: Device Page

    6. Device page Will show the trigger device and related device icon on the device page. You can also get the information of property for each device from this page. You can click the node number “>” to show the device node settings: “Advanced settings”, ”Remove Failed Node”, ”Node Neighbor Update”, ”Replace Failed Node”...
  • Page 24 Click the Basic icon will get the current state of the Device. Press Node number bar then select advanced stings and will show the Configurations and Association...
  • Page 25 6.1 The Network Rediscovery...

  • Page 26: Add Ip Camera

    7. ADD IP Camera First, please download the APP MyCamPro, and ensure Gateway is connected. 1. Execute MyCamPro and click the “skip”. 2. Click the “+” . 3. Click the “Add manually”. 4. Click the “Wireless”. 5. Please input the default password 89191200 for FG3200R1 and click the next step.
  • Page 29 1. Execute the Z-Butler APP. 2. Input the default account/password(admin/1234). 3. Enter the webcam page and click “+”. 4. Click the icon “magnifier”. 5. Click to join the IPCAM which you want. 6. Input the default username/password(admin/admin) and click “Add”. 7.

  • Page 31: Automator: Setting Scenarios

    8. Automator: Setting Scenarios 1. Select Scene settings from function bar. 2. Give the name to the scene task. 3. Click Select Sensor from Start Condition. 4. Select Door Sensor from Sensor Device. 5. Select On from Sensor Status. Click New Perform Action to implement.
  • Page 32 10. Give a name to the new scene. 11. Click Select Sensor from Start Condition. 12. Choose Door Sensor from Sensor Device. Click OFF from Sensor Status. Click New Perform Action. 13. Click Select ZWave Device from Perform Actions. 14. Select Siren from Action Device. Click OFF from Sensor Status.
