Quick Installation Guide
AIRNET 54 Mb Outdoor Bridge Point to Point Kit
AIR-PTP3500L
Package Contents:
• Two Netkrom AIRNET Outdoor Bridge Units
• Two Mounting brackets (include: 2 Wall/ Pole mounting system and 4 screw nuts)
• Two PoE Injectors
• Two Power Cables
• Two RJ45 Waterproof Connector System
• CD-ROM
• Two 75' Outdoor Rated Cat5e shielded cables
Advertisement
Table of Contents
Related Manuals for Netkrom AIR-PTP3500L
Summary of Contents for Netkrom AIR-PTP3500L
-
Page 1: Quick Installation Guide
AIRNET 54 Mb Outdoor Bridge Point to Point Kit AIR-PTP3500L Package Contents: • Two Netkrom AIRNET Outdoor Bridge Units • Two Mounting brackets (include: 2 Wall/ Pole mounting system and 4 screw nuts) • Two PoE Injectors • Two Power Cables •... - Page 2 Warnings • Do not work on the system or connect or disconnect cables during periods of lightning activity. • NETKROM shall not be liable for incidental or consequential damages resulting from the furnishing, performance, or use of this manual. • Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it can come into contact with such circuits.
-
Page 3: Package Contents
Package contents Kit Point to Point Take a moment to ensure you have all of the following parts in your Outdoor Waterproof Unit installation kit before you begin installing the product. If any parts are missing, please contact your local vendor or contact us, please see the contact information in Section... -
Page 4: Setup Requirements
Setup Requirements Before starting, please verify that the following is available: • CAT5/5e or FTP Outdoor Ethernet cable (from the AIRNET Outdoor Bridge to PoE Injector) • At least one computer is installed with a Web browser and a wired or wireless network interface adapter •... -
Page 5: Airnet Outdoor Bridge Point To Point Installation
AIRNET Outdoor Bridge unit. Then connect the other end of the cable to the PoE injector. For the Netkrom PoE, the recommended length of the Category 5 cable is up to 260 feet or 80 meters. - Page 6 PC. Step 3 Connect the power cable supplied in the Netkrom PoE kit to the mainelectrical supply and the power plug into the socket of the injector. Now, turn on your power supply. Notice that the POWER LED has lighted up.
- Page 7 (for example, you are on the side of a mountain in view of the base station antenna below), reverse the bracket so the Netkrom wireless radio Unit can be “tilted” downward when you aim the AIRNET Outdoor Bridge in a later step.
- Page 8 uConfig is a feature that provides the ability to directly access the AIRNET Outdoor Bridge without the need to know absolutely its IP address. It may be run directly from the product CD or installed on the user’s PC for later access.
- Page 9 Click the OK button to continue The default browser will be loaded using the correct IP address of the AIRNET Outdoor Bridge (regardless of how the computer’s TCP/IP properties are set), Default Password: password , and start configuring the Click on radio.
- Page 10 If you don’t use the uConfig Utility you need to establish Ethernet connection between your PC and the AIRNET Outdoor Bridge, by default the AIRNET Outdoor Bridge has the IP address 192.168.168.1. Therefore, your PC must be in the same network segment as the AIRNET Outdoor Bridge is to get Ethernet connectivity. Step 1 Go to Start button, then go to My Network Places and finally click on Network...
-
Page 11: Getting Started
Find below typical and basic configurations using the AIRNET Outdoor Bridge. For advanced features please refer to the user manual. Getting Started You can start configuring your AIRNET Outdoor Bridge using either your Web Browser or the uConfig utility. Address bar, enter http://192.168.168.1... - Page 12 Wireless Point to Point Setup The AIRNET Outdoor Bridge Point to Point Kit is commonly used in Point-to-Point Applications. implement Point-to-Point connection by simply setting one access point as RootAP in Access Point mode and setting the other access point in Transparent Client mode or in Client Mode.
- Page 13 Follow these steps to setup Transparent Client/s. Step 1 Select the Remote AP MAC checkbox. Enter the Remote AP MAC. Check the MAC address of your Remote AP under About system >> Wireless MAC. Ensure that The Current Mode is set to Transparent Client.
-
Page 14: Recommended Parameters
AIR-PTP3500L Recommended Parameters Recommended Country Code: In order to see almost all Frequency Channels available at 5 GHz, please select Country Code ): GB-United Kingdom. You can find Country Code option under >> Frequency Band Conversion: In order to use 3.4-3.7 GHz Frequency Band, please select in Wireless Profile: 802.11a. - Page 15 1. - Advanced Routing Configuration: Please go to page 85 of User Manual. 2. – Bandwidth Control: Please go to page 95 of User Manual. 3. – Remote Management: Please go to page 99 of User Manual. 4. – Advanced Wireless Configuration: Please go to page 114 of User Manual.
-
Page 16: Contact Information
Address: 2134 NW 99th Avenue Miami, Florida 33172 Phones: (+1) 305-418-2232 Fax: (+1) 305-418-9266 Sales and ordering: American Customers: salesusa@netkrom.com Worldwide Customers: sales@netkrom.com Latin American and Spanish Customers: ventas@netkrom.com Technical Support : Worldwide and English Customers: support@netkrom.com Latin American Customers:...
