ZHD01
TEMPERATURE SENSOR
BDA_ZHD01
USER MANUAL ZHD01
Congratulations and thank you for purchasing the Schwaiger ZHD01
product. Below you will find useful operating guidelines.
Paste in Z-Wave
• Make sure that Z-Wave RS is in the factory defaults setting.
• Activate „Inclusion/Paste" on the Z-Wave controller.
• Press the LED button on Z-Wave RS.
• Check the process status on the controller and Z-Wave RS.
Introduction
Schwaiger ZHD01 is a battery-operated temperature sensor. If it is integrated into the wireless
Z-Wave network, the control buttons can be used to control the heating system.
LED button
INCREASE temperature
Display
(with backlight)
LOWER temperature
Installation
1. Remove the back panel by
sliding it downwards.
3. Fasten the back panel to the wall.
Z-Wave information
General device class
Specific device class
Device type
SDK
NWI
Explorer frames
Manufacturer ID
Product type ID
Product ID
2. Replace the batteries.
4. Gently push the Z-Wave RS on the back panel.
Multi-level sensor
Routing multilevel sensor
Routing slave
4.55
Yes
Yes
0x0002
0x0003
0x8010
Display information
Display
LED
Rapid green flashing
Red flashing
Flashes
Red flashing every
150 seconds
Red flashing every
30 seconds
Z-Wave command classes
Command Class
Version
BASIC
V1
MANUFACTURER_
V2
SPECIFIC
VERSION
V2
BATTERY
V1
MULTI_CMD
V1
WAKE_UP
V2
PROTECTION
V2
CONFIGURATION
V2
SENSOR_MULTILEVEL
V6
CENTRAL_SCENE
V1
THERMOSTAT_
V3
SETPOINT
SCHEDULE
V1
INDICATOR
V1
Disposal information
This device contains no batteries. It is an electrical device. It can be disposed of free of charge at
specified disposal sites.
EC Declaration of Conformity
„Hereby Schwaiger GmbH declares that the ZHD01 product is in compliance with the essential requi-
rements and other relevant provisions of Directive 1999/5/EC. " The Declaration of Conformity can be
found at the following address: http://www.schwaiger.de/downloads
HOME AUTOMATION
MANUFACTURER INFORMATION
Dear Customer,
should
you
require
technical
advice
retailer
could
not
help
please
technical support.
Schwaiger GmbH
Würzburger Straße 17 90579 Langenzenn
Hotline: +49 (0) 9101 702-199
www.schwaiger.de
info@schwaiger.de
Business hours:
Monday to Thursday:
Friday:
Explanation
Room temperature displayed
Runs insertions or deletions
Insertions or deletions failed
Description
• Basic SET: Not supported
• Basic GET: Multi-level sensor get
• Basic REPORT: Multi-level sensor report
(1 °C accuracy)
ID from Danfoss and Z-Wave RS
Version of command classes, of the Z-Wave Library
and of Z-Wave RS
Battery status
Conserve battery power by transmitting multiple com-
mands in a single package
Switch-on intervals of 5 min to 24 h (default: 60
minutes)
0 = No protection
2 = User interface locked
Specific Z-Wave RS configuration
Specifies the value from the room temperature sensor
again
By pressing the LED button the transmission of
CENTRAL_SCENE_ NOTIFICATION is triggered.
When selecting a temperature setpoint on the display
controller, the setpoint is reported.
When selecting a temperature and a number of hours
on the display controller reported the program change
values.
Control of the LED display.
and
your
contact
our
08:00 - 17:00
08:00 - 14:30
