HSPT Golden Rainbow AUTOMATIC GOLDEN RAINBOW 10 PLUS Instruction Manual

RECOMMENDATIONS AND SAFETY
Recommended usage is to make an average of 2 to 3 pack a day or less. Tobacco only.
HSPT Golden Rainbow 10 + users must be of legal smoking age to use the machine.
Keep the machine and accessories away from children.
Keep and operate the machine in a well-ventilated environment (max.50% humidity) and away from liquids.
Always ensure the machine is unplugged from the electrical outlet before relocating, assembling, disassembling,
or cleaning it.
Don't touch the machine when in use, some mobile part can cause injury.
TROUBLESHOOTING
Machine doesn't start its cycle ?
Is the red LED light on front of the machine on?
If not, check if the AC cord is correctly plugged into the machine and/or to an AC plug.
Turn on the back switch and wait for the front red led turn on (expect slight delay)
Cigarette not compacted enough ?
Pause the cycle and check:
• That the set-up of the level control setting is correct. Increase compaction level if needed.
• That there is enough tobacco in the tobacco hopper.
• That the star wheels in the hopper do not have tobacco caught in the gears.
• That the tobacco size cut is at recommended standards (¼" to 5/8" or 6mm to 16mm).
• That the tobacco moisture is at recommended standard (ideal 14 or 15%).
Cigarettes cycle messed-up ?
Pause the cycle and check:
• That tubes are properly loaded and/or well aligned in the tube loader.
• That no tubes are damaged in the tube loader: Oval-shaped,, wrinkled, etc.
• That tobacco size is at standard (1/4" to 5/8" or 6mm to 16mm).
• That Tobacco moisture is at recommended standard (ideal 14 or 15%).
• That tube debris stays at exit of tobacco hopper.
• That the cleaning process was completed at the end of previous cigarette cycle.
WARRANTY
From the date of purchase, the Automatic HSPT Golden Rainbow 10 + comes with a one year limited warranty or 20,000
cigarettes made whichever come first. Please keep your proof of purchase. - The warranty covers repair of defective parts and
workmanship if the machine was used according to the owner's manual and manufacturer's recommendations; including
tobacco size cut and moisture standards. - Warranty will take effect after registration of your Automatic HSPT Golden Rainbow
10 + at www.hsptgoldenrainbow.eu, within 15 days from the date the machine was purchased.
Void of the Warranty
If is Failure to abide by standards of tobacco size cut and moisture level as defined by HSPT Golden Rainbow manufacturer.
If Physical or other damages caused by misuse, abuse, neglect, alterations, unauthorized repair, and machine opening without
manufacturer agreement or lack of proper maintenance.
If the unique machine Serial Number as well as the Quality Control stickers are removed, replaced, or broke and does not
match the machine, it's original parts, and/or electronic components.
Warranty Exclusions
Cleaning brushes and mat.
Machine and accessories returned to factory must be cleaned and properly packed in an appropriately sized box for return.
AUTOMATIC GOLDEN
RAINBOW 10 +
Residential Cigarette Making Machine
Visit our website at
www.hsptgoldenrainbow.eu
AUTOMATIC GOLDEN RAINBOW 10 +
Residential Cigarette Making Machine
INSTRUCTION MANUAL
Register your product now for a one year limited warranty or 20,000 cigarettes, whichever come first.
( Warranty information on page 4)
Visit our website at www.hsptgoldenrainbow.eu
WHAT'S IN THE BOX
(also include clean mat, cleaning brushes and power cord)
3
1
11
4
1
. Tubes Magazine (for 10 cigarettes at a time).
2
. Back carriage opening (cover to be installed).
3
. Tobacco hopper (load ONLY recommended tobacco).
4
. Discharge chute for cigarette (to be joined).
5
. Compaction level control for cigarette density.
6
. LED display for turning power on.
IMPORTANT
Tobacco moisture Tobacco length
MUST be between MUST be between
12% and 20% 1/4" to 5/8"
(6mm to 16mm)
(ideally 14% or 15%)
Failure to abide by standards of tobacco size cut and moisture level as defined
by HSPT Golden Rainbow manufacturer will void the warranty.
Patent pending
7
12
8
5
6 10
9
7
. Pause/Continue cycle button.
8
. Start/Stop/Return cycle button.
9
. Drawer for recycling excess tobacco (which can be reused).
10
. Cigarette counter.
11
. Tube Catcher.
12
. Plug and Power Switch (Located back of machine).
QUICK
START
2
