TPA CN2008 SE Documentation

Numeric control
Hide thumbs
Table of Contents

Advertisement

Quick Links

'
© T.P.A. S.p.A. S.p.A. Tecnologie e Prodotti per l
Automazione
Via Carducci, 221 - 20099 Sesto S. Giovanni
–
Tel. +390236527550
fax: +39022481008
e-mail:
marketing@tpaspa.it
-
www.tpaspa.it
P.I.: IT02016240968 C.F.: 06658040156
Numeric control
CN2008 SE
Documentation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CN2008 SE and is the answer not in the manual?

Questions and answers

Summary of Contents for TPA CN2008 SE

  • Page 1 ’ © T.P.A. S.p.A. S.p.A. Tecnologie e Prodotti per l Automazione Via Carducci, 221 - 20099 Sesto S. Giovanni – Tel. +390236527550 fax: +39022481008 e-mail: marketing@tpaspa.it www.tpaspa.it P.I.: IT02016240968 C.F.: 06658040156 Numeric control CN2008 SE Documentation...
  • Page 2 Document data Date 20/12/2016 Revision File Name eCN2008SE.pdf Protocol Documentation Type ; © T.P.A. S.p.A. Group name Remarks This documentation is property of T.P.A. S.p.A. Any unauthorized duplication is forbidden. The Company reserves the right to modify the content of the document at any time. The Company reserves the right to modify the content of the document at any time.

  • Page 3: Table Of Contents

    Revisions TABLE OF CONTENTS CONTENTS ..............................5 DESCRIPTION ........................... 6 FUNCTIONAL SPECIFICATION ....................7 General requirements ........................7 Control specifications........................7 Expansion specific boards ......................7 Power supply specifications ......................8 TECHNICAL DATA ........................... 9 System ............................9 I/O ............................... 9 Expansion Slot ..........................
  • Page 4 REVIEWS No. of Date Protocol Changes and/or changed paragraphs review Rev 0 20/12/2016 First release...

  • Page 5: Contents

    Contents CONTENTS This document describes the CN2008 Second Edition Numeric Control (hereafter abbreviated as SE). eCN2008SE...

  • Page 6: Description

     small sizes  low consumptions. CN2008 SE philosophy is to take back to the field the connections by means of a set of buses. According to the set of boards in the CN2008 SE, it is possible to configure a field bus.

  • Page 7: Functional Specification

     n°.1 serial RS485 (RS422 configurable by request).  n°.1 LAN Ethernet 10/100/1000 Mb/s for connection to PC supervisor.  n°.1 LAN Ethernet for EtherCAT bus. 2.3 Expansion specific boards  PC104 standard format  Dedicated panel  Front connectors.  TPA's approval on expansion board. eCN2008SE...

  • Page 8: Power Supply Specifications

    Functional specification 2.4 Power supply specifications  +24V +/- 10%, 4A input supply  Input protected and filtered. eCN2008SE...

  • Page 9: Technical Data

    Technical Data TECHNICAL DATA 3.1 System Processor: 1 GHz, 512KB cache RAM memory DDR3 1066 MHz, 1GB (or higher) Flash memory 512MB (or higher) Operating system Windows CE Operation temperature 5 - 45° C Storage temperature Moisture 10 - 95% relative moisture, without condensation Power Supply 24 V dc ±...

  • Page 10: Expansion Slot

    Technical Data Expansion Slot AlbMech-e Control up to 8 digital Mechatrolink II ® axes (at 1 Technical data: see relative documents TMSbus CAN Bus Management GreenBus 4.0 bus Feedrate override port Technical data: see associated documents TMSCAN CAN Bus: CANOpen Feedrate override port Technical data: see associated documents EtherCAT...

  • Page 11: Dimensions

    Technical Data 3.4 Dimensions eCN2008SE...

  • Page 12: Descriptions Of The Interfaces

    Description of the interfaces DESCRIPTIONS OF THE INTERFACES 4.1 24Vdc connector  12V: internal 12V power led  5V: internal 5V power led  24Vdc: power connector with polarization serigraphy 4.2 Connector PS/2 Keyboard and Mouse eCN2008SE...

  • Page 13: Rs232 And Rs485 Connectors

    Description of the interfaces 4.3 RS232 and RS485 connectors RS232 RING RS485 RS422 (by request) DATA- DATA+ eCN2008SE...

  • Page 14: Vga Video Out Connector

    Description of the interfaces 4.4 VGA video out connector Description Green Blue AGnd AGnd AGnd DDC dat HSync VSync DDC Clk eCN2008SE...

  • Page 15: Lan And Ethercat Connectors

    Description of the interfaces 4.5 LAN and EtherCAT connectors Description MDI0+ MDI0- MDI1+ MDI2+ MDI2- MDI1- MDI3+ MDI3- Act Link LED Speed LED 4.6 CAN and FRO connectors For the description, please, read the documentation of the TMSBus or TMSCAN board according to the board integrated into the basic control.

  • Page 16: Other Leds

    Description of the interfaces 4.8 Other leds In addition to the leds available on the previously described RJ45 connectors, hereafter you will find the references for the other leds on the interface. For the TX, RX and ST warning lights, please, see the TMSBus/TMSCAN documentation according to the basic configuration.
  • Page 17 Description of the interfaces eCN2008SE...
  • Page 18 Description of the interfaces eCN2008SE...
  • Page 19 Description of the interfaces eCN2008SE...
  • Page 20 Description of the interfaces eCN2008SE...

  • Page 21: Instructions

    However, you can also use a power supply unit (ad/dc converter) whose technical features are: Vout = 24V dc ±10%, Iout = 4 A, so that CN2008 SE functions can be guaranteed. in all its configurations described in the chapter 3.
  • Page 22 ; © T.P.A. S.p.A. S.p.A. Tecnologie e Prodotti per ’ Automazione Via Carducci, 221 - 20099 Sesto S. Giovanni – Tel. +390236527550 fax: +39022481008 e-mail: marketing@tpaspa.it www.tpaspa.it P.I.: IT02016240968 C.F.: 06658040156...
