ThunderX3 TK25 User Manual

KEYBOARD FEATURES

REC MACRO KEYS
Profiles for different games settings.
M1=Profile 1
M2=Profile 2
M3=Profile 3
REC Macro key
FN+"Q"
Adjusting button retransmission rate,
2 grar default, with speed 1S/60 byte
Set Macro to each of the five MACRO KEYS:
G1/G2/G3/G4/G5
and use these keys to fast respond to your game play.
REC the Macro key
Support 5 user-defined macros (G1-G5), free of driving manual recording, Each macro recording at most 30 bytes.
Press "REC" key start recording,LED (CAPS/NUMLOCK/WINLOCK) slowly flash,then press G1 appoint recording
instructions, press effective buttons for recording, with longest recording time 30S. If over, over recording.
Then press "REC" to quit recording. After it, all indication light back to current situation with M1-M3
three modes,that is G1-G5 could support record three different gaming macros.

Clear the REC Macro key

Press FN+"REC for 3S, clear EEPROM macros and backlight seting recording.
1/5
3
4
TK25
THUNDERX3 User Manual
LOCK KEYBOARD
F11
Press to select a backlight color:
1. Blue 2. Red 3. Purple 4. Off
5.FN+ (Three colors Breathing)
FN+PAGE UP - increase LED brightness
FN+PAGE DOWN - decrease LED brightness
Opens My Computer
Opens default web browser
Opens email
Mute
Increase volume
Reduce volume
FN+F11 lock keyboard
LED switch
FN+" "open and close Breathing LED
FN+Page Up: increase brightness,
FN+Page Down: decrease brightness,
backlight with high,middle, low four gears.
WIN / MENU LOCK
2
Free of driving manual recording

Function: Recording a Macro

1. Click the "REC"
2. The LED (CAPS/NUMLOCK/WINLOCK)
slowly flash.
3. Pree G1 appoint recording instructions,
press effective buttons for recording,
with longest recording time 30S.
4. Pree any key.
5. Over recording. Then press "REC" to
quit recording.
